Platinum CCTV Surveillance Solutions
CD-8360 SONY Indoor/Outdoor
Day/Night Long-Range Infrared
Varifocal 600 TVL Camera
Installation Manual
Outdoor Varifocal Hi-Res Day/Night
Infrared CCD Armor Dome Camera
with DSP
For Warranty Registration, Visit
Http:// Platinum-CCTV.com
Advertisement
Summary of Contents for Sony CD-8360
- Page 1 Platinum CCTV Surveillance Solutions CD-8360 SONY Indoor/Outdoor Day/Night Long-Range Infrared Varifocal 600 TVL Camera Installation Manual Outdoor Varifocal Hi-Res Day/Night Infrared CCD Armor Dome Camera with DSP For Warranty Registration, Visit Http:// Platinum-CCTV.com...
- Page 2 Platinum CCTV Surveillance Solutions Camera Installation Camera Mounting: Items Needed: Screwdriver, Drill, Mounting Hardware (not included), Pencil Loosen and remove the 3 allen screws near the base with included allen wrench Place the bracket on the wall and mark to drill holes.
- Page 3 Platinum CCTV Surveillance Solutions Camera Installation Reinstall camera ball onto the bracket and adjust camera to the proper angle then re-tighten allen screws to hold the camera solid. Adjust Zoom/Focus with 2 adjustment screws Note: BOTH adjustments need to be adjusted.
- Page 4 Platinum CCTV Surveillance Solutions CD-8360 Long Range IR CCD Camera Image Sensor 1/3” SONY Low-Light CCD DSP Number of Pixels NTSC: 768 (H) x 494 (V) Scanning System 15.7343Khz (H), 60 Hz (V) Sync System Internal Synchronization Resolution 600 TVL Lens 3.5-8mm Varifocal Lens (Ext.
