OPERATION MANUAL
MODEL
PG - C20XU
LCD PROJECTOR

Advertisement

Table of Contents
loading

Related Manuals for Sharp PG-C20X

Summary of Contents for Sharp PG-C20X

  • Page 1 OPERATION MANUAL MODEL PG - C20XU LCD PROJECTOR...

  • Page 2: Operation Manual

    2. CONSUMER PRODUCT SAFETY ACT To ensure that you will promptly receive any safety notification of inspection, modification, or recall that SHARP may be required to give under the 1972 Consumer Product Safety Act, PLEASE READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY” CLAUSE.

  • Page 3: Product Disposal

    L’INTERIEUR DU BOITIER ETANT EXTREMEMENT CHAUD, ATTENDRE 1 HEURE AVANT DE PROCEDER AU REMPLACEMENT DE LA LAMPE. NE REMPLACER QUE PAR UNE LAMPE SHARP DE TYPE BQC- PGC20X //1. RAYONS ULTRAVIOLETS : PEUVENT ENDOMMAGER LES YEUX. ETEINDRE LA LAMPE AVANT DE PROCEDER A L’ENTRETIEN.

  • Page 4: Important Safeguards

    IMPORTANT SAFEGUARDS Electrical energy can perform many useful functions. This product has been engineered and manufactured to ensure your personal safety. However IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to defeat the safeguards incorporated into this LCD Projector, observe the following basic rules for its installation, use and servicing.

  • Page 5: Outstanding Features

    Outstanding Features 1. ADVANCED COMPATIBILITY AND PCS Compatible with up to 85 Hz vertical refresh rate, Sync on Green and use with a wide variety of high-end PCs and Workstations. (Page 12) 2. 3D Y/C CIRCUITRY Provides high quality images with minimal dot crawl and cross color noise. 3.

  • Page 6: Table Of Contents

    Outstanding Features …………………………… Contents …………………………………………… Usage Guidelines ………………………………… How to Access the PDF Operation Manuals (for Windows and Macintosh) ……………… For SHARP Assistance (U.S.A. only) ………… Part Names ………………………………………… Setup & Connections Supplied Accessories …………………………… 11 Connecting the Projector ……………………… 12 Operation Basic Operations …………………………………...

  • Page 7: Usage Guidelines

    Usage Guidelines Caution Concerning the Lamp Unit Potential hazard of glass particles if lamp ruptures. Please have Authorized Sharp Industrial LCD Products Dealer or Service Center replace lamp if rupture occurs. See “Replacing the Projection Lamp” on pages 40 and 41.

  • Page 8: (For Windows And Macintosh)

    If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting” section on page 42. If this operation manual does not answer your question, please call toll free 1-888-GO-SHARP (1-888-467-4277) for further assistance. Or, send us an e-mail at lcdsupport@sharpsec.com .

  • Page 9: Part Names

    Part Names Numbers next to the part names refer to the main pages in this manual where the topic is explained. Projector Front and Top View ON/OFF button POWER indicator INPUT/BACK button KEYSTONE/Adjustment (∂ /ƒ) buttons ZOOM knob FOCUS ring Cooling fan (Exhaust vent) Foot releases Side and Rear View...

  • Page 10: Remote Control

    Part Names Remote Control Front View Mouse (∂/ƒ)/ Adjustment (∂/ƒ) buttons Mouse (ß) button MOUSE button FREEZE button MENU button INPUT button KEYSTONE buttons VOLUME buttons Inserting the Batteries Press the tab and lift open the battery cover in the direction of the arrow.

  • Page 11: Setup & Connections

    Setup & Connections E-10...

  • Page 12: Supplied Accessories

    Supplied Accessories Remote control RRMCG1613CESA Computer RGB cable QCNWG0002CEZZ Remote mouse receiver RUNTK0694CEZZ Extra air filter PFILD0123CEZZ E-11 Two AAA size batteries Computer audio cable QCNW-4870CEZZ PS/2 mouse control cable QCNW-5113CEZZ Lens cap PCOVZ1095CEKA CD-ROM LCD projector quick reference UDSKA0029CEN1 guide TINS-7205CEZZ LCD projector operation manual...

  • Page 13: Connecting The Projector

    • A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center. E-12...

  • Page 14: Connecting The Projector To Video Equipment

    Connecting the Projector Connecting other compatible computers When connecting the projector to a compatible computer other than an IBM-PC (VGA/SVGA/XGA/SXGA) or Macintosh (i.e. Workstation), a separate cable may be needed. Please contact your dealer for more information. • Connecting computers other than the recommended types may result in damage to the projector, the computer, or both. “Plug and Play”...
  • Page 15 Connecting the Projector Connecting a video source (DTV decoder or DVD player) using the 15-pin input HD-15/RCA cable (sold separately) Projector RS-232C INPUT 1 OUTPUT (INPUT 1) HD-15-RGB cable (sold separately) AUDIO COMPUTER AUDIO COMPUTER Audio cable (sold separately) Connecting an amplifier and other audio components Projector INPUT 1 OUTPUT...

  • Page 16: Connecting Rs-232C Port

    • The wireless mouse or RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for details on setting up/installing the correct mouse driver. • A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.

  • Page 17: Operation

    Operation Basic Operations Maintenance indicators ON/OFF LAMP POWER TEMP. KEYSTONE Projector Remote control ON/OFF LAMP POWER TEMP. KEYSTONE INPUT AUTO SYNC BACK ENTER MENU Maintenance indicators ON/OFF LAMP POWER TEMP. KEYSTONE 1 Make the necessary connections before pro- ceeding. Connect the power cord to a wall outlet. The POWER indicator illuminates red and the projector enters standby mode.
  • Page 18 Basic Operations Projector ON/OFF LAMP POWER TEMP. KEYSTONE AUTO SYNC INPUT BACK ENTER MENU EXAMPLE INPUT 1 (RGB) Mode INPUT 3 (VIDEO) Mode E-17 3 Slide the ZOOM knob. The image can be adjusted to the desired size within the zoom range. 4 Rotate the FOCUS ring until the image on the screen becomes clear.

  • Page 19: Setting Up The Screen

    Setting up the Screen Position the projector perpendicular to the screen with all feet flat and level to achieve an optimal image. Move the projector forward or backward if the edges of the image are distorted. • The projector lens should be centered in the middle of the screen. If the lens center is not perpendicular to the screen, the image will be distorted, making viewing difficult.

  • Page 20: Using The Adjustment Feet

    • When using a mirror, be sure to carefully position both the projector and the mirror so the light does not shine into the eyes of the audience. Ceiling-mount Setup • It is recommended that you use the optional Sharp ceiling-mount bracket for this installation. • Before mounting the projector, contact your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center to obtain the recommended ceiling-mount bracket (sold separately).

  • Page 21: Digital Keystone Correction

    Setting up the Screen Projector Remote control ON/OFF LAMP POWER 2, 3, 4 TEMP. KEYSTONE 2, 3 INPUT AUTO SYNC 1, 5 BACK ENTER MENU (GUI) On-screen Display Projector Remote control ON/OFF LAMP POWER TEMP. KEYSTONE AUTO SYNC INPUT BACK ENTER MENU Digital Keystone Correction...

  • Page 22: Operating The Wireless Mouse From The Remote Control

    Operating the You can use the remote control as a remote mouse. Connecting the Remote Mouse Receiver Connecting to the USB port on a PC or Macintosh 1 Connect one end of the supplied USB mouse control cable to the corresponding terminal on the computer. 2 Connect the other end to the USB port on the remote mouse receiver.
  • Page 23 Operating the Wireless Mouse from the Remote Control Remote Control/Mouse Receiver Positioning • The remote control can be used to control the projector within the ranges shown below. • The remote mouse receiver can be used with the remote control to control the mouse functions of a connected computer within the ranges shown below.

  • Page 24: Using The Gui (Graphical User Interface) Menu Screens

    Using the This projector has three sets of menu screens (INPUT 1 (RGB), INPUT 1 (COMPONENT) and INPUT 2 (S-VIDEO) or 3 (VIDEO)) that allow you to adjust the image and various projector settings. These menu screens can be operated from the projector or the remote control with the following buttons. Projector ON/OFF LAMP...
  • Page 25 Mode Menu Bar Main menu Picture1 Picture2 Options Language PRJ Mode Special Modes Sub menu Contrast Bright Blue Reset Color Tint Sharp Reset Signal Info Lamp Timer Keystone Auto Power Off Blue Background None Power Save Mode English Deutsch Español Nederlands Français...

  • Page 26: Main Menu

    Items on the INPUT 2 (S-VIDEO) or INPUT 3 (VIDEO) Mode Menu Bar Main menu Sub menu Picture1 Contrast Bright Blue Reset Picture2 Color Tint Sharp Reset Options Signal Info Lamp Timer Keystone Auto Power Off Background Power Save Mode Language English Deutsch Español...

  • Page 27: Selecting The On-Screen Display Language

    Selecting the On-screen Display Language Projector Remote control ON/OFF LAMP POWER 2, 3 TEMP. KEYSTONE 2, 4 INPUT AUTO SYNC 1, 5 BACK ENTER MENU (GUI) On-screen Display Selecting the Video Input System Mode (INPUT 2 or 3 mode only) Projector Remote control ON/OFF...

  • Page 28: Picture Adjustments

    Reset Color Tint Sharp • “Color”, “Tint” and “Sharp” do not appear in the INPUT 1 (RGB) mode. • “Tint” does not appear when receiving “PAL”, “SECAM”, “PAL M”, “PAL N” or “PAL (60 Hz)” in the S-VIDEO or VIDEO mode.

  • Page 29: Computer Image Adjustments (Input 1 Mode Only)

    Computer Image Adjustments (INPUT 1 mode only) Projector Remote control ON/OFF LAMP POWER TEMP. KEYSTONE INPUT AUTO SYNC BACK ENTER MENU On-screen Display Auto Sync Adjustment • Used to automatically adjust a computer image. • Auto Sync adjustment can be made manually by pressing AUTO SYNC.

  • Page 30: Adjusting The Computer Image

    Computer Image Adjustments (INPUT 1 mode only) Projector ON/OFF LAMP POWER 2, 3, 4 TEMP. KEYSTONE 2, 3 INPUT AUTO SYNC 1, 5 BACK ENTER MENU (GUI) On-screen Display E-29 Remote control Adjusting the Computer Image When displaying computer patterns which are very detailed (tiling, vertical stripes, etc.), interference may occur between the LCD pixels, causing flickering, vertical stripes, or contrast irregularities in portions of...

  • Page 31: Useful Features

    Useful Features Freeze Function Remote control 1, 2 On-screen Display This function allows you to instantly freeze a moving image. This is useful when you want to display a still image from a computer or video, giving you more time to explain the image to the audience.

  • Page 32: Digital Image Magnification

    Digital Image Remote control On-screen Display E-31 Magnification This function allows you to magnify a specific portion of an image. This is useful when you want to display a detailed portion of the image. 1 Press ENLARGE on the remote control. Each time ENLARGE is pressed, the image will be magnified.

  • Page 33: Gamma Correction

    Gamma Correction Remote control On-screen Display STANDARD GAMMA 1 GAMMA 2 • Gamma is an image quality enhancement function that offers a richer image by brightening the darker portions of the image without altering the brightness of the brighter portions. •...

  • Page 34: Selecting The Picture Display Mode

    Selecting the Picture Display Mode Remote control COMPUTER VGA, SVGA, SXGA VIDEO/DTV EXAMPLE 4:3 aspect ratio 480I/P, NTSC, PAL, SECAM Input Signal 4:3 aspect ratio 480I/P, NTSC, PAL, SECAM Letterbox Squeeze E-33 This function allows you to modify or customize the picture display mode to enhance the input image.

  • Page 35: Checking The Input Signal And The Lamp Usage Time

    Checking the Input Signal and the Lamp Usage Time Projector Remote control ON/OFF LAMP POWER TEMP. KEYSTONE INPUT AUTO SYNC BACK ENTER MENU (GUI) On-screen Display Automatic Power Shutoff Function Projector Remote control ON/OFF LAMP POWER 2, 3, 4 TEMP. KEYSTONE 2, 3 AUTO SYNC...

  • Page 36: Selecting A Background Image

    Selecting a Projector ON/OFF LAMP POWER 2, 3, 4 TEMP. KEYSTONE 2, 3 INPUT AUTO SYNC 1, 5 BACK ENTER MENU (GUI) On-screen Display Power Save Mode Function Projector ON/OFF LAMP POWER 2, 3, 4 TEMP. KEYSTONE 2, 3 INPUT AUTO SYNC 1, 5 BACK...

  • Page 37: Reverse/Invert Image Function

    Reverse/Invert Image Function Projector Remote control ON/OFF LAMP POWER 2, 3 TEMP. KEYSTONE 2, 3 AUTO SYNC INPUT 1, 4 BACK ENTER MENU (GUI) On-screen Display Special Mode Adjustment Projector Remote control ON/OFF LAMP POWER 2, 3 TEMP. KEYSTONE 2, 4 INPUT AUTO SYNC 1, 5...

  • Page 38: Maintenance & Troubleshooting

    • Have your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center exchange the filter (PFILD0123CEZZ) when it is no longer possible to clean it.
  • Page 39 Air Filter Maintenance Clean the air filter. Clean the dust off the air filter and cover with a vacuum cleaner extension hose. Replacing the air filter Disconnect the power cord. Unplug the power cord from the AC socket. Replace the air filter. 1 Put the new air filter into position.

  • Page 40: Lamp/Maintenance Indicators

    (See pages 37 and 38.) • Cooling fan breakdown. • Take the projector to your nearest Authorized • Internal circuit failure. Sharp Industrial LCD Products Dealer or Service Center for repair. • Cooling down. • Wait until the indicator stops flashing and turns off.

  • Page 41: Replacing The Projection Lamp

    Carefully change the lamp by following the steps below. If the new lamp does not light after replacement, take your projector to the nearest Authorized Sharp Industrial LCD Products Dealer or Service Center for repair. Purchase a replacement lamp unit (lamp/cage module) of the current type BQC-PGC20X//1 from your nearest Authorized Sharp Industrial LCD Products Dealer or Service Center.

  • Page 42: Resetting The Lamp Timer

    Replacing the Projection Lamp Remove the lamp cage cover. Turn over the projector and loosen the user service screw that secures the lamp cage cover. Then lift open the cover in the direction of the arrow. Insert the new lamp cage. Press the lamp cage firmly into the lamp cage compartment.

  • Page 43: Using The Kensington Lock

    Using the Kensington Lock Kensington Security Standard connector Troubleshooting Problem No picture and no sound. • Projector power cord is not plugged into the wall outlet. • The filter cover is not securely installed. • Selected input is wrong. (See page 17.) •...

  • Page 44: Appendix

    Appendix Attaching the Lens Cap Put on the lens cap to prevent damage to the lens when transporting the projector. A lens cap strap is provided to prevent the loss of the lens cap. Attach the lens cap strap to the lens cap. CAUTION •...

  • Page 45: Connection Pin Assignments

    Connection Pin Assignments COMPUTER INPUT 1 Port: 15-pin mini D-sub female connector RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable Pin No. RS-232C Terminal: 9-pin Mini DIN female connector Pin No. Computer Input Analog 1. Video input (red) 2.

  • Page 46: Rs-232C Port Specifications

    RS-232C Port Specifications PC control A computer can be used to control the projector by connecting an RS-232C cable (null modem, cross type, sold separately) to the projector. (See page 15 for connection.) Communication conditions Set the serial port settings of the computer to match that of the table. Signal format: Conforms to RS-232C standard.
  • Page 47 RS-232C Port Specifications Commands EXAMPLE • When “BRIGHT” of INPUT 1 (RGB) IMAGE ADJUSTMENT is set to Computer COMMAND PARAMETER CONTROL ITEM C2 C3 C4 P1 P2 P3 P4 SPECIAL MODE AUTO POWER OFF POWER SAVE MODE POWER SETTING INPUT SWITCHING INPUT CHECK VOLUME ADJUSTMENT...

  • Page 48: Computer Compatibility Chart

    Computer Compatibility Chart Horizontal Frequency: 15–80 kHz Vertical Frequency: 43–85 Hz Pixel Clock: 12–108 MHz Compatible with sync on green and composite sync signals SXGA (1,280 1,024) compatible in intelligent compression Horizontal Vertical MAC/ Frequency Frequency Resolution (kHz) 27.0 31.5 37.9 27.0 31.5...

  • Page 49: Specifications

    (PFILD0123CEZZ), Lens cap (PCOVZ1095CEKA), Lens cap strap (UBNDT0013CEZZ), CD-ROM (UDSKA0029CEN1), LCD projector operation manual (TINS-7204CEZZ), LCD projector quick reference guide (TINS-7205CEZZ) This SHARP projector uses LCD (Liquid Crystal Display) panels. These very sophisticated panels contain 786,432 pixels ( Film Transistors). As with any high technology electronic equipment...

  • Page 50: Dimensions

    Dimensions Side View E-49 Rear View COMPUTER AUDIO COMPUTER AUDIO (INPUT OUTPUT INPUT RS-232C 100-240V Top View MENU ENTER BACK SYNC AUTO INPUT KEYSTONE TEMP. POWER LAMP ON/OFF ZOOM FOCUS (260) (118) (58) Front View Bottom View Units: inches (mm)

  • Page 51: Glossary

    Glossary Active digital keystone correction Corrects keystone distortion caused when the projected image is not perpendicular to the screen. This method provides not only horizontal correction, but vertical as well, thus maintaining the original 4:3 aspect ratio and eliminating jag lines. Aspect ratio Width and height ratio of an image.

  • Page 52: Index

    Index Active digital keystone correction ... AC socket ... 12 Adjustment buttons ... 23 Air filter ... 37 Aspect ratio ... 33 AUDIO INPUT terminals ... 13 AUDIO INPUT 1 terminal ... 12 AUDIO OUTPUT terminal for INPUT 1 ... 14 Automatic power shutoff function ...
  • Page 53 SHARP CORPORATION...
