- Page 1 Usermanual HDMI 2.0 to DisplayPort 1.2a Converter 1x2 Partilink Technology Co., Ltd Copyright @2018...
- Page 2 Release Notes: Date Version Release Notes 2018/3/5 V1.0 Production www.partilink.com...
-
Page 3: Table Of Contents
Table of Contents 1. Introduction ............2 2. Features ............3 3. Application ............4 4. Specifications ........... 5 5. Product Information ......... 6 6. Installation ............6 7. Package Content ..........7... -
Page 4: Introduction
1. Introduction P4K2-H1D2 is a HDMI 2.0 to DisplayPort 1.2a converter that provides one HDMI input and two DisplayPort outputs. P4K2-H1D2 supports resolution up to 4Kx2K@60 4:4:4 color sampling. It allows you to connect an HDMI 4K60 4:4:4 enabled video source, such as Blu-ray™ player, PS4, Xbox One X or computer, to a DisplayPort 1.2... -
Page 5: Features
2. Features ● DisplayPort 1.2a & HDMI 2.0 compliant ● HDMI input supports video bandwidth up to 18Gbps. ● The EDID automatically sends the complete video feedback to media player and provides with high- resolution video quality ● Supports HDCP 1.4 / 2.2 ●... -
Page 6: Application
3. Application ● Connects a variety of HDMI 2.0 sources to DisplayPort 1.2 display. ● HDMI 2.0 to 2-port DP 1.2a splitter ● Converts HDMI 2.0 to DP 1.2a input devices as a source of AV 4K@60Hz DP AV Device 4K@60Hz HDMI Source 4K@60Hz DP Display... -
Page 7: Specifications
4. Specifications MODEL NO. P4K2-H1D2 DESCRIPTION HDMI 2.0 to DisplayPort 1.2a Converter 1x2 1 x HDMI Type A female INPUT Resolution 3840 x 2160/ 4096 x 2160 @60Hz YUV INTERFACE 4:4:4 2 x DisplayPort female OUTPUT Resolution 3840 x 2160/ 4096 x 2160 @60Hz YUV... -
Page 8: Product Information
DisplayPort Output 2 ports 6. Installation ● Connect the HDMI cable to the HDMI Input port of P4K2-H1D2 converter and connect the DisplayPort cables from your displays to DisplayPort output ports of P4K2-H1D2 ● Connect the power adapter to DC jack; then the other end to an AC outlet ●... -
Page 9: Package Content
2. DC 12V LED Indicator: When the red light is on, it means the power is on 7. Package Content P4K2-H1D2 1 HDMI to 2 DisplayPort converter X 1 DC12V power adaptor X 1 User manual X 1 Warranty The warranty starts from the date of product delivery and will cover a one-year period of time.
