- Page 1 SANTO Combinaciones de refrigeradores y congeladores Refrigerator/Freezer Combinations Combinações frigorífico/congelador Instrucciones de servicio Operating Instructions Instruções de utilização...
- Page 2 Dear customer, Before placing your new refrigerator/freezer into operation please read these operating instructions carefully. They contain important information for safe use, for installation and for care of the appliance. Please keep these operating instructions for future reference. Pass them on to possible new owners of the appliance.
-
Page 3: Table Of Contents
Contents Safety ............35 Environmental Information . - Page 4 Contents Interior Accessories ..........49 Storage Shelves .
-
Page 5: Safety
Safety The safety of our refrigerators/freezers is in accordance with recognised technological standards and appliance safety legislation. We neverthe- less feel that it is important to acquaint you with the following safety guidelines: Use for Intended Purpose • The refrigerator/freezer is intended for household use. It is suited for the refrigeration, freezing and frozen storage of foods as well as the preparation of ice. - Page 6 Safety • Children often do not recognise the dangers involved with household appliances. Please provide for the necessary supervision and do not allow children to play with the appliance! Daily Operation • Containers with flammable gases or fluids can develop leaks through contact with the cold.
-
Page 7: Environmental Information
• Refrigerators/feezers may only be repaired by trained personnel. Repairs carried out by untrained personnel can lead to substantial danger. Please contact your dealer or our customer service depart- ment for repairs. Environmental Information Packaging All transit packaging materials are environmentally compatible and can be reused. -
Page 8: Appliance Transport
Appliance Transport Two persons are required for transport of the appliance. 0 In order to push the appliance into its final position, press carefully at the top of the upper door and tip the appliance back slightly. The weight is then transferred to the back wheels and the appliance can be easily pushed. -
Page 9: The Refrigerator/Freezer Needs Air
Installation If installation next to a source of heat is unavoidable, the following minimum clearances must be maintained at the sides of the appliance: – for electric cookers 3 cm; – for oil and coal fired ranges 30 cm. If these clearances cannot be maintained a heat insulating pad is required between the cooker and the refrigeration appliance. -
Page 10: Changing Over The Door Hinges
e.g.: AC 220 ... 230 V 50 Hz or 220 ... 230 V~50 Hz (i.e. 220 to 230 volts alternating current, 50 Hertz) The rating plate is inside the appliance at the left. Warning: To avoid potential danger, if the mains connection lead of this appliance is damaged, it must be replaced by our customer service representative or a person with similar qualifications. - Page 11 Changing Over The Door Hinges 0 Reposition upper pivot pin to the left side. 0 Carefully push refrigerator door onto upper pivot pin and close. 0 Slide the centre door bearing into the bottom left of the fridge com- partment door and fasten to the housing.
-
Page 12: Appliance Description
Appliance Description View of Appliance (various models) á Control panel and elements à Dynamic air cooling system â Butter and cheese compartment with lid ä Door storage compartments ã Bottle compartment å Fruit and vegetable drawers ç Shelves é Drawer for frozen goods (for storage and freezing) è... -
Page 13: Freezer Tray
Appliance Description Freezer tray A freezer tray is located above the upper drawer in the freezer com- partment, this tray contains one ice tray. You can pre-freeze, for example, individual berries on the freezer tray. Advantage: the berries are not squashed; they retain their original shape. -
Page 14: Buttons For Adjusting The Temperature
Appliance Description Buttons for Adjusting the Temperature The temperature is adjusted using the „+“ (WARMER) and „-“ (COLDER) buttons. These buttons are connected to the temperature display. • The temperature display is switched over from the display of the ACTUAL temperature (Temperature display is illuminated) to the dis- play of the DESIRED temperature (Temperature display flashes) by pressing one of the two buttons, „+“... -
Page 15: Prior To Initial Start-Up
Prior to Initial Start-Up Before connecting the appliance to the mains and putting it into ope- ration for the first time, leave the appliance to stand for 30 minutes if was transported upright. After transport on its side, the appliance must be left to stand for 4 hours before putting it into operation. -
Page 16: Temperature Adjustment
Temperature Adjustment With the individual buttons for temperature adjustment the desired temperatures in the refrigerator and in the freezer compartment can be adjusted independently of one another. 0 Press either the „+“ (WARMER) or „-“ (COLDER) button. The temperature display switches over and the DESIRED temperature currently set flashes on the temperature display. -
Page 17: Frostmatic
selected DESIRED temperature is again valid. The temperature display shows the ACTUAL refrigerator temperature. 0 The COOLMATIC function can be ended manually at any time by pres- sing the COOLMATIC button again. The yellow light goes out. FROSTMATIC The FROSTMATIC function provides for quick freezing of fresh food products, and at the same time protects pre- viously stored goods against undesired warming in the freezer compartment. -
Page 18: Control And Information Systems
Control and Information Systems The control and information systems consist of temperature displays, an optical warning display and an acoustic warning. The system warns: – when first switching on the appliance (when the storage temperature has not yet been attained); –... -
Page 19: Function Errors
Function Errors If the electronics in the appliance detects a technical defect that has to be rectified by the customer, the temperature display indicates: – a square in the refrigerator compartment’s temperature display indi- cates a malfunction in the refrigerator compartment, –... -
Page 20: Proper Storage
0 To start the dynamic air cooling system push the button on the fan housing. The green pilot light comes on. 0 To switch off push the button again. The green pilot light goes out. The cooling process is more efficient when the dynamic cooling system is in operation. -
Page 21: Freezing
Freezing The bottom drawer is best suited for freezing, and the two upper drawers are to be used in the storage of frozen items. Attention! • Before foods are frozen, the actual temperature in the freezer com- partment must be -18°C or colder. •... -
Page 22: Frozen Storage
• Make flat packages, because these freeze more quickly. • Do not fill plastic containers for frozen foods to the brim with liquid or paste-like goods, because liquids expand during freezing. Frozen Storage Warning! Before initial loading of the freezer compartment with pre- viously frozen goods, the required storage temperature of -18°C must be reached. -
Page 23: Defrosting
Defrosting The refrigerator is defrosted automatically The integrated evaporator on the rear wall of the refrigerator compart- ment is defrosted fully automatically. The water collects in the discharge trough at the back wall of the refrigerator, and is fed through the discharge opening in the catch tray at the compressor where it is evaporated. -
Page 24: Cleaning And Maintenance
0 Remove all the drawers. Place a bowl directly in front of the appli- ance to collect the water from defrosting and pull out the water drain conduit. Tip: In order to speed up the defrosting process, place a pot of hot water in the freezer compart- ment. -
Page 25: Energy Saving Tips
If the refrigerator only is to be cleaned, press the FROSTMATIC button several hours in advance, in order to build up sufficient chill reserve in the freezer compartment for the interruption in service. Do not open the freezer compartment door. 0 Defrost freezer compartment before cleaning (see section: "Defrosting“). -
Page 26: What To Do If
What to do if ... Correcting Malfunctions Perhaps a malfunction has been caused by a minor error, which you can correct yourself with the help of the following instructions. Do not attempt any further repairs if the following instructions do not help in each specific case. - Page 27 What to do if ... Malfunction Possible cause Remedy Temperature is not properly Please refer to the section adjusted. "Temperature Adjustment". Door was open for a long Only leave the door open time. as long as necessary. The refrigerator and/or freezer compartment tem- Within the last 24 hours a Press COOLMATIC and/or...
-
Page 28: Replace Light Bulb
Noises during Operation Replace light bulb For safety reasons the interior lighting switches off after 20 minutes when the door is open. It switches on again the next time the door is opened. Warning! Danger of electrical shock! Before replacing the light bulb switch off the appliance and remove the mains plug. -
Page 29: Regulations, Standards, Guidelines
Regulations, Standards, Guidelines This appliance was designed for household use and was manufactured in accordance with the appropriate standards. The necessary measures in accordance with appliance safety legislation regulations (GSG), acci- dent prevention regulations for refrigeration appliances (VBG 20) and the regulations of the German Society of Electrical Engineers (VDE) were observed in the manufacture of this appliance. - Page 30 USD 14 billion in more than 150 countries around the world. AEG Hausgeräte GmbH Postfach 1036 D-90327 Nürnberg http://www.aeg.hausgeraete.de © Copyright by AEG Salvo modificaciones Subject to change without notice H 214.3672.83 – 01 - 0303 Sujeito a alterações sem aviso prévio...
