- Page 1 Product Manual PSH-25-PNEU Pneumatic hand wash basin...
- Page 2 Product Manual PSH-23 Revision 1...
-
Page 3: Table Of Contents
Table of Contents 1. Disclaimer .......................... 4 2. Conventions ........................4 3. Warning ..........................4 4. Note ........................... 4 5. Numbered procedures ......................4 6. Bullet lists ........................... 4 7. Menu items ......................... 5 8. Glossary ..........................5 9. Overview ..........................6 10. -
Page 4: Disclaimer
Disclaimer The specifications of Wallgate products can change without notice because of developments in design and manufacturing. Conventions Certain conventions are used in this manual to make it easier to read and understand. They are given in the sections below. -
Page 5: Menu Items
Menu items Menu items, submenu items and settings, where available, are given in bold. Glossary The glossary lists all words, abbreviations and technical terminology used in this manual, along with a short description of these terms. Term Description Anti-Ligature Recently we have become aware that there is some inconsistency in the market as to the exact meaning of "anti-ligature". -
Page 6: Overview
Overview The PSH was commissioned by The UK Home Office for use in police holding cells as an extremely safe in-cell hand wash solution. The PSH-25-PNEU is an anti- ligature, anti-vandal solid surface pneumatically controlled hand wash recessed basin. 10. Installation and Commissioning 10.1 Package Contents... -
Page 7: Mounting The Basin
10.3 Preparing & Mounting the basin Assemble the M10 threaded wall fixings to the four threaded inserts on the rear face of the basin ensuring they are fully inserted a minimum of 33mm & then tighten each stud to a torque of 6Nm. ... -
Page 8: Waste Outlet Connection
10.6 Pneumatic button installation Refer to PSH-25-PNEU drawing (Page 13) in this document for details on how to fit the pneumatic push button and air tube to the fascia and water valve. 10.7 Commissioning for Use ... -
Page 9: Technical Specifications
If so the supplier instructions for the valve should be followed as it is not a part of this Wallgate product. 10.8 Technical Specifications Table 1. Technical specifications Weight 20 Kg Dimensions 420mm (W) x 430mm (H) x 300mm (D) Water Supply Water pressure: 1 - 3 Bar (Static) recommended. - Page 10 Revision 1...
- Page 11 Revision 1...
- Page 12 Revision 1...
- Page 13 Revision 1...
-
Page 14: User And Maintenance Instructions
11. User and Maintenance Instructions The PSH-25-PNEU water dispenser has been designed & manufactured from quality materials. If these instructions are followed, the unit will give reliable efficient service. If you need any further information or advice, please contact: Wallgate Ltd, Crow Lane, Wilton, Salisbury, Wiltshire, SP2 OHB. - Page 15 Contact Wallgate to report any warranty breakdowns. Table 2 Spare Parts List Part Number Description. WV0034 Pneumatic push button. WF3095 Water nozzle. WW4004 Waste grille. BRUSH01 Waste grille cleaning brush. Revision 1...
