WASTEWATER TREATMENT SYSTEM
OPERATION & MAINTENANCE MANUAL
WASTEWATER TREATMENT SYSTEMS
CLASS I / NSF STD 40
®
MANUFACTURED
PRODUCTS
BY:
QUANICS
TM
FIXED FILM MEDIA
®
PHONE: (502) 992-8200
1-877-QUANICS
FAX:
(502) 992-8249
®
Revised August 2007
Advertisement
Table of Contents
Summary of Contents for Quanics AeroCell ATS-SCAT-86-AC-C750
- Page 1 E n g i n e e r i n g Wa t e r S o l u t i o n s ® P.O. BOX 1520 PHONE: (502) 992-8200 6244 OLD LAGRANGE ROAD 1-877-QUANICS CRESTWOOD, KY 40014 FAX: (502) 992-8249 www.quanics.net...
-
Page 2: Table Of Contents
® ® Table of Contents INTRODUCTION PROCESS DESCRIPTION INSPECTION SEQUENCE SERVICE INSTRUCTIONS Section 1.0 Septic Tank Section 2.0 A300-8” Series Effluent Filter Section 3.0 Dosing Tank Section 4.0 Filtered Pump Vault Section 5.0 Controls/Pumps/Floats Section 6.0 Treatment Module Section 7.0 Recirculation Device TROUBLESHOOTING GUIDE SAFETY... -
Page 3: Introduction
ATS-SCAT-886-AC-C1250 ATS-SCAT-886-BC-C1250 ATS-SCAT-888-AC-C1500 ATS-SCAT-888-BC-C1500 We are eager to assist you with any questions or problems. Please contact QUANICS at 1-877-QUANICS to request assistance. PROCESS DESCRIPTION The QUANICS AeroCell & Bio-COIR are individual wastewater treatment systems utilizing fixed film media. The module(s) consist of a fiberglass tank(s) containing a pre-determined amount of media. Ef- fluent is sprayed over the media utilizing specialized spay nozzles. -
Page 4: Inspection Sequence
NSF International Stan- dard 40 Class 1 requirements. After passing through the full depth of media the effluent travels to the QUANICS ATS-GRD-100/80/20 recirculation device. The recirculation device splits the flow and dis- charges 80% back into the treatment stream and 20% to the final disposal point. -
Page 5: Dosing Tank
QUANICS product. To clean the filter: 1. Firmly pull the filter handle and slide the cartridge out of the case. 2. While holding the cartridge over the access opening, rinse off the cartridge with fresh water, being careful to rinse all septage material back into the tank. -
Page 6: Recirculation Device
material and may require replacement every 7 to 10 years. When the Bio-COIR media has reduced in volume by 50%, and the effluent quality fails to meet minimum regulatory requirements, it needs to be replaced. The open cell foam media is warranted to be free from defect for 10 years. -
Page 7: Safety
* The system will not perform to its fullest capabilities if volumetric overload is allowed to occur. This occurs whenever excessive water, above the designed flow rate, is allowed into the system. Excessive water use or leaking plumbing fixtures may cause this condition. The AeroCell &... -
Page 8: Drawings/Technical Data
soap is strongly recommended. * Wear disposable rubber gloves when handling wastewater-contaminated items or chlorine tablets. * Always dispose of scum, rags, trash, debris, or soiled material in a proper waste container. * If a wastewater spill or leak occurs in a yard, flush area with plenty of clean water and disinfect. If a spill or leak occurs in the house, clean with a dilute solution of bleach. - Page 9 500 GPD AeroCell System ® www.quanics.net/autocad.htm The septic tank shall have a minimum L:W ratio of equal to or greater than one. 750 GPD AeroCell System www.quanics.net/autocad.htm The septic tank shall have a minimum L:W ratio of equal to or greater than one.
- Page 10 1000 GPD AeroCell System ® www.quanics.net/autocad.htm The septic tank shall have a minimum L:W ratio of equal to or greater than one. 1250 GPD AeroCell System www.quanics.net/autocad.htm The septic tank shall have a minimum L:W ratio of equal to or greater than one.
- Page 11 1500 GPD AeroCell System ® www.quanics.net/autocad.htm The septic tank shall have a minimum L:W ratio of equal to or greater than one. 500 GPD Bio-COIR ® System www.quanics.net/autocad.htm 500 gallons per day 85ft of Bio-COIR media 5.88 gpd/ft hydraulic loading rate...
- Page 12 ® 750 GPD Bio-COIR System www.quanics.net/autocad.htm 750 gallons per day 138ft of Bio-COIR media 5.88 gpd/ft hydraulic loading rate Eight 120 degrees spray nozzles The septic tank shall have a minimum L:W ratio of equal to or greater than one.
- Page 13 1250 GPD Bio-COIR ® System www.quanics.net/autocad.htm 1250 gallons per day 223ft of Bio-COIR media 5.88 gpd/ft hydraulic loading rate Twelve 120 degrees spray nozzles The septic tank shall have a minimum L:W ratio of equal to or greater than one.
-
Page 14: Ats-Scat-886-Ac-C1250
ADVANCED TREATMENT SCAT AeroCell & Bio-COIR ® ® ® ATS-SCAT-6 ATS-SCAT-8 AeroCell & Bio-COIR Specifications Model # Nozzles Modules Media Loading Septic Tank Pump Tank Individual Discharge Doses (ft 3 ) (gpd/ft 3 ) Rating (gal) (gal) Dose Volume Volume per (gal) 24 hrs. -
Page 15: Fpv-H44-4
1/16” • Available with either 2 or 4 filter plates • Includes maintenance plate for servicing ease Warranty for Defects in Material and Workmanship FPVs - 2 Year All FPVs when used with a QUANICS pump - 10 year... -
Page 16: P-Se-13T
PRESSURE DISTRIBUTION Pumps P-SE-13T Specifications Capacities: From 15 - 80 GPM Heads: To 260 FT Motor: 1/2 HP; hermetically sealed with automatic thermal overload Electrical: 115V, 12.0 FLA, 1PH, 60Hz Operation: Manual model (controls required) Minimum Diameter: 4” (102mm) Impeller: Delrin®, closed vane type Solids handling: 1/8”... -
Page 17: Ac-Ft-3
Pressure Distribution Grommets PDS-GT-1.5 PDS-GT-2.0 Materials • 65 Durometer PVC Warranty for Defects in Material and Workmanship • All components - 2 Years STEP SYSTEMS Float Tree AC-FT-3 Materials Pipe • 1.5” or 2” SCH 40 PVC • 1.5” or 2” PVC flex tubing True Union Ball Valve •... -
Page 18: Ac-Jsb-4
STEP SYSTEMS Junction Box AC-JSB-4 Materials Lid & Box • High impact, corrosion resistant thermoplastic • Weatherproof • 1/2” UL approved, CSA Certified round cable liquid-tight strain relief connectors • 1-1/2” terminal adapter hub Gasket • Flexible PVC Screws • Brass Warranty for Defects in Material and Workmanship •... -
Page 19: Ats-Grd-100/80/20-N
• High density non-corrosive polyethyl- ene plastic • Stainless steel screws • Neoprene gasket IMPORTANT: • When adding risers together for deeper installations QUANICS does RB-R-26x18 (Riser) not recommend exceeding a maximum depth of 48”. • Neoprene gaskets must be installed as per instructions •... -
Page 20: Wiring Schematics
Wiring Schematics... -
Page 21: Data Plates
Consecutively Serial Numbered Data Plates & Maintenance Sticker... - Page 22 4. Regulatory Notification: Send a copy of the service report to the applicable regulatory agency, if required. 5. Manufacturer Notification: Send a copy of the service report to QUANICS as required to continue the AeroCell Limited War- ranty.
- Page 23 QUANICS be liable for any incidental or consequential damages or any labor, material, freight or any other expense required to replace, correct or reinstall the product. QUANICS’s liability is limited to repair or replacement of the part. Except as stated herein, there are no warranties express or implied, including the warranty of merchantability or warranty of fitness for a specific purpose.
- Page 24 E n g i n e e r i n g Wa t e r S o l u t i o n s ® P.O. BOX 1520 PHONE: (502) 992-8200 6244 OLD LAGRANGE ROAD 1-877-QUANICS CRESTWOOD, KY 40014 FAX: (502) 992-8249 www.quanics.net...
