Wansview K2 Quick Installation Manual

703GC(K2)快速安装指南-英文版
折后尺寸：85*138mm
材质：128g双铜
双面四色印刷，过哑胶
Contents
1 Installation guide
1 Camera , 1 power adapter
Mounting accessories
Photosensor
Lens
Infrared LED
Mic
Speaker
WPS 720P X Series Wifi IP Camera(K2)
Status LED/
Wi-Fi LED
DID:VIEW-227361-CEWEE
Reset
Power Interface
OFF: The device is not powered
LAMBENT: The device is powering
Red
SLOW: No network connection
(Status LED)
STEADY: Connect Wi-Fi successfully
QUICK: Start to upgrade/Reset successfully
OFF: The device is powered 5 minutes but not connect Wi-Fi yet
SLOW: Not connect Wi-Fi
Blue
(WiFi LED)
QUICK: The device is connecting Wi-Fi now
STEADY: The device has connected Wi-Fi already
Step 4
View Live video and Edit Camera
Once your camera is online, you can view live video and enter to
the Edit Camera page to do more settings according to the below
picture.
Tap here to view
Tap to enter
Live Video.
Edit Camera page
Resolution
·
Always remember to change your password, tap the > and
then access to Edit Camera Page, get into Advanced Setting
then User Settings, change password and click √
to save.
Easy Set Up
Download
Step 1
·
Go to the App Store or Google Play to search and
download " Wansview " APP to your supported device .
wansview App icon
·Or scan the QR code below to get the app.
Step 2 Power on camera
Power for the camera with the included power supply and place
it near your router(within 3 feet).
Power adapter
FAQ:
1. If the night vision stops working, please turn on the IR light
as below:
Tap this icon to turn night vision on
Tap this icon to turn night vision off
2. If you forgot the password, hold the "Reset" button around
15 seconds, then the camera will be back to factory default.
Default User/password: admin/123456. Remember to
configure WiFi again after the Reset.
Reset
注：机器图为首页
Step 3
Connect to network
Add camera onto the App
Verify your smart device(iOS or Android) is connected with a 2.4G
WiFi network
Launch the Wansview app, Click to access Add Camera page
and select "Add cameras via WiFi Configuration Guide"
Wansview Add camera
①
Camera's DID
tap"+"to add camera
Username
Password
Name
LAN search
Add Cameras via WiFi configuration guide
WiFi configuration to add cameras
②
·
Scan the QR code on the back of the camera, and name the camera.
(
Then "Next" keep "admin" as login name and "123456" as the default
password )
Connecting camera Add camera
Named camera
④
Camera's DID VIEW-511723-JYVTU
Username admin
Password
QR Code
1.The Default username and password is admin/
123456
2.The maximum length of password is 20characters
⑤
③
LET US KNOW
WHAT YOU THINK
Thank you so much for your order and trust to Wansview.
Please feel free to contact us if you have any questions about
the product application.
As a young and growing company, it would mean the
world to us if you could leave an honest review about
our product and services.
US:service@wansview.com
service2@wansview.com
UK:service3@wansview.com
US:service2@wansview.com
UK:service3@wansview.com
Facebook: www.facebook.com/WansviewClub/
Youtube: https://www.youtube.com/channel/
UCPRXQcIkLsMAWQtpGxVx_jw
The instruction is for reference only. Slight differences may
be found in the user interface.All the designs and software
here are subject to change without prior written notice.
For latest instructions, please go to www.wansview.com to
download.
www.wansview.com
封底
· Input correct WiFi password and "Next", then the camera
will try to connect, if connected, "Add success" appears,
and it will go back to the Camera page, and shows "online".
If it fails to connect, please tap "try again" and repeat the
process for 2-4 times.
The whole process should be finished within 5 minutes of
powering on.Otherwise, the camera should be unplugged
and powered back.
Tips
Wi-Fi name and Password should not contain special
*
characters 'and &.
Your smart device (mobile phone) must be within 3 feet
*
from the camera during configuration.
WiFi network information WiFi configuration Wansview
K2
WiFi name amazon.com2.4
VIEW-511723-JYVTU
WiFi Password
⑥
1.Make sure the phone connected with 2.4GHz wif
2.Please configure WiFi within 5 minutes after powering
it up
3.The maximum length of WiFi password is 31
characters
⑦
Note: When the camera shows "online", you can move it to
other place that has a good wifi receiption.
720P HD Wireless IP Camera K2
