Page 1
The technical data sheet specifies the AMY-6M ROM-based GPS module featuring the u-blox 6 positioning engine. The AMY-6M boasts the industry’s smallest form factor and is a fully tested standalone solution that requires no additional components and no host integration.
Page 2
AMY-6M - Data Sheet Document Information Title AMY-6M Subtitle u-blox 6 GPS Module Document type Data Sheet Document number UBX-13004381 Document revision Document status Production Information Document status information Objective This document contains target values. Revised and supplementary data will be published Specification later.
1 Functional description 1.1 Overview The AMY-6M is the world’s smallest standalone GPS module dedicated to consumer applications. It has been specifically developed to provide basic GPS functionality required by high-volume, portable products. It is a fully integrated autonomous GPS solution requiring no host integration resulting in fast time-to-market.
Operational Limits Altitude 50,000 m Velocity 500 m/s Table 2: AMY-6M GPS performance All satellites at -130 dBm Dependent on aiding data connection speed and latency Demonstrated with a good active antenna CEP, 50%, 24 hours static, -130 dBm 50% @ 30 m/s Assuming Airborne <4g platform...
Supply of aiding information like ephemeris, almanac, rough last position and time and satellite status and an optional time synchronization signal will reduce time to first fix significantly and improve the acquisition sensitivity. The AMY-6M module supports the u-blox AssistNow Online and AssistNow Offline-GPS services , and is OMA SUPL ready.
1.9.2 USB AMY-6M provides a USB version 2.0 FS (Full Speed, 12Mbit/s) interface as an alternative to the UART. The pull- up resistor on USB_DP is integrated to signal a full-speed device to the host. The VDD_USB pin supplies the USB ®...
Protocol Specification [2] and the u-blox 6 Power Management Application Note [3]. 1.11.1 Operating modes AMY-6M modules only operate in Eco mode, this mode optimizes the use of the acquisition engine to deliver lower current consumption. Power Save Mode is not supported with AMY-6M.
1.12.1 Configuration Pins The AMY-6M provides 2 configuration pins (CFG_xxx) for boot-time configuration. These become effective immediately after start-up. Once the module has started, the configuration settings may be modified with UBX configuration messages. The modified settings remain effective until power-down or reset. If these settings have been stored in battery-backup RAM, then the modified configuration will be retained, as long as the backup battery supply is not interrupted.
AMY-6M - Data Sheet 2 Pin Definition 2.1 Pin assignment Figure 2: Pin Assignment Name Description RF_IN RF Input Ground Ground XTAL_OUT RTC Output XTAL_IN RTC Input VDD_LNA LNA Power Supply VDD_ANA Analog Power VDD_RF Core Power Ground Ground Reserved...
Page 13
VDD_C Core Power DCDC_EN DC/DC Control Output Table 7: Pinout Pins designated Reserved should not be used. For more information about Pinouts see the AMY-6M Hardware Integration Manual [1]. UBX-13004381 - R07 Production Information Pin Definition Page 13 of 28...
Table 8: Absolute maximum ratings GPS receivers are Electrostatic Sensitive Devices (ESD) and require special precautions when handling. For more information see the AMY-6M Hardware Integration Manual [1]. Stressing the device beyond the “Absolute Maximum Ratings” may cause permanent damage.
AMY-6M - Data Sheet 3.2 Operating Conditions The test conditions specified in Table 9 apply to all characteristics defined in this section. Symbol Parameter Min. Typ. Max. Unit Tamb Ambient Temperature °C VDD_IO Supply Voltage I/O ring VDD_USB Supply Voltage USB...
AMY-6M - Data Sheet Symbol Parameter Condition Min. Typ. Max. Unit Ileak Leakage current input pins Low level input voltage VDD_USB >= 3.0 V High level input voltage VDD_USB >= 3.0 V VDD_USB Low level output voltage = 1.425 kΩ to VDD_USB, VDD_USB >= 3.0 V, 22 Ω...
FW version used, external circuitry, number of SVs tracked, signal strength, type of start as well as time, duration and conditions of test. For more information about power requirements, see the AMY-6M Hardware Integration Manual [1]. 3.4 SPI timing diagrams In order to avoid a faulty usage of the SPI, the user needs to comply with certain timing conditions.
AMY-6M - Data Sheet 3.4.1 Timing recommendations Parameter Description Recommendation Initialization Time 500 µs INIT Deselect Time 1 ms Bitrate 100 kbit/s Table 19: SPI timing recommendations The values in the above table result from the requirement of an error-free transmission. By allowing just a few errors, the byte rate could be increased considerably.
AMY-6M - Data Sheet 4 Mechanical specifications 4.1 AMY-6M-0-001 For information regarding Paste Mask and Footprint see the AMY-6M Hardware Integration Manual [1]. UBX-13004381 - R07 Production Information Mechanical specifications Page 19 of 28...
AMY-6M - Data Sheet 4.1 AMY-6M-0-002 For information regarding Paste Mask and Footprint see the AMY-6M Hardware Integration Manual [1]. UBX-13004381 - R07 Production Information Mechanical specifications Page 20 of 28...
AMY-6M - Data Sheet 5 Design-in and migration considerations For important information for conducting a proper design-in as well as considerations for migration, u-blox strongly recommends consulting the AMY-6M Hardware Integration Manual [1]. 6 Reliability tests and approvals 6.1 Reliability tests Qualification tests for AMY-6M conducted according to standards JESD47.
Information Guide [4]. Figure 4: Reeled AMY-6M modules 7.1.1 Reels AMY-6M modules are deliverable in quantities of 2000pcs on a reel. AMY-6M modules are delivered using reel Type A as described in the u-blox Package Information Guide [4]. Parameter Specification...
AMY-6M - Data Sheet 7.1.2 Tapes Figure 5 shows the position and orientation of AMY-6M modules as they are delivered on tape. The orientation of the modules and dimensions of the tapes are specified in Figure 5 and Figure 6.
AMY-6 modules are Moisture Sensitive Devices (MSD) in accordance to the IPC/JEDEC specification. AMY-6M modules are rated at MSL level 3. For more information regarding moisture sensitivity levels, labeling, storage and drying see the u-blox Package Information Guide [4]. For MSL standard see IPC/JEDEC J-STD-020, which can be downloaded from www.jedec.org.
AMY-6M - Data Sheet 8 Default settings Interface Settings Serial Port 1 Output 9600 Baud, 8 bits, no parity bit, 1 stop bit Configured to transmit both NMEA and UBX protocols, but only following NMEA and no UBX messages have been activated at start-up:...
The labeling of u-blox 6 GPS modules includes important product information. The location of the product type number is shown in Figure 7. Figure 7: Location of product type number on AMY-6M packages 9.2 Explanation of codes 3 different product code formats are used. The Product Name is used in documentation such as this data sheet and identifies all u-blox 6 products, independent of packaging and quality grade.
AMY-6M - Data Sheet Related documents AMY-6M Hardware Integration Manual, Docu. No GPS.G6-HW-10037 u-blox 6 Receiver Description including Protocol Specification, Docu. No GPS.G6-SW-10018 u-blox 6 Power Management Application Note, Docu. No GPS.G6-X-10014 u-blox Package Information Guide, Docu. No GPS-X-11004 Firmware 7.03 Release Note, Docu. No GPS.G6-SW-11013 All these documents are available on our homepage (http://www.u-blox.com).
