Panasonic NR-B26M8 Service Manual

Service Manual
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or
repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer's specifi ed parts to prevent shock, fi re or other hazards. Do not modify the original design without permission of
manufacturer.
NR-B26M8-30M8-34M8..indd 1 NR-B26M8-30M8-34M8..indd 1
CFCs have been used in refrigerant as refrigerator and the insulation materials for many
years. But it is now known that these compounds which once seemed so ideal for use as
cleaning agents and in refrigeration systems, destroy the earth's ozone layer as a result, an
international body decided on a total worldwide ban of harmful CFCs by the end of 1995.
WARNING
IMPORTANT SAFETY NOTICE
Order No. PHAT090201C3
NR-B26M8
NR-B30M8
NR-B34M8
Product Color
Silver (SL),
Destination
India
© 2009 Panasonic Home Appliances (Thailand) Co.,Ltd
All rights reserved. Unauthorized copying and distribution
is a violation of law
Refrigerator
