1. SAFETY AND USE NOTICES ........................................... 16
2. INSTALLING THE PARTS................................................. 17
3. POSITIONING ................................................................... 20
4. WATER DRAIN.................................................................. 22
5. USE OF THE SINK ............................................................ 23
6. DESCRIPTION OF THE CONTROLS ............................... 24
7. CLEANING AND MAINTENANCE..................................... 25
INSTRUCTIONS FOR THE USER: these contain user advice, description
of the commands and the correct procedures for cleaning and maintenance
of the appliance
INSTRUCTIONS FOR THE INSTALLER: these instructions are intended
for the qualified technician who must perform the installation, put it into
operation and test the appliance
Contents
15
Advertisement
Related Manuals for Smeg ML60
Summary of Contents for Smeg ML60
-
Page 1: Table Of Contents
1. SAFETY AND USE NOTICES ... 16 2. INSTALLING THE PARTS... 17 3. POSITIONING ... 20 4. WATER DRAIN... 22 5. USE OF THE SINK ... 23 6. DESCRIPTION OF THE CONTROLS ... 24 7. CLEANING AND MAINTENANCE... 25 INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands and the correct procedures for cleaning and maintenance of the appliance INSTRUCTIONS FOR THE INSTALLER: these instructions are intended... -
Page 2: Safety And Use Notices
Instructions for safety and use 1. SAFETY AND USE NOTICES THIS MANUAL IS AN INTEGRAL PART OF THE PRODUCT. IT MUST BE KEPT INTACT AND WITHIN EASY REACH THROUGHOUT THE LIFECYCLE OF THE SINK. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INSTRUCTIONS IT CONTAINS CAREFULLY BEFORE USING THE SINK. -
Page 3: Installing The Parts
Instructions for the installer 2. INSTALLING THE PARTS Installing the tap Prepare the area where the tap is to be installed then proceed as follows: • Insert the tap (2) into the housing hole (1), making sure that the o- ring seal (4) is in place between the tap and the sink contact surface. - Page 4 Instructions for the installer Installation diagram for sink parts RECTANGULAR OVERFLOW...
- Page 5 Instructions for the installer Overflow drain • The installation provides the option of connecting the flexible tube to the overflow drain control. • Insert the end of the tube (1) into the pin (2) on the drain control (3). • Attach the plate (4) using the screws (5) as shown in the diagram.
-
Page 6: Positioning
Instructions for the installer 3. POSITIONING Built-in installation FRONT POSSIBLE HOLE FOR REAR WATER CONNECTION POSSIBLE HOLE FOR LOWER WATER CONNECTION VIEW WATER DRAIN GAP SIDE VIEW WATER CONNECTION TUBE 1/2” f POSSIBLE HOLE FOR WATER CONNECTION IF THERE IS A BACK WALL WATER DRAIN GAP... - Page 7 Instructions for the installer Installation on a trolley See the instructions provided with the trolley to install the sink like a normal barbecue. Connection to the water distribution network Connect the water intake connector on the back (A) to a water connector with a 1/2”...
-
Page 8: Water Drain
Instructions for the installer 4. WATER DRAIN The water drainage can be connected up in three different ways depending on requirements and the location of the sink. The drain can be connected: • to a tank-type container • for dispersion into the environment •... -
Page 9: Use Of The Sink
Instructions for the user 5. USE OF THE SINK General instructions and advice Before using the sink, make sure that the water distribution network connections and the sink installation have been performed correctly. Using control (1), the water flow can be adjusted by turning it to the right to increase the supply or to the left to reduce the supply. -
Page 10: Description Of The Controls
Instructions for the user 6. DESCRIPTION OF THE CONTROLS TURNING RUNNING WATER ON/OFF Enables running water to be turned on and off and the flow to be adjusted. OPENING/CLOSING THE DRAIN Enables the drain in the sink to be opened and closed. DRAIN Drains and discharges the water from the sink. -
Page 11: Cleaning And Maintenance
Instructions for the user 7. CLEANING AND MAINTENANCE Cleaning stainless steel Stainless steel needs to be cleaned regularly in order to keep it in good condition. To clean and preserve stainless steel surfaces, always use only special products which do not contain abrasive or chlorine-based acidic substances. - Page 12 Instructions for the user Inspection and cleaning of the drain If the outflow of water in the sink is not continuous, the drain needs to be cleaned (1). Place a container underneath the drain to catch the water once the drain tube has been detached (2).
