Controls and indicators
1
2
3
7
ON/STAND-BY
Main Unit
2
3
4
5
MENU
6
7
Remote Control with touch panel
■ Precaution in using the touch panel
●
Use soft cloth to gently clean the touch panel.
●
Always place the remote control face up to avoid damage to
the touch pad.
●
Do not press the pad too hard, it can damage the touch
sensor.
●
Touch only on one dot for each function as it will not operate
if you touch 2 pads simultaneously.
Dot
8
E
SOUND
9
1
8
9
TV DISPLAY
10
11
ENTER
12
13
Dot
■ Main unit front view
4
5
1.
Sliding Top Cover . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6
2.
iPod and iPhone Dock . . . . . . . . . . . . . . . . . . . . . . 14
3.
ON/STAND-BY Button . . . . . . . . . . . . . . . . . . . . . . 12
4.
E
Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SOUND
5.
Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . 12
6.
Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.
On/Stand-by Indicator . . . . . . . . . . . . . . . . . . . . . . 12
8.
E
Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SOUND
9.
Subwoofer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
■ Remote control with touch panel
1.
Remote Control Transmitter . . . . . . . . . . . . . . . . . 11
2.
iPod and iPhone Menu Pad . . . . . . . . . . . . . . . . . . 15
3.
iPod and iPhone Enter Pad . . . . . . . . . . . . . . . . . . 15
4.
Remote Control Active Indicator . . . . . . . . . . . . . . 12
5.
iPod and iPhone Skip Up and Down Pads . . . . . . 15
6.
On/Stand-by Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.
iPod and iPhone Cue and Review Pads . . . . . . . . 15
8.
iPod and iPhone Shuffle Pad . . . . . . . . . . . . . . . . . 15
9.
iPod and iPhone Play/Pause Pad. . . . . . . . . . . . . . 15
10. iPod and iPhone TV Display Pad . . . . . . . . . . . . . . 15
11. E
Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SOUND
12. Volume Up and Down Pads . . . . . . . . . . . . . . . . . . 12
13. iPod and iPhone Cursor Up and Down Pads . . . . 15
Note:
Before using remote control, please remove plastic protective
shield at battery holder.
Battery holder
DK-AP8P
Reference page
Reference page
Plastic shield
7
