Service Manual

32PFL1507/F8
In this service manual, there are some models which consist of two Power Supply CBAs.
The main Power Supply CBA and the sub Power Supply CBA are compatible with each other
for a board level repair but they are not compatible with each other for a component level
repair.
When you conduct on a component level repair for the Power Supply CBA for any models
within this service manual, make sure to refer the right Block Diagrams, Schematic
Diagrams/CBA and Parts List.
For the main CBA, the last digit of the board number, which is engraved on every board,
should be a number(e.g. BA17F1F0102 4).
For the sub CBA, the last digit of the board number, which is engraved on every board,
should be an alphabet(e.g. BA17F1F0102 Y).
© 2012 Funai Electric Co., Ltd.
This service manual contains information of different types of models.
Make sure to refer to the section describing your model.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the content
herein without the obligation to notify any person or organization of such changes.
with the
without the express written consent of Funai. All other trademarks used herein remain the exclusive property of
their respective owners. Nothing contained in this manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any
other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights
to the fullest extent of the law.
PHILIPS
(Serial No.: DS1)
design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way
chassis PL11.10
Contents
32" LCD TV
120821

Advertisement

Table of Contents
loading

Summary of Contents for Philips 32PFL1507/F8

  • Page 1: Service Manual

    32” LCD TV chassis PL11.10 Service Manual Contents 32PFL1507/F8 PHILIPS (Serial No.: DS1) In this service manual, there are some models which consist of two Power Supply CBAs. The main Power Supply CBA and the sub Power Supply CBA are compatible with each other for a board level repair but they are not compatible with each other for a component level repair.
  • Page 2: Important Safety Notice

    IMPORTANT SAFETY NOTICE Proper service and repair is important to the safe, reliable operation of all P&F Equipment. The service procedures recommended by P&F and described in this service manual are effective methods of performing service operations. Some of these service special tools should be used when and as recommended.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Specifications ................1-1 Important Safety Precautions .
  • Page 4: Specifications

    SPECIFICATIONS < TUNER / NTSC > ANT. Input ---------------------- 75 Ω Unbal., F type Description Condition Unit Nominal Limit 1. AFT Pull-In Range ±2.3 ±2.1 TV.ch.4 dBμ 2. Synchronizing Sens. CA.ch.31 dBμ CA.ch.87 dBμ < TUNER / ATSC > Description Condition Unit Nominal...
  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Prior to shipment from the factory, our products are strictly inspected for recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
  • Page 6 3. Design Alteration Warning - Do not alter or add 7. Product Safety Notice - Some electrical and to the mechanical or electrical design of this TV mechanical parts have special safety-related receiver. Design alterations and additions, characteristics which are often not evident from including, but not limited to circuit modifications visual inspection, nor can the protection they give and the addition of items such as auxiliary audio...
  • Page 7 Precautions during Servicing A. Parts identified by the # symbol are critical for safety. Replace only with part number specified. B. In addition to safety, other parts and assemblies are specified for conformance with regulations applying to spurious radiation. These must also be replaced only with specified replacements.
  • Page 8 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been returned to original positions. Afterwards, perform the following tests and confirm the specified values in order to verify compliance with safety standards. 1.
  • Page 9: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING Circuit Board Indications How to Remove / Install Flat Pack-IC 1. The output pin of the 3 pin Regulator ICs is 1. Removal indicated as shown. With Hot-Air Flat Pack-IC Desoldering Machine: Top View Bottom View 1.
  • Page 10 3. The flat pack-IC on the CBA is affixed with glue, so With Soldering Iron: be careful not to break or damage the foil of each 1. Using desoldering braid, remove the solder from pin or the solder lands under the IC when all pins of the flat pack-IC.
  • Page 11 With Iron Wire: 2. Installation 1. Using desoldering braid, remove the solder from 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder the foil of each pin of the flat pack-IC on the CBA flux which is applied to all pins of the flat pack-IC, so you can install a replacement flat pack-IC more you can remove it easily.
  • Page 12 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.
  • Page 13: Cabinet Disassembly Instructions

    CABINET DISASSEMBLY INSTRUCTIONS 1. Disassembly Flowchart Step/ Fig. Loc. Part Removal Note This flowchart indicates the disassembly steps for the cabinet parts and the CBA in order to gain access to Front items to be serviced. When reassembling, follow the [10] D2 --------------- Cabinet...
  • Page 14 (L-1) (S-2) (L-1) (S-2) (S-3) (L-1) (L-1) (S-3) [2] Rear Cabinet (S-2) (S-4) (S-2) [1] Stand Assembly (S-1) Fig. D1 PL11.10-A_DC...
  • Page 15 [10] Front Cabinet [9] Function [7] LCD Module CBA Unit Assembly [3] Digital Main Function Knob CBA Unit Jack Holder Sensor Lens [8] IR Sensor [5] Stand Bracket (S-5) CBA Unit (S-7) Speaker (S-8) (S-6) Holder (S-8) Speaker Holder [6] Speaker (S-6) [4] Power Supply CBA (S-6)
  • Page 16 TV Cable Wiring Diagram To LCD Module Assembly Power Supply CBA CN200 To LCD Module Assembly CN1102 Digital Main CBA Unit CN3005 CN632 CN3701 CN1101 CN3102 CN3101 CN3801 CN3802 CN1100 CN601 To Speaker To AC Cord IR Sensor CBA Unit CN4052 Function CBA Unit CN4001...
  • Page 17: Electrical Adjustment Instructions

    ELECTRICAL ADJUSTMENT INSTRUCTIONS How to set up the service mode: General Note: “CBA” is abbreviation for “Circuit Board Assembly.” Service mode: Note: Electrical adjustments are required after 1. Turn the power on. replacing circuit components and certain mechanical parts. It is important to perform 2.
  • Page 18 1. Purity Check Mode 2. VCOM Adjustment This mode cycles through full-screen displays of red, Test Point Adj. Point green, blue, and white to check for non-active pixels. [CHANNEL UP/DOWN] Screen 1. Enter the service mode. buttons 2. Each time the [7] button on the remote control unit M.
  • Page 19: White Balance Adjustment

    The White Balance Adjustment should be 6. Press [MENU] button. The internal Raster signal appears in the screen. (“Internal (Single)” appears performed when replacing the LCD Panel in the upper right of the screen as shown below.) or Digital Main CBA. 3.
  • Page 20: How To Initialize The Lcd Tv

    HOW TO INITIALIZE THE LCD TV The purpose of initialization is to place the set in a new out of box condition. The customer will be prompted to select a language and program channels after the set has been initialized. To put the program back at the factory-default, initialize the LCD TV using the following procedure.
  • Page 21: Firmware Renewal Mode

    FIRMWARE RENEWAL MODE Equipment Required 4. The update will start and the following will appear in the screen. a. USB storage device " * " differs depending on the models. b. Remote Control Unit Software Upgrade Software upgrade in progress. Please wait. Firmware Update Procedure Do not remove the USB storage device or turn the TV off while upgrade is in progress.
  • Page 22: Troubleshooting

    TROUBLESHOOTING [Power Supply Section] FLOW CHART NO.1 The power cannot be turned on. Is the fuse (F601) normal? See FLOW CHART No.2 <The fuse blows out.> Check if there is any leak or short-circuiting on the primary circuit component, and service it if defective. (D600, D601, D602, D603, Q600, Q601, T600) Is the P-ON+24V line voltage normal? FLOW CHART NO.2...
  • Page 23 FLOW CHART NO.5 P-ON+24V is not output. Check C648A, D637, D644, D646, D648 and their periphery circuit, and service it if defective. FLOW CHART NO.6 LCD+24.5V is not output. FLOW CHART NO.7 PANEL+15.8V is not output. FLOW CHART NO.8 AMP+24V is not output. PL11.10ATR...
  • Page 24 FLOW CHART NO.9 AL+5V is not output. Replace Q636. FLOW CHART NO.10 P-ON+3.3V is not output. FLOW CHART NO.11 LCD-6V is not output. Replace Q213. PL11.10ATR...
  • Page 25 [Video Signal Section] FLOW CHART NO.1 The key operation is not functioning. Replace the Function CBA Unit. Replace Digital Main CBA Unit. FLOW CHART NO.2 No operation is possible from the remote control unit. Check AL+3.3V line and service it if defective. Replace the IR Sensor CBA Unit or the remote control unit.
  • Page 26 [Audio Signal Section] FLOW CHART NO.1 Audio is not outputted normally. See FLOW CHART NO.9 <AL+5V is not output. [Power Supply Section]> See FLOW CHART NO.8 <AMP+24V is not output. [Power Supply Section]> See FLOW CHART NO.5 <P-ON+24V is not output. [Power Supply Section]>...
  • Page 27: Block Diagrams

    BLOCK DIAGRAMS 1. System Control Block Diagram PL11.10BLS...
  • Page 28 2. Video/Audio Block Diagram PL11.10BLV...
  • Page 29 3. Digital Signal Process Block Diagram PL11.10BLD...
  • Page 30 4. Inverter Block Diagram (main Power Supply CBA) PL11.10BLINV...
  • Page 31 4. Inverter Block Diagram (sub Power Supply CBA) PL11.10BLINV2...
  • Page 32 5. Power Supply Block Diagram PL11.10BLP...
  • Page 33: Schematic Diagrams / Cba And Test Points

    SCHEMATIC DIAGRAMS / CBA AND TEST POINTS Standard Notes WARNING Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
  • Page 34 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE_A,_V FUSE. ATTENTION: UTILISER UN FUSIBLE DE RECHANGE DE MÊME TYPE DE_A,_V. 2.
  • Page 35 Power Supply 1 Schematic Diagram CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. NOTE: CAUTION ! : For continued protection against risk of fire, If Main Fuse (F601) is blown , check to see that all components in the power supply The voltage for parts in hot circuit is measured using replace only with same type 4 A, 125V fuse.
  • Page 36 Power Supply 2 Schematic Diagram POWER SUPPLY CBA CONTINUE POWER 1 PANEL+15.8V P-ON+3.3V LCD-6V LCD+24.5V CONTINUE D201A POWER 1 OPEN PROTECT3 D201 1SS133 VCOM-PWM R225 P-ON-H1 P-ON-H1-1 C200 C212 R209A R209 R217 OPEN C211 15.7 1000P Q202 KTC3875S-Y-RTK/P (V-COM DRIVE) R210 R207 OPEN...
  • Page 37 Power Supply 3 Schematic Diagram (main Power Supply CBA) When you conduct on a component level repair for the Power Supply CBA for any models within this service manual, make sure to refer the right Block Diagram/Schematic Diagram/CBA and Parts List. For the main CBA, the last digit of the board number, which is engraved on every board, should be a number (e.g.
  • Page 38 Power Supply 3 Schematic Diagram (sub Power Supply CBA) When you conduct on a component level repair for the Power Supply CBA for any models within this service manual, make sure to refer the right Block Diagram/Schematic Diagram/CBA and Parts List. For the main CBA, the last digit of the board number, which is engraved on every board, should be a number (e.g.
  • Page 39 Function Schematic Diagram (NO CONNECTION) CN4002 KEY-IN1 TO DIGITAL MAIN CBA UNIT CN3101 CN4001 KEY-IN1 R4007 R4005 R4004 R4003 R4002 R4001 2.2K 2.2K 2.7K 4.7K 8.2K C4004 C4002 D4001 OPEN EDZTE615.6B SW4006 SW4007 SW4005 SW4004 SW4003 SW4002 SW4001 D4002 OPEN POWER CH UP MENU...
  • Page 40 IR Sensor Schematic Diagram C4054 R4051 R4052 R4061 6.8K OPEN R4062 TO DIGITAL MAIN CN4052 CBA UNIT CN3102 R4054 1 GND 2 REMOTE C4055 3 AL+3.3V RS4051 OPEN GP1USC32XP 4 P-ON+5V (REMOTE SENSOR) 5 LED1 R4055 R4059 IC4051 OPEN OPEN 6 KEY-IN1 OPEN D4051...
  • Page 41 Digital Main 1 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3005. IC3005 is divided into six and shown as IC3005 (1/6) ~ IC3005 (6/6) in this Digital Main Schematic Diagram Section. CONTINUE DIGITAL 4 VCOM-PWM...
  • Page 42 Digital Main 2 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3005. IC3005 is divided into six and shown as IC3005 (1/6) ~ IC3005 (6/6) in this Digital Main Schematic Diagram Section. DIGITAL MAIN CBA UNIT TU3401 TUNER UNIT IC3013...
  • Page 43 Digital Main 3 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3005. IC3005 is divided into six and shown as IC3005 (1/6) ~ IC3005 (6/6) in this Digital Main Schematic Diagram Section. C3009 IC3005(3/6) R8A05011BG-U0...
  • Page 44 Digital Main 4 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3005. IC3005 is divided into six and shown as IC3005 (1/6) ~ IC3005 (6/6) in this Digital Main Schematic Diagram Section. DIGITAL MAIN CBA UNIT CONTINUE DIGITAL 3...
  • Page 45 Digital Main 5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3005. IC3005 is divided into six and shown as IC3005 (1/6) ~ IC3005 (6/6) in this Digital Main Schematic Diagram Section. AUDIO SIGNAL DIGITAL MAIN CBA UNIT R3183...
  • Page 46 Digital Main 6 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3005. IC3005 is divided into six and shown as IC3005 (1/6) ~ IC3005 (6/6) in this Digital Main Schematic Diagram Section. VIDEO SIGNAL AUDIO SIGNAL CONTINUE...
  • Page 47 Power Supply CBA Top View (main Power Supply CBA) Because a hot chassis ground is present in the power supply CAUTION ! circuit, an isolation transformer must be used when repairing. Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. Also, in order to have the ability to increase the input slowly, CAUTION ! : For continued protection against risk of fire,...
  • Page 48 Power Supply CBA Bottom View (main Power Supply CBA) Because a hot chassis ground is present in the power supply CAUTION ! circuit, an isolation transformer must be used when repairing. CAUTION ! : For continued protection against risk of fire, Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
  • Page 49 Power Supply CBA Top View (sub Power Supply CBA) Because a hot chassis ground is present in the power supply CAUTION ! circuit, an isolation transformer must be used when repairing. Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. CAUTION ! : For continued protection against risk of fire, Also, in order to have the ability to increase the input slowly,...
  • Page 50 Power Supply CBA Bottom View (sub Power Supply CBA) Because a hot chassis ground is present in the power supply CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. circuit, an isolation transformer must be used when repairing. CAUTION ! : For continued protection against risk of fire, Also, in order to have the ability to increase the input slowly,...
  • Page 51: Waveforms

    WAVEFORMS WF1 ~ WF4 = Waveforms to be observed at Waveform check points. (Shown in Schematic Diagram.) Input: Component Color Bar Signal (480i, 480p, 720p or 1080i) (with 1kHz Audio Signal) JK3701(Y-IN) VIDEO-Y 0.2V 20µs JK3701(Pb-IN) VIDEO-Pb 0.2V 20µs JK3701(Pr-IN) VIDEO-Pr 0.2V 20µs...
  • Page 52: Wiring Diagram

    WIRING DIAGRAM 12-1 PL11.10WI...
  • Page 53: Exploded Views

    EXPLODED VIEWS CL3005 Function CBA Unit CL3101 CL200 Digital Main CBA Unit CL3102 IR Sensor CBA Unit CL3801 LCD1 SP3801 CL3802 SP3802 Power Supply CBA See Electrical Parts List for parts with this mark. AC600 SSK1 13-1 PL11.10-A_CEX...
  • Page 54 Packing SSK1 Tape Stand Assembly Packing Tape Packing Tape Tape Some Ref. Numbers are not in sequence. 13-2 PL11.10_PEX...
  • Page 55: Parts List

    PARTS LIST [32PFL1507/F8 (Serial No.: DS1)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a Ref. No. Description Part No. # have special characteristics important to safety. OWNERS MANUAL A1AFRZH 1EMN30161 Before replacing any of these components, read REMOTE CONTROL TRANSMITTER YKF259-...
  • Page 56: Electrical Parts

    Electrical Parts PRODUCT SAFETY NOTE: Products marked with a POWER SUPPLY CBA (main CBA) # have special characteristics important to safety. Ref. No. Description Part No. Before replacing any of these components, read POWER SUPPLY CBA (main CBA) A17F7MPW-001 carefully the product safety notice in this service Consists of the following: manual.
  • Page 57 Ref. No. Description Part No. Ref. No. Description Part No. C1107 CHIP CERAMIC CAP . CH J 330pF/50V CHD1JJ3CH331 D207A SWITCHING DIODE 1SS400 TE61 QD1Z001SS400 C1108 CAP CERAMIC HV 10pF/6.3kV/SL/J CCC1000MR007 D208A SWITCHING DIODE 1SS400 TE61 QD1Z001SS400 C1109 CHIP CERAMIC CAP . CH J 330pF/50V CHD1JJ3CH331 D210A ZENER DIODE SMD TFZGTR5.1B...
  • Page 58 Ref. No. Description Part No. Ref. No. Description Part No. RES CHIP 1608 1/10W F 10.0k Ω D1507 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U R215 RTW1002HH008 RES CHIP 1608 1/10W F 1.50k Ω D1508 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U R216 RTW1501HH008 RES CHIP 1608 1/10W F 10.0k Ω...
  • Page 59 Ref. No. Description Part No. Ref. No. Description Part No. METAL OXIDE FILM RES. 1W J 68k Ω RES CHIP 1608 1/10W J 33k Ω R613 RN01683ZU001 R1207 RRXA333HH013 RES CHIP 1608 1/10W J 15k Ω RES CHIP 1608 1/10W J 22k Ω R631 RRXA153HH013 R1208...
  • Page 60 Ref. No. Description Part No. Ref. No. Description Part No. T1102# TRANS INV HVT-325 LTZ3PZ0XB018 C1103 CHIP CERAMIC CAP . F Z 2.2µF50V CHF1JZ30F225 C1104 CAP CERAMIC HV 10pF/6.3kV/SL/J CCC1000MR007 T1100# TRANS INV TZ.7617A.101 LTZ3PZDAR014 C1105 CHIP CERAMIC CAP . CH J 330pF/50V CHD1JJ3CH331 T1101# TRANS INV TZ.7617A.101...
  • Page 61 Ref. No. Description Part No. Ref. No. Description Part No. D201 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 D1504 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U D202A SWITCHING DIODE 1SS400 TE61 QD1Z001SS400 D1505 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U D205A ZENER DIODE SMD TFZGTR33B QD1B000TFZ33 D1506 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U D206...
  • Page 62 Ref. No. Description Part No. Ref. No. Description Part No. RES CARBON FILM T 1/4W J 10 Ω RES CARBON FILM T 1/4W J 270 Ω R209 RCX4100T1001 R610 RCX4271T1001 RES CARBON FILM T 1/4W J 10 Ω CEMENT RESISTOR 5W J 2.2 Ω H 10MM R211 RCX4100T1001 R611#...
  • Page 63 Ref. No. Description Part No. Ref. No. Description Part No. RES CHIP 1608 1/10W J 22k Ω R1208 RRXA223HH013 SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB RES CHIP 1608 1/10W J 10k Ω R1209 RRXA103HH013 T600# TRANS POWER 11714 LTT3PC0KT069 RES CHIP 1608 1/10W J 10k Ω R1212 RRXA103HH013 When you replace one of the below Trans Inverters on this CBA, please...
  • Page 64: Revision History

    REVISION HISTORY Chassis PL11.10 • 2012-08-21 32PFL1507/F8 (Serial No. : DS1) added 15-1 PL11.10REV...
  • Page 65: Comparison List Of Model Names

    COMPARISON LIST OF MODEL NAMES Chassis PL11.10 32PFL1507/F8 (DS1) A1AFRZH TYPE A 16-1 PL11.10COM...
