Icelined Refrigerator
Operation Manual
•Please read this instruction carefully before using.
•Our company reserves the right to interpret the Operation Manual.
•The appearance of refrigerator please prevail in kind.
•Please keep it properly with the invoice after reading.
•Any upgrade of refrigerator or software is carried out without notice.
Model :
HBC - 80
HBC - 150
HBC - 260
Advertisement
Table of Contents
Related Manuals for Haier HBC-150
Summary of Contents for Haier HBC-150
- Page 1 Icelined Refrigerator Operation Manual Model : HBC - 80 HBC - 150 HBC - 260 •Please read this instruction carefully before using. •Our company reserves the right to interpret the Operation Manual. •The appearance of refrigerator please prevail in kind. •Please keep it properly with the invoice after reading.
-
Page 3: Product Feature
• High-performance insulation layer, good heat insulation effect. • Safety door lock and other humanized design. The Haier refrigerator you obtained is probably not exactly the same as illustrated in the Operation Manual due to continuous improvement of product, and we sincerely apologize for this. The contents... -
Page 4: Table Of Contents
Content Product Feature ............1 Content ..............2 Safety Precautions ............ 3 Precautions for use............ 6 Name of each component ........11 Method of Use ............12 Cleaning and Maintenance ........14 Wiring Diagram ............15 Specifi cation&Packing Slip ........16 Explosion diagram ............ -
Page 5: Safety Precautions
Safety Precautions Dear user's: Thank you for using Haier Icelined Refrigerator. For your better reading this specifi cation and using this refrigerator, and to prevent from personal injury and damage to the goods, please read carefully and comply with the contents which has the following identifi ers in this manual. - Page 6 Do not climb up to the refrigerator or place articles on the refrigerator, otherwise it may cause personal injury or damage of refrigerator due to overturn of the refrigerator. The plastic packaging bag should not be placed where the child is easy to get, because the plastic bag may cause suffocation.
- Page 7 Only the professional technicians or after-sale service men can install this refrigerator. Failure to do so may result in electric shock or fi re. Make sure to place the refrigerator fi rmly on a solid and fl at ground. If the ground is not stable or it is not properly placed, it will cause overturn of the refrigerator or personnel injury.
-
Page 8: Precautions For Use
Precautions for use • Please check if the inner temperature reaches the setting value before placing the goods into the refrigerator. Then, place a few items into the former in batches. • The displayed temperature value of the refrigerator refers to the temperature of the temperature sensing probe in the display box. - Page 9 Product Installation • Ambient temperature: 5 ℃ to 43 ℃ . Good ventilation. Air conditioning system shall be used if necessary. • Ambient humidity: 15%~90% • Avoid large quantities of dust. • Avoid mechanical sway or vibration. • The working position altitude of the refrigerator: below 2000m. •...
- Page 10 1. Remove the packing materials and the packing straps Take down all the packing material and packing straps used for transportation. • Before unpacking the package, the refrigerator can be transported with forklift or clip charter. If using forklift, It shall insert under the wood support plate of the refrigerator from front or back side and move the refrigerator.
- Page 11 5. Set aside Do not power on the refrigerator fi rstly after leveling and cleaning. Let it stand for over 24 hours before powering it on so as to ensure normal running of the refrigerator. 6. Before the main power switch is energized, confi rm the following matters: 1.
- Page 12 Please observe the following rules when conducting initial start-up and continuous running: In the case of empty container, connect the refrigerator to the power supply of appropriate specifi cation. When the power is turned on, the temperature controller display will light on. Before leaving the factory, the corresponding parameters have been set.
-
Page 13: Name Of Each Component
Name of each component Handle Door lock Hinge Indicator Draining nut Air intake Storage basket Condenser... -
Page 14: Method Of Use
The parameters of the factory are already set before leaving factory ,User changing parameters are not supported. For the three models of HBC-80, HBC-150 and HBC-260, the temperature inside the refrigerator is displayed on the left side display screen. The display screen on the right will not display at normal situation. - Page 15 • Temperature controller fault code Display symbols Description Remarks Refrigerating sensor failure Ambient temperature sensor failure high temperature alarm low temperature alarm • Temperature displayer Temperature displaying area Solar receiving area REFREGUTOR--shows the temperature of the vaccine storage area; The displayer is equipped with solar energy and is powered by itself, without additional circuitry. The display only shows the temperature inside the refrigerator, Do not control the refrigeration system of the product.
-
Page 16: Cleaning And Maintenance
Cleaning and Maintenance • Before cleaning, turn off the main switch and disconnect the power supply. • The detergent of the cleaning product must be diluted, otherwise the plastic part or the refrigerator shell might be change color. • If the product is not used for a long time, turn off the switch, disconnect the power supply and empty the contents in the refrigerator. -
Page 17: Wiring Diagram
Wiring Diagram... -
Page 18: Specifi Cation&Packing Slip
Specifi cation&Packing Slip Specifi cation Model No. HBC - 80 HBC-150 HBC - 260 Ambient temperature (℃ ) +5 - +43 +5 - +43 +5 - +43 Temperature range of refrigerator ( (℃ ) +2 - +8 +2 - +8... -
Page 19: Explosion Diagram
Explosion diagram... - Page 20 Name Remarks 0274000357 Solar display screen 0070814623D Handle Assembly 0070816334 Hinge assembly-assembly 0070203942B Upper/ Lower Hinge Cover 0070204349B HBC-150 back condenser: 0270700421 0270700425 HBC-80 Condenser HBC-260 back condenser: 0270700621 0074180007 The fi lter 0274000418 Compressor 0075050003 Power switch 0270400390 Power cord socket...
