  • Page 1 SOFTWARE MANUAL α SIMPLE APPLICATION CONTROLLER...
  • Page 2 α • If in doubt at any stage of the installation of the series controller always consult a profes- sional electrical engineer who is qualified and trained to the local and national standards which apply to the installation site.
  • Page 3 α Simple Application Controllers AL-PCS/WIN-E SOFTWARE MANUAL Manual number : JY992D74001 Manual revision : D Date : Jan 2000...
  • Page 4 α Simple Application Controllers...
  • Page 5 α Simple Application Controllers FAX BACK Mitsubishi has a world wide reputation for its efforts in continually developing and pushing back the frontiers of industrial automation. What is sometimes overlooked by the user is the care and attention to detail that is taken with the documentation. However,to continue this process of improvement, the comments of the Mitsubishi users are always welcomed.
  • Page 6 α Simple Application Controllers...
  • Page 7 All maintenance should be carried out in accordance with established safety prac- tices. c ) All operators of the completed equipment should be trained to use that product in a safe and co-ordinated manner in compliance to established safety practices. The operators should also be familiar with documentation which is connected with the actual operation of the completed equipment.
  • Page 8 α Simple Application Controllers viii...

  • Page 9: Table Of Contents

    Table of Contents Guideline...........................vii 1. Introduction....................1-1 1.1 Outline ........................ 1-1 1.1.1 List of Models Compatible with the VLS software ........... 1-1 1.1.2 Product Configuration....................1-1 1.1.3 Major Features of the AL-PCS/WIN-E Software ............ 1-1 1.2 Definitions ......................1-2 1.3 Abbreviations ...................... 1-2 2.
  • Page 10 5.10 Window ....................... 5-4 5.11 Help ........................5-4 6. Function Block Diagram (FBD) Operation ..........6-1 6.1 Opening a New File .................... 6-1 6.1.1 FBD Base Resize ....................6-1 6.1.2 FBD Base Color ...................... 6-1 6.2 The Program Edit Mode - Begin to Program ............6-2 6.2.1 Inputs........................
  • Page 11 7.2 Insert an LCD Display..................7-2 7.2.1 The Insert Menu ...................... 7-2 7.2.2 Simulation and Monitor Mode.................. 7-2 7.3 Adding an OLE File..................... 7-3 7.4 Adding a Signal or Function Block..............7-3 7.5 The Simulation Mode..................7-3 7.6 The Monitor Mode....................7-4...

  • Page 13: Introduction

    NT Version 4.0 and above (hereafter referred to collectively as Windows). The software has been designed to be both powerful and user friendly. While many of the software features can be learned intuitively, a detailed help file has been incorporated into the software to assist users in finding answers to their questions.

  • Page 14: Definitions

    Function Blocks, Memory Bits, or Keys) are placed on the FBD base during programming. Digital - A type of Input or Output that only recognizes an On or Off state. An On state can also be referred to as “High” or “1” while the Off state can be referred to as “Low” or “0”.

  • Page 15: Installation

    Operating System Requirements The AL-PCS/WIN-E software is designed to be installed on a computer that meets or exceeds the following specifications. Please check whether your personal computer meets these requirements prior to the software installation.

  • Page 16: System Configuration

    A C IN P U T A C 1 0 0 /2 4 0 V E S C R E L A Y O U T P U T O U T 1 O UT 2 O U T 3...

  • Page 17: Using The Help Files

    The F1 key will provide specific help on a highlighted object. Click a system component on the FBD base to highlight it and press the F1 Key to bring up a dialog screen. To receive Help on a command, move to the command with the mouse until the instruction is highlighted in blue.

  • Page 18: The Contents Command Or Tab

    The Contents Command or Tab The contents menu allows the user to choose from the following categories or chapters Introduction - Choose from a basic introduction, information on the FBD base, or the System Sketch Operations. Menu Options - Choose to view detailed information upon each pull down menu available at the top of the screen.

  • Page 19: The Index Tab

    3.3.3 The Find Tab The Find Tab generates a list of key VLS words and lets you search for help on those words. A matching words directory gives an option to narrow the number of matches found. A third directory lists the topics in which your word appears.
  • Page 20 α Using the Help Files 3 Simple Application Controllers...

  • Page 21: What You Should Know Before Starting To Program

    α What You Should Know Before Starting to Program 4 Simple Application Controllers What You Should Know Before Starting to Program This section describes the basic functions and background information necessary to the proper operation of the VLS software. Please read and understand this section prior to begin- ning your first program.

  • Page 22: The Function Block Diagram Base

    The Function Block Diagram (FBD) base provides the platform upon which the program for the α controller is constructed. The FBD base consists of a large wiring area (green by default), a title box and input and output rectangles vertically along the right and left hand sides, respec- tively.

  • Page 23: The System Sketch Monitor Screen

    Simple Application Controllers The System Sketch Monitor Screen The System Sketch Screen is a simple drawing window. System sketch is useful to give the pictorial view of I/O devices which are connected to the Controller and the programming logic. The following operations can be performed in System Sketch.

  • Page 24: The Programming Mode

    Use the Accessories Tool bar to add components as in the FBD base. Copy components to or from the FBD base. Select any component in the window by pressing the mouse left but- ton and drag the object to the desired location. Double click on a Function Block to open the parameter setting dialog.

  • Page 25: Modem Communication

    Modem Communication α controller can communicate via modems to a PC using VLS software. The user can Upload or Download Programs, monitor counter values or function block times, change param- eter settings, or write new data to the controller. All communications are initiated from VLS α...

  • Page 26: Modem Initialization

    specifications.

  • Page 27: Pc To Modem Configuration Check

    α What You Should Know Before Starting to Program 4 Simple Application Controllers Please refer to the modem manufacturer’s manual for the necessary requirements for models other than the one’s listed here. Maker/Model 3Com AIWA Remarks SP560V-P PV-AF3360 Require command prefix Set local echo Echo Off Displays/suppress result codes...

  • Page 28: Connecting The Modem Telephone Line

    Box. Type in your telephone number, pick the modem name from the options available, and enter the Maximum Data Transmission Speed. The Dialing box will appear while the modem tries to make a connection. 4.8.5 Data Transfer After the modem line has been successfully established, data can be transferred between VLS α...

  • Page 29: As-Interface Programming

    In order to address the slaves from the Master station, only one unaddressed slave can be active at any one time. Once a slave has an address, another passive slave can be turned to an active state to receive its address. Please refer to the AL-ASl-BD manual and the manual for the ASI Network Master controller.
  • Page 30 α What You Should Know Before Starting to Program 4 Simple Application Controllers 4-10...

  • Page 31: Menu Bar Functions

    Save (Crtl+S) - Saves the current file to its current name and directory. Save As - Save the current file under a new name and or directory. The first time a file is saved this command will come up so that the file can be named.

  • Page 32: View

    Search By Comment - Search for a Function Block by the attached comment. The comment does not have to be displayed nor is the search case sensitive. The text, however, must be an exact match.

  • Page 33: Controller

    Check Used Memory - Check the amount of memory, function blocks, or input signals used in the program. Simulation - The simulation mode will run the program in the VLS memory without a controller. This is very useful to check your program prior to transferring it to the actual controller.

  • Page 34: Window

    Contents - Shows the Table of Contents of the Help Function. The user can click on the desired chapter and the help file will appear onscreen. Search for Help on... - Displays the opening screen of the Help command. Choose from a list of instructions and reference information on the features of the VLS software.

  • Page 35: Function Block Diagram (Fbd) Operation

    Open an existing file with the “Open...” command under File or by clicking on the Open icon. A list of the current VLS files contained in the Prog default folder will appear. Choose a file from this folder or browse and open a file in another location.

  • Page 36: The Program Edit Mode - Begin To Program

    FBD Base and connecting the various components together with the wiring analyzer. There are five types of system components that can be placed on the FBD base. A short description of the function and placement locations possible for the various components follows.

  • Page 37: System Memory Bits

    The six Logic Blocks - AND, OR, NOT, XOR, NAND, NOR - can receive only digital inputs. These blocks turn their Output on depending on the ON/OFF conditions of their Inputs. Please see the Help File for a detailed description of each block.

  • Page 38: Placing The Blocks On The Fbd Base

    To place the Function Blocks or Signals on the FBD base, left click once on the icon and move the mouse to the desired location for the icon to be placed. The arrow should turn into a crosshair when pulled over the FBD base border. Left click to install the icon.

  • Page 39: Connecting Functions And Blocks

    Display Signal Number box. The Comment Edit box is used to enter a comment which will be displayed on the top of the icon. This can be up to 256 characters but only 16 characters will be considered for display.

  • Page 40: The Function Blocks

    The Function Block Wizard Th e FB D W iza rd is a too l to le arn fu nc tion b lock programming. It can guide the user through simple...

  • Page 41: Choose Additional Function Blocks

    Use the Up and Down arrow keys to scroll through the possible combinations. Depending upon the number and type of Function blocks chosen, dozens of possible combinations will show onscreen. The first combination will be chosen as a default if no selection is made. 6.5.5...

  • Page 42: Setting Parameters

    Double click on the Function Block to open the parameter dialog box and enter the parameters as required. A Boolean Function Block will always appear in this screen to enable the user to employ Logic Operations. The logic must be set for the Boolean operation. (The logic can be set so that the whenever the input is On, the Boolean Block is On.

  • Page 43: Simulation Mode

    Force Outputs On/Off Outputs can be forced On/Off momentarily but the existing program parameters will overwrite the force at the next program scan. The force will be in effect long enough to active a Pulse, Set/Reset, or other trigger related signal.
  • Page 44 The Monitor Mode can be used to monitor the current conditions of an controller that is α running a program. The controller must be connected to the PLC via the AL-232CAB cable and running or, when Monitor Mode is started an error dialog box will appear.

  • Page 45: Turn Signals On/Off

    If during the course of monitoring the controller contents are updated using the front panel keys, a message box will appear stating that controller contents are updated and monitoring will be stopped. The application will automatically switch to Program mode.
  • Page 46 α Function Block Diagram (FBD) Operation 6 Simple Application Controllers 6-12...

  • Page 47: System Sketch Screen Operation

    Base size can be increased to a scroll bar position limit of 30,000. 7.1.2 Changing the Base Color Choose a new Base Color from the shades available in the Set Base Color command in the Options Menu. 7.1.3 Drawing Lines, Ovals, and Rectangles Lines can be drawn by clicking on the line icon and then moving the mouse to place for the line to start.

  • Page 48: Changing Colors

    A Display function block will cause a dialog box to appear upon entering Simulation or Monitor Mode. This box will give a prompt for whether to add the Display to the System Sketch Window base. Check yes to automatically add the LCD Display.

  • Page 49: Adding An Ole File

    Function Block parameters. Updates to Function Block values will be transferred to the FBD base and signals can be turned On/Off with a click of the mouse just as would be done in the FBD base. There is no wiring to show status in the System Sketch Window.

  • Page 50: The Monitor Mode

    FBD base and from there to the controller. Force signals On/Off momentarily with a click of the mouse just as would be done in the FBD base. There is no wiring to show status in the System Sketch Window.
  • Page 51 Simple Application Controllers Under no circumstances will MITSUBISHI ELECTRIC be liable or responsible for any consequential damage that may arise as a result of the installation or use of this equipment. All examples and diagrams shown in this manual are intended only as an aid to understanding the text, not to guarantee operation.
  • Page 52 HEAD OFFICE: MITSUBISHI DENKI BLDG MARUNOUCHI TOKYO 100-8310 TELEX:J24532 CABLE MELCO TOKYO HIMEJI WORKS: 840, CHIYODA CHO, HIMEJI, JAPAN JY992D74001D Effective Jan 2000 (MEE 0001) Specifications are subject to change without notice.
