General

© 2004 ABB STOTZ-KONTAKT GmbH
General
The Switch Actuator Module SA/M 2.6.1 as well as the Electronic Switch
Actuator Modules ES/M 2.230.1 and ES/M 2.24.1 are snapped into a module
slot of the Room Controller Basis Device RC/A 8.1. They are used to control
switched loads:
Type of load
Lighting
Electrothermal valve drives (heating control)
Fan coil units
signaling equipment (ohmic loads)
The Room Controller Basis Device establishes the connection to the ABB i-
®
bus EIB / KNX installation bus.
All the modules have two outputs each. The Switch Actuator Module SA/M
2.6.1 switches via relay outputs while the Electronic Switch Actuator
Modules switch via noise-free, wear-resistant electronic semiconductor
components.
SA/M 2.6.1 and ES/M 2.230.1 are automatically connected to the incoming
supply when they are snapped into the Room Controller Basis Device. The
ES/M 2.24.1 is supplied via two terminals with 24 V DC.
On the output side, the devices have screw terminals with plug-in
connection.
The comprehensive functionality is defined by programming the Room
Controller Basis Device with the EIB Tool Software (ETS2 V1.2a or higher).
It is almost identical for all three devices.
Suitable module type
SA/M 2.6.1
ES/M 2.230.1, ES/M 2.24.1
SA/M 2.6.1
ES/M 2.230.1, ES/M 2.24.1
