User Manual
General use pH probe: Models PHC20101, PHC20103
Safety information
Precautionary labels
Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after 12
August of 2005. In conformity with European local and national regulations (EU Directive 2002/98/EC), European
electrical equipment users must now return old or end-of-life equipment to the Producer for disposal at no charge to
the user.
Note: For return for recycling, please contact the equipment producer or supplier for instructions on how to return end-of-life
equipment, producer-supplied electrical accessories, and all auxillary items for proper disposal.
Specifications
Specifications
Probe type
pH range
pH resolution
Slope
Operating temperature range
Storage temperature range
Junction
Reference type
Sodium (alkalinity) error
Temperature accuracy
Minimum sample depth
Dimensions (standard)
Cable connection
Product overview
Read all labels and tags attached to the instrument. Personal injury or damage to the
instrument could occur if not observed.
Note: Specifications are subject to change without notice.
Details
Digital combination non-refillable, semi-liquid gel-filled probe with double
junction reference and built-in temperature sensor
pH 0 to 14
User-selectable stabilization time and resolution—Fast: 0.1, Fast: 0.01,
Medium: 0.01, Slow: 0.01 or Slow: 0.001
-59 mV/pH (85 to 115% at 25 °C (77 °F) per Nernstian theoretical value)
0 to 80 °C (32 to 176 °F)
5 to 40 °C (41 to 104 °F)
Ceramic
Ag/AgCl
<20% at pH 14 in 1 M NaCl
±0.3 °C (±0.54 °F)
15 mm (0.59 in.)
Diameter: 12 mm (0.47 in.)
Length: 103 mm (4.056 in.)
Total length: 200 mm (7.9 in.)
Cable length: 1 or 3 m (3.28 or 9.84 ft)
M12 digital output and connector compatible with HQd meters
The PHC201 series probe is a non-refillable, semi-liquid gel-filled combination pH probe
with a built-in temperature sensor
comes with a 1 or 3 m (3.28 or 9.84 ft) cable and is intended for laboratory use. The probe
provides pH measurement in general aqueous applications. The probe is not suitable for
use with organic solvents, low ionic strength, wastewater, high solids or high alkaline sample
types.
(Figure
1). The standard PHC20101 or PHC20103 probe
DOC022.52.80197
1
Advertisement
Table of Contents
Related Manuals for HACH LANGE PHC20101
Summary of Contents for HACH LANGE PHC20101
-
Page 1: Safety Information
User Manual DOC022.52.80197 General use pH probe: Models PHC20101, PHC20103 Safety information Precautionary labels Read all labels and tags attached to the instrument. Personal injury or damage to the instrument could occur if not observed. Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after 12 August of 2005. -
Page 2: Preparation For Use
Figure 1 Probe overview Probe soaker bottle Reference junction Standard probe (1 or 3 meter cable) Glass bulb and temperature sensor Soaker bottle holder Preparation for use To prepare the probe for initial use: 1. Turn the probe soaker bottle cap counter-clockwise to loosen the cap. Remove the soaker bottle from the probe. -
Page 3: Calibration Notes
Calibration notes • pH buffers can be used in any order. Use buffers that are two pH units apart. • Additional standard sets along with the minimum number of calibration points can be selected in the Calibration Options. For a two point calibration, it is recommended that two buffers be selected: one with a pH above and one with a pH below the expected sample pH. -
Page 4: Sample Measurement
Sample measurement Before measurement: The probe must have the correct service-life time stamp. Set the date and time in the meter before the probe is attached. If complete traceability is necessary, enter a sample ID and operator ID before measurement. Refer to the HQd meter manual for more information. -
Page 5: Run A Check Standard
Run a check standard The run check standard feature validates instrument performance between sample measurements. Use the run check standard feature for periodic or user-defined interval measurements of a traceable standard solution. Set the criteria for check standards from the PHC201 Settings menu. Note: Access control must be off or a valid password must be entered before any of the check standard method options can be changed. -
Page 6: Change Measurement Options
Change measurement options Methods are groups of default or user-defined settings relevant to specific applications. If the meter is set to the default method and the Modify Current Settings option is chosen, a prompt for a new name is shown after the changes are entered. The settings are saved with this name to distinguish them from the default method settings, which cannot be changed. - Page 7 4. Select Calibration Options and update the settings: Option Description Buffer Set Sets the temperature compensated buffer set used for calibration— • Color Coded—4.01, 7.00, 10.01 (default) • IUPAC—1.68, 4.01, 7.00, 10.01, 12.45 • DIN—1.09, 4.65, 9.23 • IUPAC—1.68, 4.01, 6.86, 10.01, 12.45 •...
-
Page 8: Change Check Standard Options
Table 2 Custom buffer sets Buffer set values Option Description Std1 1.09pH—25 °C Pre-set temperature compensated buffer values. Note: Selected standards must differ by a minimum of 2 pH units. For example, if 1.09pH is chosen Std2 1.68pH—25 °C for the first standard, the second standard must differ by at least 2 pH. Standards that do not meet Std3 this minimum will appear gray on the screen and will not be selectable. -
Page 9: Maintenance
5. Select Check Standard Reminder and update the settings: Option Description Reminder Repeat Sets the time interval for the check standard reminder—Off, 30 minutes, 2 h, 4 h, 8 h, 12 h or 24 h. Allow Defer Allows the postponement of check standard reminders—Yes or No. 6. -
Page 10: Troubleshooting
2. Fill the probe storage cap or soaker bottle half full with Hach Electrode Storage Solution or 3 M potassium chloride (KCl) solution. 3. Put the soaker bottle on the probe and tighten the soaker bottle cap. 4. Make sure that the solution in the storage cap or soaker bottle completely covers the glass bulb and reference junction. - Page 11 Message or symptom Possible cause Action Calibration errors Calibration not done correctly Recalibrate using freshly prepared pH buffers. Contaminated glass sensor Clean the probe (refer to Clean the probe on page 9). Slope exceeds the criteria for % of Widen the slope limits by changing the PHC201 theoretical (as defined in the method calibration settings and method.
