- Page 1 Refrigerator User manual Free Standing Appliance Untitled-16 1 2017-06-28 12:56:13...
-
Page 2: Table Of Contents
Instructions about the WEEE Installation Refrigerator at a glance Door removal for entrance Step-by-step installation Operations User interface Samsung Connect Recommendations for voice recognition Samsung Family Hub Special features Maintenance Handle and care Cleaning Replacement English Untitled-16 2 2017-06-28 12:56:13... - Page 3 Troubleshooting General Samsung Connect Samsung Family Hub Do you hear abnormal sounds from the refrigerator? English 3 Untitled-16 3 2017-06-28 12:56:13...
-
Page 4: Safety Information
Safety information • Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. • This appliance is not intended for use by persons (including... - Page 5 • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. • Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.
-
Page 6: Important Safety Symbols And Precautions
Safety information Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. -
Page 7: Critical Installation Warnings
- This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. •... - Page 8 Safety information • Do not bend the power cord excessively or place heavy objects on • Do not pull or excessively bend the power cord. • Do not twist or tie the power cord. • Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.
- Page 9 • If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of fire. • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
-
Page 10: Installation Cautions
Safety information • Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground. - You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator. - This may result in an electric shock, fire, explosion, or problems with the product. -
Page 11: Critical Usage Warnings
• Overload on any one door may fell the refrigerator, causing physical injury. Critical usage warnings WARNING • Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock. • Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage. - Page 12 • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
- Page 13 • Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, fire, or problems with the product. • Never put fingers or other objects into the water dispenser hole, ice chute and ice maker bucket.
- Page 14 Safety information • Do not put fridge shelf in upside down. Shelf stopper could not work. - It may cause a personal injury because of glass shelf drop. • Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.
- Page 15 • If the interior or exterior LED lamp has gone out, contact your nearest service center. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards.
-
Page 16: Usage Cautions
Safety information Usage cautions CAUTION • Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury. - Page 17 - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.
- Page 18 • When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center. • Do not strike or apply excessive force to any glass surface.
-
Page 19: Cleaning Cautions
Cleaning cautions CAUTION • Do not spray water directly on the inside or outside the refrigerator. - There is a risk of fire or electric shock. • Do not use a hair dryer to dry the inside of the refrigerator. •... -
Page 20: Critical Disposal Warnings
Safety information • Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, flammable fluids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material. -
Page 21: Additional Tips For Proper Usage
• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product. • Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. -
Page 22: Saving Energy Tips
Safety information • Temperature rise during defrosting complies with ISO requirements. If you want to prevent an undue rise in the temperature of frozen food while the appliance defrosts, wrap the frozen food in several layers of newspaper. • Do not re-freeze frozen foods that have thawed completely. Saving Energy Tips •... -
Page 23: This Appliance Is Intended To Be Used In Household And Similar Applications Such As
This appliance is intended to be used in household and similar applications such as • staff kitchen areas in shops, offices and other working environments; • farm houses and by clients in hotels, motels and other residential type environments; • bed and breakfast type environments; •... -
Page 24: Installation
Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •... - Page 25 • When the door opens, the interlock switch automatically disables the auger motor of the ice maker for safety reasons. • If the internal or external LED lamp is out of order, contact a local Samsung service center. English 25...
-
Page 26: Door Removal For Entrance
Installation Door removal for entrance If the refrigerator cannot pass through the entrance due to its size, follow these instructions: Tools required (not provided) Phillips screwdriver Flat-heat screwdriver Socket spanner (10 mm) Pliers Allen spanner (4 mm) Allen spanner (5 mm) Detach the fridge doors 1. - Page 27 2. Disconnect the two connectors on the left door. The position of the connectors differs with the model. CAUTION • Do not remove both doors simultaneously. Make sure to remove one door at a time. Otherwise, any of the doors may fall and cause physical injury.
- Page 28 Installation 6. Open the door by 90 degrees. While holding the door, remove the top hinge. 7. Gently pull up the door vertically to remove. Do not apply excessive force to the door. The door may fall, causing physical injury. 8.
- Page 29 2. Then, disconnect the connectors. 3. Locate the hinge shaft. While holding the door with one hand, use a flat-head screwdriver or wrench to press down the shaft. Make sure to hold the door to prevent the door from falling. 4.
- Page 30 Installation Reattach the freezer doors CAUTION • Before reattaching the doors, make sure all the electrical connectors are properly connected. • The freezer door must be reattached before the fridge door. • Be careful not to damage or step on the wires during this process. 1.
- Page 31 4. Attach the levelling foot cover using a Phillips screwdriver. Use caution not to damage or step on the connectors. 5. Repeat the above steps for the other door. Reattach the fridge doors 1. While holding the door open by more than 90 degrees, reinsert it into the middle hinge.
- Page 32 Installation 4. Draw back the clamp as shown. 5. Connect the wire connectors. CAUTION • Make sure the wire connectors are connected properly. Otherwise, the display does not operate. 6. Connect the water tube. CAUTION • To prevent water leaks, make sure the red clips tighten the coupler properly.
-
Page 33: Step-By-Step Installation
Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •... - Page 34 Installation Clearance See the pictures and table below for space requirements for installation. Depth “A” Width “B” Height “C” 1797 Overall Height “D” 1825 (unit: mm) 01 50 mm 02 125° 03 1515 mm 04 303 mm 05 305 mm 06 908 mm 07 610 mm 08 70 mm...
- Page 35 STEP 2 Flooring • The surface to install the refrigerator must support a fully loaded refrigerator. • To protect the floor, put a large piece of cardboard on each leg of the refrigerator. • Once the refrigerator is in its final position, do not move it unless necessary to protect the floor.
- Page 36 Installation STEP 4 Adjust the door height as well as the door gap Snap ring The height of a door can be adjusted using the provided snap rings, which come in 4 different sizes (1 mm, 1.5 mm, 2 mm, and 2.5 mm).
- Page 37 To correct the door gap Door gaps can be corrected using the gap bolt on the top right corner of the refrigerator. 1. With the door closed, use a Phillips screwdriver to remove 3 screws on the top cover with the wire connectors. 2.
- Page 38 • Samsung takes no responsibility for the water line installation. If water leaks occur, contact the installer of the water line.
- Page 39 CAUTION The waterline must be repaired by a qualified professional. If you encounter a water leak, contact a local Samsung service centre or the installer of the waterline. STEP 6 Initial settings By completing the following steps, the refrigerator should be fully functioning.
-
Page 40: Operations
Operations User interface NOTE • For more information about other menus and apps available on the Refrigerator app, see the Online manual of your refrigerator. • The content of apps and widgets, or their design is subject to change or support may be discontinued without notice, depending on the content provider’s policy. - Page 41 01 Home screen 01 Apps & Widgets • Tap a desired app or widget to launch • Tap and hold an app or widget to enter Edit mode. A grid appears. In Edit mode, you can drag and drop an app or widget to a new position on the grid.
- Page 42 Operations Indicates there is a notification message. Notification ( ) Indicates Family Hub is receiving data from the cloud server. Cloud sync ( ) 02 Task bar Tap to turn on or off the voice recognition function. 01 Microphone The microphone icon turns red when it is turned off.
- Page 43 Fridge Manager To access Fridge Manager, tap the Fridge Manager widget on the Home screen. • On the Fridge Manager widget, the current fridge and freezer temperatures as well as active special functions are displayed for quick reference. • For detailed settings, tap the widget to open the Fridge Manager.
- Page 44 Operations The Fridge Manager is a graphical representation of your refrigerator. The top half represents the refrigerator compartment, the bottom left the freezer compartment, and the bottom right the Cool Select+. The temperature or mode settings for each are displayed over each section.Fridge Manager At a Glance 01 Temperature Set or change the temperatures for the...
- Page 45 NOTE Also displayed is the Ice Off (ice maker off) indicator at the top, center. When the indicator displays Ice Maker Off, the refrigerator's ice maker is turned off. Turn the ice maker on or off. Note that if the ice bucket is full of ice, the refrigerator does not start making ice at the press of this Ice Maker button (turning the Ice Maker on), but displays the Ice Making...
- Page 46 • Legal information displays the Open Source License Agreement. Tap the list item to open the Open Source Announcement. • Easy Connection can be used with Samsung Smartphone apps, and Easy allows you to connect your device to the same home Wi-Fi network Connection that your smartphone is connected to.
- Page 47 Clean Screen • Turn on so you can clean the screen without activating any apps. Mode • The online manual will walk you through various menus and apps Online Manual that the refrigerator provides directly on the display. • Tap Reset to restart the refrigerator in Factory Data Reset mode. All user data will be removed permanently.
- Page 48 Operations Display reset (applicable models only) If you encounter an abnormal symptom on the display, try resetting the display. This may solve the symptom. 1. Open the right-side fridge door and locate the switch cover on the top right corner of the door. 2.
-
Page 49: Samsung Connect
Samsung Connect Installation Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “Samsung Connect”. Download and install the Samsung Connect app provided by Samsung Electronics to your smart device. NOTE • The Samsung Connect app is designed for Android 6.0 (Marshmallow) or higher, or iOS 9.0 or higher, and is optimized for Samsung smartphones (Galaxy S and Galaxy Note... - Page 50 Operations Samsung account You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. Getting started Turn on the device you want to connect, open the Samsung Connect app on your phone, then follow the instructions below.
- Page 51 Category Item Description Displays the current temperature setting of the Fridge temperature fridge. Displays the current temperature setting of the Freezer temperature freezer. Cool Select+ Displays the settings of the Cool Select+ Monitoring (FlexZone) settings (FlexZone). Detects abnormal operations of the Diagnosis refrigerator.
-
Page 52: Recommendations For Voice Recognition
Family Hub”. Download and install the Samsung Family Hub app provided by Samsung Electronics to your smart device. NOTE • The Samsung Family Hub app is designed for Android 4.4 (KitKat) or higher, or iOS 8.0 or higher, and is optimized for Samsung smartphones (Galaxy S and Galaxy Note series). - Page 53 Samsung account You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. NOTE To connect your smartphone and the refrigerator, register your Samsung account in Settings ...
-
Page 54: Special Features
Operations Special features The refrigerator has features convenient for you. Water dispenser With the water dispenser, you can dispense water without opening the fridge door. The water dispenser offers 3 options: chilled water, cubed ice, and crushed ice. If you do not want to dispense ice, simply press water lever (B). - Page 55 CAUTION • If the ice making chime rings repeatedly, contact the waterline installer or a local Samsung service center. • Do not press the button repeatedly after the ice tray is filled with ice or water. Water may overflow or ice may jam.
- Page 56 Operations • When reinserting the ice maker tray, make sure that the tray is properly centered at the entrance. Otherwise, the tray may be stuck. Ice Maker Off To disable the icemaker, tap Fridge Manager > Fridge Settings > Ice Maker on the Home screen, and then select Off.
- Page 57 Water clouding Water supplied to the refrigerator flows through a core alkaline filter of any kind. During this filtering process, the water that has flowed through the filter increases in the water pressure and becomes saturated with oxygen and nitrogen. This causes the water to look misty or cloudy temporarily when dispensed.
- Page 58 Operations 2. Insert the freezer shelf in the position of the middle drawer. Make sure the REAR mark faces upward, which is Rear located at the rear of the shelf. CAUTION • The freezer shelf (ASSY SHELF FRE) is specifically designed to replace the middle drawer for additional storage room.
-
Page 59: Maintenance
Maintenance Handle and care Ice bucket If you do not dispense ice for an extended period, ice may form clumps inside the bucket. If this happens, remove and empty the ice bucket. 1. To remove the ice bucket, gently lift it up and pull out slowly while holding the bottom of the bucket with one hand and the side with the other hand. - Page 60 Maintenance Tempered glass shelves (fridge) • To remove a shelf, fully open the corresponding door. Hold the front of the shelf, and then gently lift up and slide out. • To reinsert, lower the rear side of the shelf and insert into the shelf hooks. Then, lower the front side to slide in to the end.
- Page 61 Door bins The top door bin section has a marked line to ensure easy removal and proper reinsertion. Lift up the door bin, and then pull out straight. CAUTION Do not allow children to play with the bins. Sharp-edged corners may cause injury. Vegetable &...
- Page 62 Maintenance 2. Slide in the right-sided foldable shelf. 3. While supporting the vegetable shelf with one hand, slide out with the other hand. NOTE Using the space that is revealed after removing the foldable shelf, take out the vegetable shelf. To reinsert, follow the steps above in the reverse order.
-
Page 63: Cleaning
Cleaning Interior and exterior WARNING • Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning purposes. They may damage the surface of the refrigerator and cause a fire. • Do not spray water onto the refrigerator. This may cause electric shock. •... -
Page 64: Replacement
• Do not use third-party water filters. Use only Samsung-provided or -approved filters. • Unapproved filters may leak and damage the refrigerator, causing electric shock. Samsung holds no responsibility for any damage that may occur from use of third- party water filters. - Page 65 3. Insert a new filter cartridge. Use only Samsung-provided or -approved filters. 4. Turn the cartridge knob clockwise to lock into place. 5. On the Home screen, tap Fridge Manager > Fridge Settings > Water Filter, and then select Reset.
- Page 66 To purchase a new water filter, contact a local Samsung service center. LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service centre. WARNING The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock.
-
Page 67: Troubleshooting
Troubleshooting If you encounter an abnormal situation with the refrigerator, first check the table below and try the suggestions. General Temperature Symptom Possible causes Solution • Power cord is not plugged • Properly plug in the power in properly. cord. •... - Page 68 Troubleshooting Odors Symptom Possible causes Solution • Clean the refrigerator and • Spoiled food. remove any spoiled food. Refrigerator has odors. • Make sure strong smelling • Food with strong odors. food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the •...
- Page 69 Water/ice (dispenser models only) Symptom Possible causes Solution • Make sure the water Water flow is weaker • Water pressure is too low. pressure is between 20 to than normal. 120 psi. • The ice maker function is Ice maker makes a activated, but the water •...
- Page 70 • Water line is not connected properly or water supply is not on. • Dispenser Lock is activated. • Deactivate Dispenser Lock. Water does not • Use only Samsung-provided dispense. or approved filters. • A third-party water filter • Unapproved filters may was installed.
-
Page 71: Samsung Connect
• The old Samsung Smart Refrigerator app cannot connect with Samsung Smart Home models. • You must log into your Samsung account to use the app. The Samsung Connect • Make sure that your router is operating normally. -
Page 72: Samsung Family Hub
Android 4.4 (KitKat) or higher, or iOS 8.0 or higher. market. • You must log into your Samsung account to use the app. Could not log into the • If you don’t have a Samsung account, follow the app’s app. -
Page 73: Lcd
Symptom Action • This refrigerator can connect only with Samsung Smart TV 6400 series or higher models released since 2015. Please Cannot connect to my check the model name of your TV first. • Network connections may suffer temporary interruptions. -
Page 74: Do You Hear Abnormal Sounds From The Refrigerator
Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal. • When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting. - Page 75 • As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling! • As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working.
- Page 76 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site AUSTRALIA 1300 362 603 www.samsung.com/au/support NEW ZEALAND 0800 726 786 www.samsung.com/nz/support DA68-03460G-01 Untitled-16 76...
