- Page 1 OCEANIC SYSTEMS 10.1” PRIMARY DISPLAY Part Numbers: 5010 USER MANUAL Revision 1.00...
-
Page 2: Table Of Contents
1 Introduction ............2 1.1 Product Features ..........2 2 Unit Dimensions ........... 3 3 Installation............4 3.1 Unpacking The Box ..........4 3.2 Mounting The Unit..........4 3.3 Connecting The Display........4 4 User Controls ............5 5 Technical Support ..........6 6 Warranty ............ -
Page 3: Introduction
INTRODUCTION The Oceanic Systems’ 5010 NMEA2000® Primary Display is a 10.1”, high bright, sunlight readable 1000cd/m2 display. The 10.1” Primary Display is designed for the Poseidon® System and contains a button panel to control the brightness of the backlight to the display. -
Page 4: Unit Dimensions
UNIT DIMENSIONS Outside/overall dimensions 262mm x 186mm x 46mm Inside/active area dimensions 230mm x 155mm Diagonal 10.1” 262mm 46mm 3 of 7... -
Page 5: Installation
INSTALLATION 3.1 UNPACKING THE BOX You will find the following items in the shipping box: 1x 10.1” Primary Display 1x 5m HDMI cable 1x 5m USB cable 1x 2m DC Power cable 1x Mounting kit (x4 screws and x4 mounting clamps) 1x User Manual (this document) 3.2 MOUNTING THE UNIT 1. -
Page 6: User Controls
USER CONTROLS The button panel on the screen provides the following BRIGHT STANDBY Each press will decrease the brightness level. Holding the button will continue to decrease the brightness until the minimum level is reached. BRIGHT Each press will increase the brightness level. Holding the button will continue to increase the brightness until the maximum level is reached. -
Page 7: Technical Support
Email: sales@osukl.com Web: www.osukl.com Copyright © 2019 Oceanic Systems (UK) Ltd. All rights reserved. Our policy is one of continuous product improvement so product specifications are subject to change without notice. Oceanic Systems products are designed to be accurate and reliable. -
Page 8: Warranty
Systems sole obligation hereunder, provided product is returned pursuant to the return requirements below, shall be limited to the repair or replacement, at Oceanic Systems option, of any product not meeting the above limited warranty and which is returned to Oceanic Systems; or if Oceanic Systems is unable to deliver a replacement that is free from defects in materials or workmanship, Purchaser’s...
