SERVICE MANUAL
• HCD-D11/T11 is the tuner, CD player and
preamplifier section in CMT-D11/T11.
TE
L 13942296513
Tuner section
Tuning range
US, Canadian model:
FM :87.5 – 108 MHz
AM :531 – 1,710 kHz (at 9 kHz interval)
530 – 1,710 kHz (at 10 kHz interval)
Except US, Canadian model:
FM :87.5 – 108 MHz
AM :531 – 1,602 kHz (at 9 kHz interval)
530 – 1,710 kHz (at 10 kHz interval)
Intermediate frequency
FM :10.7 MHz
AM : 450 kHz
Aerial terminals
FM :75 ohm unbalanced
AM :External aerial terminal
Timer Quarts lock system
Timer setting
One-minute step
Sleep timer 10-minute step, max. 90 minutes
CD player section
System Compact disc digital audio system
Laser Semiconductor laser
Wavelength 780 – 790 nm
Frequency response
2 Hz – 20 kHz ± 0.5 dB
Signal to noise ratio
More than 90 dB
www
Harmonic distortion
Less than 0.03%
.
MICROFILM
http://www.xiaoyu163.com
HCD-D11/T11
x ao u163
y
i
http://www.xiaoyu163.com
2 9
8
Photo: HCD-T11
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Pick-up Name
Q Q
3 6 7 1 3 1 5
SPECIFICATIONS
Preamplifier section
Frequency response
15 Hz – 50 kHz dB
Inputs PC/MD IN (US, Canadian model) :
MD IN (Except US, Canadian model) :
Stereo phone jack, sensitivity 450 mV, impedance 47 kilohms
Outputs DIGITAL OUT (CD OPTICAL OUT) jack:
Digital connector, –18 dBm, wavelength 660 nm
OUTPUT jack:
Stereo phones jack, 1 V, 1 kohm
PC/MD OUT jack (US, Canadian model):
MD OUT jack (Except US, Canadian model):
Stereo phone jack, 250 mV, 1 kohm
PHONES (headphones) jack:
Stereo mini jack, accepts headphones of 8 ohms or more.
General
Power requirents
US, Canadian model
120 V AC, 60 Hz
Except US, Canadian model
120 V or 220 – 240 V AC, adjustable, 50/60 Hz
Power consumption
25 W (HCD-T11)
20 W (HCD-D11)
co
.
9 4 2 8
US Model
Canadian Model
Tourist Model
E Model
HCD-D11/T11
CDM13C-5BD19
BU-5BD19
KSS-213B/K-N
0 5 8 2 9 9 4 2 8
+0
–3
– Continued on next page –
m
TUNER CD PLAYER
9 9
HCD-T11
