Summary of Contents for VAST Technologies DMC-2513
- Page 1 DMC-2513 HD 720P Microscope...
- Page 2 Product Dimensions Specification Operating System Supported iOS 8+ / Android 5.0+ Compatible Host Devices Mobile Phone/ Pad Image Sensor 1.0M Pixel Color CMOS Resolution HD 1280*720 Magnification 1X~80X (with 9.7" screen) (Magnification varies depending on the monitor size) Lighting 6 Adjustable LED Lights Shutter Trigger Hardware(Microscope)/ Software(APP) Communication...
- Page 3 Quick Guide to Connect Microscope with phone/pad 2. Make sure Power Indicator lighting up. (Green) 1. Turn on the device 3. Go to “Setting” of your phone/pad 4. Enter “Wi-Fi” 5. Choose “SMARP_XXXXXXX” 6. Key-in the password (Default: 12345678) 7. Make sure it is well connected and shows the tick on left.
- Page 4 Quick Guide to Operate Wi-Viewer Application Main Page A: SSID : The domain name of your microscope B: Live View Window: shows real time live image C: Library: Area to review Videos & Pictures in Wi-Viewer HD (Click anywhere on Live View Window can open/fold Library) D: Setting: Go to Setup page E: Freeze: Click: Pause &...
- Page 5 H: Go back to Live View window I: Name of video/ photo J: Trash Can Icon: Delete photo/video K: Y/N Poping Window: Click trash can icon, a Y/N window pops up and recheck if you want to delete the file. ...
-
Page 6: Fcc Warning
O: Preview Window P: Image parameter adjustments Q: Mirror: Horizontally flip image R: Flip: Vertically flip image S: About: App & Firmware version info. T: Default Setting: Reset Wi-Fi SSID/Password & Image Parameters Warning FCC WARNING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 7: Ncc Warning
NCC WARNING Administrative Rules for Low-power Radio-Frequency Devices Article 12: For those low-power radio-frequency devices that have already received a type-approval, companies, business units or users should not change its frequencies, increase its power or change its original features and functions. Article 14: The operation of the low-power radio-frequency devices is subject to the conditions that no harmful interference is caused to aviation safety and authorized radio and if interference...
