Thank you for your recent purchase of the Philips physical rehabilitation treadmill, 7.0 T. Philips physical therapy and exercise solutions provide simple, reliable products that o er the most relevant feedback to caregivers and users to achieve best-in-class outcomes and empower individuals to build con dence in rebuilding and maintaining healthy lifestyles and keep in touch with their communities.
Page 3: Table Of Contents
Contents Important safety instructions Important electrical information Important operation instructions Application speci cation Operating principle Signi cant physical characteristics Signi cant performance characteristic Intended user pro le...
Page 4 Operating the 7.0 T Features Operation of your new treadmill Data transfer software instructions Using a heart rate transmitter Assembly instructions for 7.0 T Important assembly instructions Maintenance Speci cations Description of packaging symbols...
Page 5: Important Safety Instructions
Important safety instructions Attention Read all instructions in this manual before using this device. Danger To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to cleaning and/or service work. Warning • Do not modify this equipment without authorization of the manufacturer.
Page 6 There should be a minimum of at least one foot of free space at the front and three and a half feet at the rear. • Do not use any after market parts on this device, other than those recommended by Philips.
Page 7 • Do not attempt any servicing or adjustments other than those described in this manual. All else must be left to trained service personnel familiar with electro-mechanical equipment and authorized under the laws of the country in question to carry out maintenance and repair work.
Page 8: Important Electrical Information
• The treadmill is not suitable for use in an oxygen rich environment. • If not stated otherwise Philips devices are designed for operation in normal climatic surroundings (IEC 60601-1): - Temperature: + 10° ... + 36° C - Relative humidity: 30 ...
Page 9: Grounding Instructions
Grounding instructions This product must be grounded. In the unlikely event that the treadmill’s electrical system should malfunction or breakdown grounding provides a path of least resistance for electric current, reducing the risk of electric shock. This product is equipped with a cord having an equipment-grounding plug.
Page 10: Important Operation Instructions
Important operation instructions • Never use the treadmill during an electrical storm. Surges may occur in your facility power supply that could damage the treadmill’s components. • All users should have medical clearance before starting any rigorous exercise program. • Start the user at a safe exercise level. Do not allow the user to be over exerted.
Page 11: Application Speci Cation
Application speci cation Medical purpose • Patient warm up before physical therapy session. • Have the patient walk to improve ambulation and range of motion after knee/hip/ankle surgery or neurological conditions. • Allow patients to perform cardiovascular exercise. Intended patient population •...
Page 12 Intended conditions of use • Environment including hygienic requirements - General: intended for indoors use. This product is not designed for use outdoors, near a pool or spa, or in any other high humidity environment. - Conditions of visibility: Ambient luminance: standard ambient room lighting is su cient.
Page 13: Operating Principle
Operating principle The operator will start the device and use the speed and incline keys to control motors. When the speed key is pressed a signal is sent to the AC motor inverter to request a change. The inverter will then send the appropriate amount of power the AC drive motor to reach the requested speed.
Page 14: Signi Cant Performance Characteristic
Signi cant performance characteristic Please refer to “Unique uses for the 7.0 T” in operating the 7.0 T.
Page 15: Intended User Pro Le
Intended user pro le Intended operator • There is no particular restriction on age, gender, height, weight, ability and culture. • Education: University or above • Knowledge: The operator should read the user’s manual before use. • Discipline: The operator should receive training from the manufacturer before use.
Page 16: Operating The 7.0 T
Operating the 7.0 T The treadmill is intended to be used in aiding in the physical rehabilitation process for patients with orthopedic and neurological problems. Also used in sports medicine, wellness and general conditioning programs. Typical applications for this type of product are •...
Page 17 Other features of the 7.0 T • Belt speed settings start at 0.1 km/hr. • The parallel handrails are adjustable to accommodate for pediatric to large adult sizes. • Heart rate monitoring using the optional heart rate chest-strap. Heart rate measurements are not for medical use The heart rate function on this product is not a medical device and should not be relied on when accurate readings are necessary.
Page 18: Features
Features 7.0 T – Treadmill Parts and adjustments 1. Hand grips 2. Electronic console 3. Safety lanyard 4. Adjustable hand rails 5. Handrail horizontal adjustment 6. Handrail vertical adjustment 7. Handrail lift bar 8. Rear step 9. Rear incline 10. Front incline...
Page 19 The 7.0 T is an easy product to set up and use, from the adjustments to the intuitive interface. This section explains how to set up, adjust and operate your 7.0 T. Leveling the 7.0 T Once the 7.0 T is assembled, and placed on a at level oor, it may be necessary to adjust the four leveling glides on the bottom of the rear incline unit to ensure proper stability of the 7.0 T.
Page 20 Adjusting the hand rail vertical position • To lift: Turn both the left and right vertical adjustment knobs counterclockwise one or two rotations. Then just grab the lift bar and pull up. The locking pins in the knobs will automatically ratchet into the indexing holes in the tubes.
Page 21: Operation Of Your New Treadmill
Operation of your new treadmill 7.0 T electronic console Large LED matrix window Tablet friendly reading rack holder 16-character messsage center Heart rate % pro le Incline buttons Speed buttons Power on When initially powered on the console will perform an internal self-test.
Page 22: Console Operation
The odometer will remain displayed for only a few seconds then the console will go to the start up display, also known as Idle Mode. The message window will be scrolling the start up message. You may now begin to use the 7.0 T. The console will automatically power down after 30 minutes of inactivity.
Page 23 The dot matrix has 24 columns of lights and each column represents 1 minute in the Quick Start program (time per column can be modi ed in other programs). At the end of the 24th column (or 24 minutes of work) the display will wrap around and restart at the rst column again.
Page 24: Function Keys
To the left of the message window is a display key that allows you to switch the data shown. Below the message window is a heart icon and a bar graph. Wearing an optional heart rate chest belt transmitter will start the Heart Icon blinking (this may take a few seconds).
Page 25 Forward This key sets the belt direction to forward. Forward is the default direction setting when the treadmill is powered on and any time the console is in the idle mode. If the belt is already set in the reverse direction, it will change the direction of the belt to forward.
Page 26 Decline Allows operation of the rear deck motor for decline function. This key only operates in quick start or manual modes. When the function is active the grade window will show a minus (-) sign indicating the grade is set for decline. Zero Percent Returns the deck to zero percent when pressed.
Page 27: Preset Programs
Selecting and customizing programs When a program is selected you have the option of modifying the settings. If you want to begin without entering new settings just press the start key. This will bypass the programming of data and take you directly to the start of the program.
Page 28 The pro les shown in the dot matrix are merely pictures of the whole pro le and will not change in size when the speed keys are pressed. When setting up a program you will enter the maximum speed setting for the peak of the pro le.
Page 29 • Now press the start key to begin your workout. • There will be a 3 minute warm-up to begin. You can press the start button to bypass this and go straight to the workout. During the warm-up the clock will count down from 3 minutes. Facility program The facility program allows you to build and save a custom program.
Page 30 • Now you are asked to adjust the max level. This is the peak exertion level you will experience during the program. Adjust the level and then press enter. • Now the rst column will be blinking and you are asked to adjust the level for the rst segment of the workout.
Page 31 VO2 test The VO2 test is based on the Gerkin protocol, also known as the reman’s protocol, and is a sub-max VO2 (volume of oxygen) test. The test will increase speed and elevation alternately until 85% of Max heart rate is attained. The time it takes the heart rate to reach 85% determines the test score (VO2max) as shown in the chart below.
Page 32 Before the test • Make sure you are in good health; check with your physician before performing any exercise if you are over the age of 35 or persons with pre-existing health conditions. • Make sure you have warmed up and stretched before taking the test. •...
Page 33 What the score indicates: VO2max chart for males and very t females 18-25 26-35 36-45 46-55 56-65 years years years years years years Excellent >60 >56 >51 >45 >41 >37 Good 52-60 49-56 43-51 39-45 36-41 33-37 Above 47-51 43-48 39-42 35-38 32-35 29-32 average...
Page 34 Symmetry The symmetry program provides basic gait information and a feedback graph. The program will measure the left and right step length and calculates the symmetry index. The message window will display the user’s cadence, left and right step length in inches (or centimeters) and symmetry index.
Page 35 Biofeedback graph Below is a sample picture showing the symmetry graph. In the message window there is an average step cadence, left and right step length and symmetry measurements. In the example below the step length numbers shown indicate that the left leg is stepping longer than the right leg, 26 vs.
Page 36: Data Transfer Software Instructions
Data transfer software instructions • Works with newer 7.0 T, 7.0 S, 7.5 S, 7.0 R and 7.0 U consoles with USB ports on the back • The software works with Windows 10, 7 and XP series, with .Net • Framework 2.0.
Page 37 Step 2. Click "Connect" or "Change" to select the connecting port (left gure). After clicking the "Change", or connecting to the wrong port, the COM port selection window pops up (right gure). Select the correct COM port and click "Connect". Selecting COM port Pop-Up COM Port Selection Window...
Page 38 The saved data can be found at the assigned destination. Click record button Philips Data Transfer V1.0 Philips Data Transfer V1.0 Recording complete Philips Data Transfer V1.0...
Page 39 The le is saved in .CSV format, which can be opened by Microsoft Excel. Example shown below.
Page 40: Using A Heart Rate Transmitter
Using a heart rate transmitter Note: The chest strap transmitter is not a standard part, but is a separate purchase. Most transmitters that operate at 5kHz frequency will also work. How to wear your wireless chest strap transmitter? • Attach the transmitter to the elastic strap using the locking parts. •...
Page 41 • Sweat is the best conductor to measure very minute heart beat electrical signals. However, plain water can also be used to pre-wet the electrodes (2 black square areas on the reverse side of the belt and either side of transmitter). It’s also recommended that you wear the transmitter strap a few minutes before your work out.
Page 42: Heart Rate Program Operation
Erratic operation Caution! Do not use this treadmill for Heart Rate Control unless a steady, solid Actual Heart Rate value is being displayed. High, wild, random numbers being displayed indicate a problem. Areas to look at for interference, which may cause erratic heart rate •...
Page 43 • You are now asked to enter your Weight. You may adjust the Weight number using the Up and Down keys or the numeric key pad, then press enter to continue. • Next is Time. You may adjust the Time and press enter to continue. •...
Page 44: Assembly Instructions For 7.0 T
Assembly instructions for 7.0 T Hardware Step 1. #104-3/8" x 3-3/4" #58-3/8" x 2T x 4H #59-3/8" x 25 x 2T (6PCS) (6PCS) (6PCS) Step 2. #153-3/8" x 3/4" #58-3/8" x 2T x 4H #59-3/8" x 25 x 2T (6PCS) (6PCS) (6PCS) #104-3/8"...
Page 45 Step 3. #110-M5 x 10L #112-M5 x 30L (6PCS) (6PCS) Step 4. #153-3/8" x 3/4" #59-3/8" x 25 x 2T #226-3/8" x 2" (6PCS) (6PCS) (6PCS) Tools #113-Philips screw driver (1PCS) #137-5mm Allen wrench (1PCS) #259-6mm Allen wrench (1PCS)
Page 46 Assembly Read each step’s instructions and study the drawing carefully to become familiar with all the parts and procedures before beginning each step. Step 1. Upright tubes • The right side upright tube (19) has the computer cables pre-installed. Lift the tube o the walking surface and attach it to the base frame. You need to gently pull on the computer cables as you align the upright tube into the bracket on the base frame, taking the slack out so the cable does not get pinched between the tube and the base...
Page 47 Step 2. Console frame assembly • Install the two mounting brackets (3 & 4) with the six M8 x 12mm screws (108). Refer to the important instructions on the following page for this step. • Mount the console frame (5) to the upright tubes (18 & 19) with six 3/8” x 3/4”...
Page 48: Important Assembly Instructions
Important assemble instructions When assembling the console mounting brackets (Items 3&4) please be sure to slide the brackets all the way towards the back of the console frame before tightening the bolts. Push mounting bracket all the way towards the back of the console, then tighten screws.
Page 49 Step 3. Console assembly • Plug all the connectors in back of the console. • Mount the console (36) to the console frame (5) with two M5 x 30mm screws (112) in the top holes and two M5 x 10mm screws (110) in the bottom holes in the back side of the console frame.
Page 50 Step 4. Parallel bar handrail assembly • Install the eight 3/8” x 3/4” bolts (153) and 3/8” at washers (59) into the holes on the underside of the frame. Only thread them into the holes two or three turns so the slots in the handrail brackets can slide onto the bolts easily.
Page 51 Exploded view drawing...
Page 52 7.0 T parts list Item Description Main frame Incline bracket Console mast locking assembly ( l ) Console mast locking a Ssembly ( r ) Console support Running deck stabilizer assembly(a) Running deck stabilizer assembly(b) Belt guide(r) Belt guide(l) Front roller w/pulley Rear roller Running deck Running belt...
Page 53 Item Description M4 × P0.7 × 5.0t_nyloc nut M5 × P0.8 × 12m/m_phillips head screw M5 × P0.8 × 5.0t_nyloc nut M3 × 12m/m_tapping screw M5 × 12m/m_tapping screw M5 × 15m/m_sheet metal screw 3/8" × Unc16 × 3-3/4"_button head socket bolt M8 ×...
Page 54 Item Description 36-15 Console bottom cover 36-16 Console top cover(r) 36-17 Console top cover(l) Oval tube end cap 25m/m × 50m/m_square end cap Hand pulse end cap Stable wheel spacer Ø10 × Ø25 × 0.8t_nylon washer Motor cover anchor(d) Rear adjustment base (r) Rear adjustment base (l) 80m/m_handgrip foam Ground isolation cap...
Page 55 Item Description P. Bar vertical adjustment tube P. Bar bearing inner race 3/8" × Unc16 × 1-1/2" _button head socket bolt M5 × 6m/m_socket head cap bolt P. Bar horizontal adjustment arm (l) P. Bar horizontal adjustment arm (r) P.Bar horizontal adj. Cap Parallel handle bar (l) Parallel Handle bar (r) P.Bar lift assist handle...
Page 56 Item Description Step up frame pop pin M4 × P0.7 × 8m/m_phillips head screw 5/16" × Unc18 × 5/8"_hex head bolt 3/8" × Unc16 × 1-1/2" _hex head bolt 3/8" × Unc16 × 3" _he X head bolt 3/8" × Unc16 × 7.0 t _nyloc nut 3/8"...
Page 57 Item Description Eva foam for rail strap Power cord A.C. Input module 200m/M_connecting wire (white) 200m/m_connecting wire (black) A.C. Power lter 150m/m_connecting wire (white) 150m/m_connecting wire (black) Lower control board Inverter, a.C. Motor Encoder, a.C. Motor Fan, motor cooling 500m/m_motor fan connecting cable (black) 500m/m_motor fan connecting cable (white) Drive motor Front incline motor...
Page 58 Item Description Ferrite core(21.4m/m) Ferrite core(30m/m) 80m/m_connecting cable of motor Ø16 × Ø35 × 1t_ at washer 300m/m_connecting wire (white) 300m/m_connecting wire (black) Ø5.2 × 0.4t × 14.5l_constrict spring...
Page 59: Maintenance
Maintenance • Belt and deck Your treadmill uses a very high-e cient low-friction deck and belt. Performance is maximized when the bed is kept as clean as possible. Use a soft, damp cloth or paper towel to wipe the edge of the belt and the area between the belt edge and frame.
Page 60 Tighten the rear roller bolts only enough to prevent slippage at the front roller. Turn both tread-belt tension adjustment bolts with a 10mm allen wrench in increments of 1/4 to 1/2 turn each and inspect for proper tension by walking on the belt at a low speed, making sure the belt does not slip.
Page 61: Maintenance Mode
Remember, a small adjustment can make a dramatic di erence! Turn the bolt clockwise to move the belt to the right. Turn the bolt only a 1/4 turn and wait a few minutes for the belt to adjust itself. Continue to make 1/4 rotation turns until the belt stabilizes in the center of the running deck.
Page 62 • Key test - Press each key to verify it is functioning correctly • Display test - Lights all LED lights • Functions - Sleep Turns sleep mode on or o . When o , display power is always on. - Pause Turns pause mode on or o .
Page 63 - Motor brake: Brake on (brake coil turned o ) (User press enter to turn brake o ) - Step sensors Test Use sensor outputs to light DM similar to Symmetry display. This test is only to make sure the sensors are functioning and does not test accuracy.
Page 64 Factory and acceleration settings Enter the Factory settings; press Start and Speed Fast keys while console is in a.power up reset. User presses enter • Units: English - The default setting is English. User can press any up/down arrows to change to Metric. User presses enter. •...
Page 65 Error codes, messages and solution/cause E1 Over Current E8 Over Torque E14 Ext Fault Deck Lube Brake locked Reset Power Bad Drive or Motor Deck Lube E15 U Phase I Check Brake Bad Drive Bad Motor Reset Power E2 Over Volt Bad Drive E9 Over I Speed Check AC line V...
Page 66 E22 RS-485 Flt E30 CPU Error E37 LV Bus Check Wiring Electronic circuit Check AC Line V fault Bad Drive E23 PID Error Check Wiring E31 Fan E38 Ext BB Chk Para Setting Drive Fan Bad Para Settings E24 PU Comm E32 Analog In E41 Incline Err Bad Drive...
Page 67: Speci Cations
Speci cations 7.0 T Set-up dimensions Patient weight capacity Length : 94” (239 cm) with rear step. 440 Lbs. (200 Kgs.) Width : 36” (91.4 cm) Power Height : 56.5” (143.5cm) 115 Volts A.C., 20 Amps, 60 Hz. Product weight Fuse rating 514.8 Lbs.
Page 68 Certi cations TUV listed to ANSI/AAMI ES60601-1:2005+A2 (R2012) +A1, CAN/CSA-C22.2 No. 60601-1:14, CE conformity to EN 60601-1 EMC, Compliance to EN 60601-1-2 Classi cation Class I measuring, Type B, ordinary equipment, continuous operation. This product is classed as ordinary equipment according to IEC/EN/UL60601-1 and is not protected against the ingress of water.
Page 69 Guidance and manufacturer’s declaration - electromagnetic compatibility The 7.0 T is intended for use in the electromagnetic environment speci ed below. The customer or the user of the 7.0 T should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment –...
Page 70 Immunity test IEC 60601 Compliance level – Electromagnetic environment test level guidance Electrical fast +/-2 kV for power +/-2 kV for power Mains power quality should be that transient/burst supply lines supply lines of a typical commercial or hospital environment. IEC 61000-4-4 +/-1 kV for +/-1 kV for...
Page 71: Description Of Packaging Symbols
Description of packaging symbols Indicates that the package is heavy and two or more people are required to lift. Package contains fragile electronic equipment. Care should be used when handling. The product inside the packaging could be easily damaged if dropped or handled without care and attention.
Page 72 Indicates that an object is capable of being recycled - not that the object has been recycled or will be accepted in all recycling collection systems. Top. This side up.
Page 73 Product warranty Dyaco Commercial & Medical North America LLC (hereinafter “Dyaco”), the manufacturer of the Philips Professional Series Physical Therapy Products (hereinafter “Products”) warrants all of the Prod- ucts and their components listed below for the periods of time set...
Page 74 • Proper connection to a grounded power supply of su cient voltage, replacement of blown fuses, repair of loose connections or defects in house or facility wiring. • Expenses for making the tness equipment accessible for servicing, including any item that was not part of the tness equipment at the time it was shipped from the factory.
Page 75 • Manufacturer, distributor, or the Licensor shall not be responsible or liable of any direct, indirect, general, special, punitive, incidental or consequential damages; loss of or damage to property; claims of third parties; loss of life; personal injury (including further injury, or re-injury), and any other losses or damages of any kind or character, arising out of or in connection with the use of Biophysical Agents by the facilities or clinicians.
Page 76 Service Keep your bill of sale. Twenty four (24) months from the date on the bill of sale or eighteen (18) months from the date of factory shipping as determined by the serial number establishes the warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Page 77 2019© Dyaco Commercial & Medical North America LLC. All right reserved. The Philips trademark and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license. This product has been manufactured by and is sold under the responsibility of Dyaco Commercial & Medical North America LLC,...
