- Page 1 3-213-968-E1 (1) Trinitron Color TV Operating Instructions • Before operating the unit, please read this manual thoroughly and retain it for future reference. KV-HG21 © 2007 Sony Corporation...
-
Page 2: Specifications
Dimensions (w/h/d, mm) 638 × 458 × 482 Mass (kg) Design and specifications are subject to change without notice. Made in Malaysia. Manufacturer: Sony Corporation Address: 1-7-1 Konan, Minota-ku, Tokyo 108-0075, Japan. KV-HG21M91 Output: 1 Phono jacks; 1 Vp-p, 75 ohms Output: 1 Phono jacks;... - Page 3 WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 110 – 240 V AC. • Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.
-
Page 4: Getting Started
C Getting Started Step 1 Insert the batteries (supplied) into the remote. • Do not use old or different types of batteries together. Step 2 Connect the antenna cable (not supplied) to 8 (antenna input) at the rear of the TV. •... - Page 5 Setting up your TV (“Initial Setup”) When you turn on your TV for the first time, the “Initial Setup” menu will appear. You can adjust settings below using the buttons on the remote control or TV front panel. Press V , v , B or b to select or adjust items, then press Select the desired menu language.
-
Page 6: Connecting Optional Components
Connecting optional components You can connect a wide range of optional components to your TV. Connecting cables are not supplied. Connecting to the TV (front) Connecting to the TV (rear) Antenna Audio/ cable Video cable DVD Player • If you connect a VCR to 8 (antenna input), preset the signal output from the VCR to the program number 0 on the TV (see L). -
Page 7: Troubleshooting
If you find any problem while viewing your TV, you can either use the “Factory Settings” function (see M) or check the Troubleshooting guide below. If the problem persists, contact your Sony dealer. Snowy picture, noisy sound • Check the antenna setup and other connections. - Page 8 • Count the number of times the 1 (standby) indicator flashes. Press 1 on the TV to turn it off, disconnect the AC power cord and inform your dealer or Sony service center of how the indicator flashes (duration and interval).
-
Page 9: Tv Buttons And Remote Control
TV buttons and remote control PROG WEGA GATE RETURN PROG +/– 2 +/– WEGA GATE menu operations (see I) , , , WEGA GATE PROG +/– 2 +/– Broadcasting NICAM stereo NICAM bilingual NICAM monaural NICAM Main (main), Mono A2 stereo A2 bilingual •... - Page 10 TV buttons and remote control (continued) Select TV or video input. Input numbers. For program numbers 10 and above, enter the second digit within two seconds. Select sound mode options with a 5-Band Graphic Equalizer display: “Dynamic”, “Standard”, “Custom”* (see K). 100 300 1k 3k 8k * When the “Custom”...
- Page 11 TV buttons and remote control (continued) PIP operations , V, v, B, b Not function for your TV. Manufactured under license from BBE Sound, Inc. Licensed by BBE Sound, Inc. under one or more of the following US patents: 5510752, 5736897.
-
Page 12: Listening To The Fm Radio
Listening to the FM Radio You are able to listen to the FM radio stations using your TV by connecting an antenna (see E). To access to FM Radio mode: Press WEGA GATE button and select “FM Radio” (see I). Press FM button on the front panel (see G). -
Page 13: Wega Gate Navigator
WEGA GATE navigator WEGA GATE is a gateway that allows you access to preset TV channels, connected external inputs, FM Radio mode and “Settings” menu. WEGA GATE External Inputs FM Radio Settings Select Confirm How to use WEGA GATE WEGA GATE External Inputs FM Radio Settings... -
Page 14: Picture Setting
“Picture” setting Press WEGA GATE and select “Settings”. Make sure the “Picture” icon ( then press “Picture Mode” “Color Temperature” “Intelligent Picture” “Signal Level Indicator” * You can adjust the setting to your personal preference in the “Picture Adjustment” and “Color Temperature”... -
Page 15: Sound Setting
“Sound” setting Press WEGA GATE and select “Settings”. Press V or v to select the “Sound” icon ( ), then press “Sound Mode” “Balance” “Intelligent Volume” “Surround” * You can adjust the setting to your personal preference in the “Sound Adjustment” option only when the “Custom”... -
Page 16: "Channel Setup" Setting
“Channel Setup” setting Press WEGA GATE and select “Settings”. Press V or v to select the “Channel Setup” icon ( ), then press “Auto Program” “Manual Program” “Program Sorting/Edit” Preset channels automatically. Manually preset desired channels and channels that cannot be preset automatically (see Presetting channels manually). - Page 17 “Channel Setup” setting (continued) “FM Radio Setup”* • If you preset a blocked program number, that program number will be unblocked automatically. • If you sort a blocked program, that program will remain blocked. Preset up to nine FM radio stations. You can manually preset each FM radio station that can be received in your area and then store the radio frequency of the desired FM radio stations.
-
Page 18: Presetting Channels Manually
“Channel Setup” setting (continued) Presetting channels manually After selecting “Manual Program”, select the program number to which you want to preset a channel. (1) Make sure “Program” is selected, then press (2) Press V or v until the program number you want to preset appears on the menu, then press Select the desired channel. - Page 19 “Setup” setting Press WEGA GATE and select “Settings”. Press V or v to select the “Setup” icon ( ), then press “Language” “Picture Rotation” “Video Label” “Color System” “Wake Up Timer Beep” “Factory Settings” • Color system is not selectable in FM Radio mode. •...
- Page 20 3-213-968-11 (1) Trinitron Color TV Инструкция по эксплуатации • Перед работой с устройством внимательно прочтайте инструкцию и сохраните её для дальнейшего использования. KV-HG21 © 2007 Sony Corporation...
- Page 21 110-240 В переменного тока, 50/60 Гц Указана на задней панели ТВ B/G, I, D/K, M PAL, PAL 60, SECAM, NTSC3.58, NTSC4.43 NICAM стерео / на двух языках B/G, I, D/K; A2 стерео / на двух языках B/G Aнглийский, Русский VHF : от E2 до E12 /UHF : от E21 до E69 / CATV : от...
- Page 22 • Внутри телевизора очень высокое напряжение. • Рабочее напряжение телевизора: 110-240 В переменного тока. • Во избежание утечки электроэнергии через антенну и другие разъёмы не подключайте кабель питания до тех пор, пока вы не выполнили все остальные подключения. • Во избежание протекания батарей и повреждения пульта дистанционного управления...
- Page 24 V v B...
- Page 25 (MONO) L (MONO)
- Page 27 Устранение неисправностей (продолжение)
- Page 28 PROG RETURN 4 PROG +/– , , , 7 WEGA GATE 8 FM 1 ? 1 4 PROG +/– 5 2 +/– qs A/B WEGA GATE...
- Page 29 Кнопки на телевизоре и пульт дистанционного управления (продолжение) qd t qf 0-9 100 300 1k 3k 8k 7 WEGA GATE qj V v B b qk RETURN 100 300 1k 3k 8k 100 300 1k 3k 8k...
- Page 30 Кнопки на телевизоре и пульт дистанционного управления (продолжение) V v B b...
- Page 31 Прослушивание радиостанций диапазона FM Для перехода в режим “FM радио”: Для выхода из режима “FM радио”: PROG PROG +/– WEGA RETURN GATE WEGA GATE Прослушивание станций, которые не были настроены предварительно Прослушивание предварительно настроенных станций V v B b...
- Page 32 Использование WEGA GATE , , , –PROG+ J K L M...
- Page 33 Настройка меню “Изображение” Настройка параметров “Нaстройка изображения” в режиме “Индивид. ” Нажимайте кнопки V или v для выбора “Контрaст” (контpaстность), “Яркость” , “Цветность” , “Оттенок” (тон) или “Pезкость” , затем нажмите кнопку Нажимайте кнопки V,v,B или b для настройки выбранного параметра, затем...
- Page 34 Настройка меню “Звук” Настройка параметров “Настройка звука” в режиме “Индивид. ” Убедитесь,что выбрана опция “Регулировка” , а затем нажмите кнопку Нажимайте кнопки B или b для выбора нужной звуковой частоты, а затем нажмите V или v для регулировки и кнопку...
- Page 35 Сохранение телеканалов вручную...
- Page 36 Настройка меню “Настройка каналов” (продолжение)
- Page 37 Настройка меню “Настройка каналов” (продолжение) Сохранение телеканалов вручную После выбора пункта “Ручная настройка программ” выберите номер программы, на которую вы хотите настроить канал. Выберите нужный канал. Если звук не нормальный, выберите соответствующую систему ТВ. Если вас не устраивает качество изображения и звука, вы можете улучшить...
- Page 38 Настройка меню “Установка”...
