Patent(s) Pending
Dell 9020 SFF Wall
Mount
Installation Instructions
Kit P/N:
104-4778

Advertisement

loading

Related Manuals for Dell 9020 SFF

Summary of Contents for Dell 9020 SFF

  • Page 1 Patent(s) Pending Dell 9020 SFF Wall Mount Installation Instructions Kit P/N: 104-4778...

  • Page 2: Kit Contents

    Kit Contents Kit Contents: Mounting Hardware: (1) Main Bracket (4) Pan Head Screw (1) Cover (4) Anchors PC Wall Mount Installation Instructions Step 1 Determine Location: Select an appropriate location on the wall. Consider cable routing and length. Step 2 Mark Hole Postion: Hold the base in position and mark 4 hole positions with a pencil.
  • Page 3 Dell 9020 SFF Wall Mount Installation Instructions Step 4 Main Bracket Attachment: Secure the Main Bracket on to the wall with the supplied Pan Head Screws. Step 5 Computer and Cover Attachment: Slide the Computer into the front of the mounted Main Bracket.
  • Page 4 Warranty Statement Innovation First, Inc. warrants our products against defects in material and workmanship for a period of one (1) year from the date of purchase. Innovation First, Inc. liability shall be limited to repairing or replacing, at our option, any defective product. 4778...
