Content 1. Introduction ......................4 2. Principle of Operation of MDR-NC500D and Its Configuration ......5 2.1. Feedback Type and Feedforward Type ................6 2.2. System configuration of MDR-NC500D ............... 7 2.3. Advantages of Digitization .................... 8 3. AI Noise Canceling Function ................9 3.1.
MDR-NC500D is the Digital Noise Canceling Headphones, which Sony developed as the first of their kind in the world. For this development, Sony put in all of its acoustical analysis technology, digital signal processing technology and transducer technology. By digitizing the noise canceling function, we succeeded in improving the performance in...
Principle of Operation of MDR-NC500D and Its Configuration The noise canceling headphones make a canceling signal by analyzing with their noise canceling circuit the surrounding noise collected by the small noise detection microphone built in their main body. With this canceling signal superimposed on the regenerative signal from the connected equipment, reproduction from the driver unit reduces surrounding noise and makes it possible to listen to music more clearly.
Type Feedback type The noise canceling function of the “feedback type” is used in MDR-NC500D. In the feedback type, the noise detection microphone is placed close to the ear. By collecting noise in the position closer to the ear, a noise canceling effect with high accuracy can be obtained.
Better Average individual difference / fitting difference Miniaturization Less suitable More suitable 2.2. System configuration of MDR-NC500D The Internal Block Diagram of MDR-NC500D is shown below: Headphone amplifier Digital converter equalizer converter Audio In Driver unit DNC software...
(NC filter) between the microphone to detect noise and the driver unit to reproduce the canceling signal. In MDR-NC500D, the filter circuit for noise canceling is realized on the DSP as the digital signal processing of the newly developed “DNC software engine.”...
On the other hand, in the environment such as an office, the noise energy is small but distributed over a wider range. In MDR-NC500D, the filter circuit to control a noise canceling ratio was digitized and it is controlled by software.
By integrating the noise detection microphone with the driver unit to minimize the time delay, MDR-NC500D achieved a stable and wider range canceling performance. Moreover, the use of re-informed diaphragm significantly improved the canceling performance against environmental noise with a high sound pressure that is generated in a very low frequency.
5. High-Quality Sound Unique to Digital MDR-NC500D digitized the NC circuit and used the digital equalizer in the playback system. The acoustical system of noise canceling headphones is generally based on the design, which emphasizes low frequency in order to maximize the effect with limited electric power.
6.Weight saving mechanism Magnesium and 7075 aluminum are used as the material for the housing and the headband, respectively. By using these unstintingly, the mass is reduced to as small as 195 g or more than 10 % weight reduction. * * In comparison with MDR-NC60.
7.Other Features 7.1. Monitor function MDR-NC500D is equipped with the monitor function to make the surrounding sound more audible by muting music etc. during reproduction when you are spoken to, for example. While wearing the headphones, you can hear an announcement etc. in an airplane or in a train only by pressing the button.
Appendix: Indication of Canceling Performance for Noise Canceling Headphones 1.1. Total Noise Suppression Ratio Total Noise Suppression Ratio (TNSR) of noise canceling headphones is expressed with the following formula: TNSR = 10 log (P / P • P = Energy of sound observed at the ear not wearing headphones •...
Page 15
NC MODE A 20.0 18.0 17.1 NC MODE B 17.0 20.3 18.3 NC MODE C 14.9 15.0 18.9 • Based on Sony's one noise source simulations. • Note: Noise canceling ratio (Sony’s conventional method) more than 25 dB (at MODE A)
Page 42
附录:降噪耳机降噪性能指标 1.1. 总噪音抑制率 降噪耳机的总降噪抑制率(TNSR)用以下公式表示: TNSR = 10 log (P / P = 未戴耳机在耳朵旁的声音能量。 • P • P = 戴着耳机在耳朵旁的声音能量。 * 以上声音能量测量为加权值。 TNSR 是采用普通频谱噪音信号的测量值。 与测量某一频率点降噪率的方法相比较,TNSR 能使实际使用环境中的降噪性能的 测定更客观。 此外,此方式通过使用模仿飞机和火车上真实现场的频谱分布,能计算出每种噪音 环境中的降噪性能。...
Page 43
[符号举例] TNSR: 20 dB 频率 总噪音抑制率(典型值) 单位:dB 飞机 火车/公共汽车 办公室 NC MODE A 20.0 18.0 17.1 NC MODE B 17.0 20.3 18.3 NC MODE C 14.9 15.0 18.9 • 基于 Sony 单噪音源模拟。 • 注意:降噪率(Sony 传统方法)大于 25 dB( MODE A 时)...
Page 45
목차 1. 소개 ..........................4 2. MDR-NC500D의 작동 원리 및 구성 ................5 2.1. 피드백 타입 및 피드포워드 타입 ..................6 2.2. MDR-NC500D의 시스템 구성 ....................7 2.3. 디지털의 이점 ......................... 8 3. AI 노이즈 제거 기능 ....................9 3.1. AI 노이즈 제거 기능의 작동 ....................10 4.
1. 소개 MDR-NC500D는 Sony가 동종 제품으로는 세계 최초로 개발한 디지털 노이즈 제거 헤드 폰입니다. 본 제품에는 Sony의 음향 분석 기술, 디지털 신호 처리 기술 및 변환기 기술이 총 망라되 어 있습니다. 노이즈 제거 기능을 디지털화함으로써 기존의 아날로그 신호 처리 방식으로 해결하기...
MDR-NC500D 의 작동 원리 및 구성 노이즈 제거 헤드폰은 헤드폰 본체에 내장된 소형 노이즈 감지 마이크로 수집된 주변 노 이즈를 노이즈 제거 회로에서 분석하여 제거 신호를 만듭니다. 연결된 기기에서 재생성되는 신호에 이러한 제거 신호를 중첩시킴으로써 드라이버 장치에 서 재생된 사운드에서 주변 노이즈가 줄어들게 되므로 좀더 깨끗한 음악을 들을 수 있습니다.
2.1. 피드백 타입 및 피드포워드 타입 피드백 타입 MDR-NC500D에는 "피드백 타입"의 노이즈 제거 기능이 사용됩니다. 피드백 타입은 귀 부근에 노이즈 감지 마이크가 있습니다. 귀 부근에서 노이즈를 수집하므로 정밀한 노이즈 제거 효과를 얻을 수 있습니다. 노이즈 감지 마이크에서 수집된 노이즈의 오디오 신호가 노이즈 제거 회로(NC 회로)에...
마이크 앰프 노이즈 제거 헤드폰 MDR-NC500D의 내부 계통도 MDR-NC500D의 노이즈 감지 마이크에서 귓가의 노이즈를 수집합니다. 노이즈 신호는 마이크 앰프 및 고속 A/D 컨버터를 통과하면서 디지털 화되고 DSP(Digital Signal Processor)로 입력됩니다. 그런 다음 DSP 내부의 DNC 소프트웨어 엔진이 원래 노이즈를 반전시킨 제거 신호를 생성합니다.
노이즈 제거 헤드폰의 성능은 노이즈를 감지하는 마이크와 제거 신호를 재생하는 드라 이버 장치 사이의 필터 회로(NC 필터)에 의해 크게 좌우됩니다. MDR-NC500D의 DSP에는 노이즈 제거용 필터 회로가 새로 개발된 "DNC 소프트웨어 엔 진"의 디지털 신호 처리로 구현되어 있습니다. 디지털 신호 처리는 정확한 계산 결과 같은 일반적인 이점 이외에, 심각한 변동이나 전기...
반면, 사무실 같은 환경에서는 노이즈 에너지는 작지만 더 넓은 범위에 분산됩니다. MDR-NC500D에서는 노이즈 제거 비율을 제어하는 필터 회로가 디지털화되어 소프트웨 어로 제어됩니다. 따라서 MDR-NC500D는 사용자 환경에 가장 적합한 필터 특성(노이즈 제거 모드)을 자 동으로 선택하는 AI 노이즈 제거 기능으로 필터 특성을 전환할 수 있습니다. AI 노이즈 제거 기능...
3. 선택한 모드로 노이즈 제거 작업이 시작됩니다. * 분석 도중 정확한 노이즈 정보를 얻기 위해 음악 소스 재생 및 노이즈 제거 기능이 일시적으로 중지됩니다. MDR-NC500D에서는 3초 정도의 짧은 시간에 위의 처리 과 정이 완료됩니다. AI 노이즈 제거(AINC)의 분석 알고리즘에는 노이즈가 귀에...
MDR-NC500D에 탑재된 디지털 이퀄라이저는 음질에 미치는 영향을 차단하고 드라이버 장치 고유의 성능을 최대화하여 고음질의 사운드를 제공합니다. Sony는 그 동안 AV 앰프와 Hi-Fi 시청각 기기를 통해 축적된 디지털 이퀄라이징 기술을 아낌없이 활용함으로써 새로 개발된 계산 방식을 시스템에 최적화하여 깊은 저음에서 부드...
재생 등을 하지 않고 노이즈 제거 기능을 사용하는 경우 코드를 분리하면 편안하게 사용할 수 있습니다. 또한 배터리 케이스 일체형 연결 코드를 전원으로 사용할 수 있습니다. MDR-NC500D는 충전식 내장 리튬 이온 배터리를 사용하면 더 오랫동안 사용할 수 있습 니다. 7.4. 전원 공급...
부록 : 노이즈 제거 헤드폰용 제거 성능 지표 1.1. 총 노이즈 억제 비율 노이즈 제거 헤드폰의 총 노이즈 억제 비율(TNSR)은 다음과 같은 공식으로 표현됩니다: TNSR = 10 log (P / P = 헤드폰을 착용하지 않고 귀에서 측정한 사운드 에너지 • P •...
Page 57
단위: dB 비행기 기차/버스 사무실 NC MODE A 20.0 18.0 17.1 NC MODE B 17.0 20.3 18.3 NC MODE C 14.9 15.0 18.9 • Sony의 노이즈 소스 시뮬레이션에 근거함. • 주의: 노이즈 제거 비율(Sony의 기존 방식) 25 dB 이상(MODE A에서)
