Specifications - Sharp AH-AP18DR Service Manual

AH/AY-AP18DR
AH/AY-AP24DR
ITEMS
Cooling capacity
Heating capacity
Moisture removal
Electrical data
Phase
Rated frequency
Rated voltage
Rated current Cool
Heat
Rated input Cool
Heat
Rated factor Cool
Heat
Compressor Type
Model
Oil charge
Refrigerant system Evaporator
Condenser
Control
Refrigerant volume (R-410A)
De-lce system
Noise level High
(at cooling) Med.
Low
Fan system
Drive
Air flow quantity High
(at cooling) Med.
Low
Fan
Connections
Refrigerant coupling
Refrigerant tube size Gas, Liquid
Drain piping mm
Others
Safety device
Air filters
Net dimensions Width
(Cartont dimensions) Height
Depth
Net weight (Gross weight)
Note: The condition of star (

SPECIFICATIONS

INDOOR UNIT
AY-AP18DR
kW 5.2
kW 5.5
Liters/h 1.6
– Single
Hz 50
V 220 – 240
A 9.2 – 9.3
A 8.2 – 8.4
kW 1.99 – 2.15
kW 1.77 – 1.93
% 98 – 96
% 98 – 96
Hermetically sealed rotary type
5KS225DAA
470cc [RB68A or Freol AlPha68M]
Louver fin and Grooved tube type
Corrgate fin and Grooved tube type
Capillary tube
1060g
Micro computer controled reverse sysetm
dB(A) 41
dB(A) 36
dB(A) 34
Direct drive
m 3 /min. 15.7
m 3 /min. 13.9
3
m /min. 11.7
Cross flow fan
Flare type
1/2", 1/4"
O.D ø 20
Compressor: Internal protector
Fan motors: Thermal protector(Internal)
Fuse, Micro computer control
Polypropylene net (Washable)
mm 1040 (1155)
mm 325 (300)
mm 220 (385)
kg 16 (21)
) marked item are 'ISO5151:1994(E), condition T1'.
OUTDOOR UNIT INDOOR UNIT
AE-A18DR AY-AP24DR
6.7
8.1
2.2
12.7 – 13.1
13.3 – 13.6
2.62 – 2.76
2.75 – 2.90
94 – 88
94 – 89
5JS315DAB
700cc [RB68A or Freol AlPha68M]
1550g
52 45
– 39
– 37
48 18.3
– 14.7
– 13.5
Propeller fan Cross flow fan
Compressor: Internal protector
890 (1020) 1040 (1155)
645 (735) 325 (300)
327 (398) 220 (385)
54 (58) 16 (21)
2
OUTDOOR UNIT
AE-A24DR
54
–
–
46
–
–
Propeller fan
890 (1020)
645 (735)
327 (398)
61 (65)
