Blu-ray Disc Player
Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
©
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without
the prior permission of Philips.
Published by Helen 1134 BG LE Printed in The Netherlands Subject to modification
Version 1.3
Version 0.0
BDP2600

TABLE OF CONTENTS

Location of PCB Boards..................................................1-1
Technical Speci cations ....................................................... 1-2
Safety Instruction, Warning & Notes .....................................1-3
Mechanical and Dismantling Instructions ................................ 2
Software Version & Upgrades.................................... ............. 3
Trouble Shooting Chart ........................................................... 4
Block Diagram .........................................................................5
Electrical Diagrams and PCB layouts ...................................... 6
Set Mechanical Exploded view & Parts List ............................ 7
Revision List ............................................................................ 8
/12/94/51/55/93/05/98/F8&
Page
BDP2610
/93
CLASS 1
LASER PRODUCT
314178536533
GB

Advertisement

Table of Contents
loading

Related Manuals for Philips BDP2600/12

Summary of Contents for Philips BDP2600/12

  • Page 1 Revision List ................8 CLASS 1 LASER PRODUCT Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands © All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2 LOCATION OF PCBS: MAIN BD LOADER PF BD FRONT CABINET VERSION VARIATIONS Type / Versions BDP2600 BDP2610 Service Police Board in used /12 /51 /94 /55 /93 /05 /98 MAIN BOARD M C/M C/M C/M C/M C C/M PF BOARD C/M C/M LOADER FRONT CABINET...

  • Page 3: Specifications

    Specifications Note Region code This player can play discs with the following region codes. Blu-ray Countries Russia, India Playable media BD-Video DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer) VCD/SVCD DivX (Ultra)/DivX Plus HD media, MKV media USB storage device File format Video: .avi, .divx, .mp4, .mkv Audio: .mp3, .wav Video...
  • Page 4 Specifications Note Region code This player can play discs with the following region codes. Blu-ray Countries Russia, India Compatibility: Hi-Speed USB (2.0) Class support: USB Mass Storage Class (UMS) File system: FAT16, FAT32 Support HDD (a portable hard drive disc): an external power source may be needed. Main unit Power supply rating: AC 110-240V, 50/60 Hz Power consumption: 14 W...
  • Page 5 Make sure that, • Use only lead-free soldering tin Philips SAC305 with order during repair, you are connected with the same potential as code 0622 149 00106. If lead-free solder paste is required, the mass of the set by a wristband with resistance.
  • Page 6 1 - 5 Safety Instructions, Warnings, Notes, and Abbreviation List 2.3.5 Alternative BOM identification Abbreviation List It should be noted that on the European Service website, 0/6/12 SCART switch control signal on A/V “Alternative BOM” is referred to as “Design variant”. board.
  • Page 7 Electro Magnetic Interference LORE LOcal REgression approximation EPLD Erasable Programmable Logic Device noise reduction Europe LG.Philips LCD (supplier) EXTernal (source), entering the set by Loudspeaker SCART or by cinches (jacks) LVDS Low Voltage Differential Signalling Fast BLanking: DC signal Mbps...
  • Page 8 4.406250 MHz and 4.250000 MHz Sound Intermediate Frequency SMPS Switched Mode Power Supply System on Chip Sync On Green SOPS Self Oscillating Power Supply S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board STBY STand-BY SVGA 800x600 (4:3)
  • Page 9 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step1: Remove 6 screws around the Top Cover, and then remove the Top Cover (Figure 1). XP11 XP12 Figure 1 Step2: If it is necessary to dismantle Loader or Front Panel, the Front door should be removed first.
  • Page 10 Mechanical and Dismantling Instructions Detailed information please refer to the model set. Dismantling Instruction Step3: If the tray can¡¯t open in normal way, you can make it through the instruction as below (Figure 3). Note: Make sure to operate gently otherwise the guider would be damaged. Figure 3 Step4: Dismantling Front Panel, need release 2 snaps of Front Panel and 2 snaps of bottom cabinet , then gently pull the Panel out from the set.
  • Page 11 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. Step5: Dismantling Loader, disconnect the 4 connectors (XP7, XP11, XP12,J13)(Figure 1) aiming in the below figure, and remove 2 screws that connects the loader and the bottom cabinet. (Figure 5) Figure 5 Step6: Dismantling Main Board , remove 4 screws.
  • Page 12 4) Disconnect the power cord for a few seconds and connect again to turn on the player. C) Update software via USB Flash Drive: 1) Go to www.philips.com/support to check if the latest software version is available for this player. 2) Download the software onto a USB flash drive.
  • Page 13 Trouble shooting chart Can not lighten LED Can not lighten LED Check if there is any Fix the open-circuit or short-circuit open-circuit short-circuit DuPont pin and PCB Check whether R47/R48/R36/R37/R40/R Fix the bad component 41/Q6/Q7/LED1 is normal Check if VCC and VCC_D is normal (VCC is always 5V and Q209/R297/R298R299/R300/Q210 VCC_D is 5V when ON and 0...
  • Page 14 Trouble shooting chart Keys do not work Keys do not work Check if there is any open-circuit Fix the open-circuit or short-circuit short-circuit DuPont pin and PCB Check if K1/K2 is normal Fix K1/K2 Check if every voltage on Fix the PSU or main board the PSU and main board is normal Replace the main PCBA or PSU PCBA...
  • Page 15 Trouble shooting chart Remote control does not work Remote control does not work Check whether the remote Replace the batteries of remote control works well control, or fix the remote control. Check there open-circuit or short-circuit Fix the open-circuit or short-circuit on the DuPont pin and PCB Check component...
  • Page 16 Trouble shooting chart Can’t read disc or can’t open the disc door Can’t read disc or can’t open the disc door Check if +12V and Fix the PSU/main board/DuPont pin +12V_D is normal Check if every cable of loader and cable socket is Fix the bad cable or socket well Check...
  • Page 17 Trouble shooting chart No video or audio No video or audio Configuration does not Change the settings of player or sink to match between player fix this issue and sink Check if every voltage Fix the PSU or main board on the PSU and main board is normal Check...
  • Page 18 Trouble shooting chart Can not connect to network Can not connect to network Check weather Connect twisted pair twisted pair Internet connect to Internet Check if the LAN socket Fix or replace P1 and U12 (P1) and U12 is broken Check if the soldering and Fix the abnormal components...
  • Page 19 BDP2600/12 /51/55/94/93/F8/05 /98& BDP2610/93 Block Diagram 85mm NETWORK HDMI SPDIF (for WIFI) PORT TRANSFORMER MOTOR DRIVER (R2A30209SP) MOTOR DRIVER NAND FLASH (AM2158) (128MB/256MB) LOADER MT8551 A CH DDR3 TBL200plus & IM 220 RESET (128MB/256MB) RF SIGNAL MT8560 and OTHER 45PIN FFC...
  • Page 20 PF Board Circuit Diagram: L501 L501 680uH/300mA 680uH/300mA 470pF/250VAC 470pF/250VAC CY503 CY503 Alternative C501 C501 2200pF/1KV 2200pF/1KV D503 D503 D501 D501 R505A R505A R505B R505B R505C R505C R505D R505D 150K 150K 150K 150K 150K 150K 150K 150K 470pF/250VAC 470pF/250VAC CY504 CY504 R514 R514...
  • Page 21 Main Board Circuit Diagram:POWER SOURCE 1.2V 0.1uF/16V/Y5V 0.1uF/16V/Y5V Close to DC-DC 10uF/10V/Y5V 10uF/10V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 2K/1% 2K/1% 2.2uH/3A 2.2uH/3A C327 C327 1.2V_FB 22uF/6.3V/Y5V 22uF/6.3V/Y5V 22uF/6.3V/Y5V 22uF/6.3V/Y5V 5.6K/1% 5.6K/1% C324 C324 C326 C326 0.1uF/16V/Y5V 0.1uF/16V/Y5V 1.2V_FB 0.1uF/16V/Y5V 0.1uF/16V/Y5V PGND C325 C325 0.1uF/16V/Y5V 0.1uF/16V/Y5V AT1526...
  • Page 22 Main Board Circuit Diagram:MT8551/60 DDR-A Part 1.5V 1.5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 4.7uF/10V/Y5V 4.7uF/10V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V RDQ2 RDQ10 DDRVCCIO RDQ0 RDQ6 RDQ12 DDRVCCIO RDQ0 RDQ1 RDQ3 RDQ7 DDRVCCIO RDQ1 RDQ2 RDQ4 RDQ2 DDRVCCIO RDQ2 1.5V RDQ3 RDQ0 DDRVCCIO RDQ3 RDQ4 RDQ7...
  • Page 23 Main Board Circuit Diagram:MT8551/60 DDR-B Part 1.2V 1.2V 1.2V DVCC12_K DVCC12_K AC12 RDQ0_B RDQ3_B RA0_B DVCC12_K RDQ0_B 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 22uF/6.3V/Y5V 22uF/6.3V/Y5V AC13 RDQ1_B RDQ7_B RA1_B DVCC12_K RDQ1_B AD13 RDQ2_B RDQ2_B RA2_B DVCC12_K RDQ2_B...
  • Page 24 Main Board Circuit Diagram:MT8551/60-AV/PLL Differential Signal ! No Through Hole ! AVDD33_VDAC 3.3V AVDD33_VDAC 100 ohm - Impedance RN100 RN100 AOLRCK AOSDATA0_R F_TX2+ AOSDATA0 TP30 TP30 0.1uF/16V/Y5V 0.1uF/16V/Y5V AOSDATA1_R CH2_P TP32 TP32 AVSS33_VDAC AOSDATA1 AOSDATA2_R CH2_M F_TX2- AOSDATA2 TP31 TP31 AOSDATA3_R CH1_P F_TX1+...
  • Page 25 Main Board Circuit Diagram:MT8551/60-Flash 3.3V 3.3V 3.3V AVDD33_USB 4.7K 4.7K NC/10K NC/10K NC/10K NC/10K NC/10K NC/10K NC/10K NC/10K NC/10K NC/10K DVCC33_IO AVDD33_USB 3.3V DVCC33_IO DVCC33_IO C103 C103 C104 C104 NFD7 DVCC33_IO AMUTE I/O7 1uF/16V/Y5V 1uF/16V/Y5V 10uF/10V/Y5V 10uF/10V/Y5V NFCEN NFD6 DVCC33_IO AVSS33_USB I/O6 NFWEN...
  • Page 26 Main Board Circuit Diagram:MT8551/60-Part4 8PIN/1.0mm 8PIN/1.0mm VOUTD3 VOUTD4 VOUTD5 3.3V_STBY VOUTD6 GPIO0 DVCC33_IO_STB GPIO0 3.3V DVCC33_IO_STB GPIO1 VOUTD3 DVCC33_IO_STB GPIO1 VOUTD3 VOUTD4 VOUTD4 C123 C123 VOUTD5 VOUTD5 UARXD VOUTD6 UARXD VOUTD6 0.1uF/16V/Y5V 0.1uF/16V/Y5V UATXD UATXD VSTB VSTB 3.3V_STBY AVDD33_LDO VDATA AVDD33_LDO VDATA VCLK...
  • Page 27 Main Board Circuit Diagram:MT8551/60-FE A1.2V A3.3V FE RS232 Port NC15 NC15 1.2V 3.3V NC18 NC18 3.3V VDAC0 VDAC0 VDAC0 NC14 NC14 VWDC3O VWDC3O1 VWDC3O1 VWDC2O VWDC2O1 VWDC2O1 C181 C181 C176 C176 URXD TRINC TRINC1 TRINC1 10uF/10V/Y5V 10uF/10V/Y5V 10uF/10V/Y5V 10uF/10V/Y5V UTXD C142 C142 TRIND...
  • Page 28 Main Board Circuit Diagram:Motor Driver REIC_TR+ REIC_TR+ REIC_TR- REIC_TR- REIC_FO+ REIC_FO+ REIC_FO- REIC_FO- REIC_TL+ REIC_TL+ REIC_TL- REIC_TL- MVCC_R VCC_D REIC_CO_B- REIC_CO_B- put FB19 nearby Motor Driver REIC_CO_B+ REIC_CO_B+ REIC_CO_A+ REIC_CO_A+ FB19 FB19 10/2A 10/2A REIC_CO_A- Motor Driver REIC_CO_A- REIC_FMO4 REIC_FMO4 REIC_FMO3 Sensorless REIC_FMO3...
  • Page 29 6-10 6-10 PF Board Print Lay-out(Bottom Side):...
  • Page 30 6-11 6-11 Main Board Print Lay-out(Top Side):...
  • Page 31 6-12 6-12 Main Board Print Lay-out(Bottom Side):...
  • Page 32 Exploded View for BDP2600/94:...
  • Page 33 Exploded View for BDP2600/12/51/55/93/F8/05/98&BDP2610/93:...
  • Page 34 REVISION LIST Version 1.0 * Initial release for BDP2600/12/94/51/55 Version 1.1 * Initial release for BDP2600/93 Version 1.2 * Initial release for BDP2600/05/98 Version 1.3 & BDP2610/93 * Initial release for BDP2600/F...
