Camco eaz lift 48475 Installation Instructions

HITCH MOUNT
CARGO CARRIER
™
Includes:
No. Description Qty.
1 Post
2 Basket
3 Cross Brace
4 Hitch Pin
5 Spring Clip
6 M8X35 Bolt
7 M8 Washer
8 M8 Lock Nut
9 M10X75 Bolt
10 M10 Washer
11 M10 Lock Nut
WARNING: READ THE FOLLOWING
INSTRUCTIONS CAREFULLY BEFORE
ATTEMPTING INSTALLATION.
Installation Instructions
• The maximum weight capacity is 500 pounds
• Do Not Exceed vehicle or hitch manufacturer's maximum tongue weight rating
• For use with Class III or better 2" hitch receiver only
• Distribute loads evenly. Do not load heavy objects toward the edges of the rack
• Do not load objects that overhang the rack's side rails
• Not for transport of people, animals, or flammable liquids
• Do not load items in close proximity to the exhaust pipe. If exhaust pipe extends toward the rack an
angled or curved exhaust tip must be used to redirect exhaust away from the cargo carrier
• Securely fasten cargo to the carrier
• Carrier should not be used if carrier is wider than the vehicle
• If carrier or cargo block license plate the license plate should be relocated to a more visible location
• Do not block rear tail lights with the carrier or cargo
CAUTION: CAMCO CANNOT BE HELD RESPONSIBLE FOR ANY DAMAGES DUE TO IMPROPER
USE OR INSTALLATION OF THIS PRODUCT. CAMCO CANNOT BE
STRUCTURAL INTEGRITY OF ANY FRAME.
1
2
2
1
1
4
4
4
4
4
4
4 5 6
7
8
WARNING
9
10
11
HELD ACCOUNTABLE FOR THE
MODEL #48475
2
3
1
Tools for Installation
• (2) 13mm wrench
• (2) 17mm wrench
• Appropriate safety protection (gloves, eye
protection, etc.)
OR
• (2) Adjustable wrenches, 0 to 30mm
NOTICE
If product components
are missing or damaged
do not return to
dealer, contact the
manufacturer.
1-800-334-2004
