fadini BAYT 980 Instruction Booklet

Oil-hydraulic barrier for traffic control of from 3 to 8 metres wide
Hide thumbs Also See for BAYT 980:
Table of Contents

Advertisement

Quick Links

BAYT 980
Oil-Hydraulic barrier for traffic control of from 3 to 8 metres wide
INOX Stainless Steel and Painted Versions
Version with aluminium fencing
Version with cabled hinged road barrier beam
Folding or fixed leg with yoked pedestal
Fully convertible to right and left versions
Fixed braking when opening and adjustable when closing
Road barrier beams set up for flashing LED lamps
BA YT 98
0
Ole odi nam
ica
Instruction Booklet
GB
the gate opener
Made in Italy

Advertisement

Table of Contents
loading

Related Manuals for fadini BAYT 980

Summary of Contents for fadini BAYT 980

  • Page 1 BAYT 980 Oil-Hydraulic barrier for traffic control of from 3 to 8 metres wide INOX Stainless Steel and Painted Versions Version with aluminium fencing Version with cabled hinged road barrier beam Folding or fixed leg with yoked pedestal Fully convertible to right and left versions Fixed braking when opening and adjustable when closing Road barrier beams set up for flashing LED lamps...
  • Page 2 - All of the packing material and other waste must be disposed of through specialised firms. Do not dispose of toxic substances into the environment. The Meccanica Fadini Company is not responsible for any damages brought about by improper utilisation or any use that is not specifically indicated in this booklet.
  • Page 3 FIG. 2 The Bayt 980 traffic control barrier is distinguished in Right Handed or Left Handed versions according to how it is observed from outside the installation: in any case the opening thrust of the hydraulic piston must always lift the barrier beam (Fig. 2).
  • Page 4 fixed pedestal - 2 - 80 mm out of line from the corner of the housing cabinet base (Fig. 5). Once the Anchor Plate Anchor Plate has been well set in the ground (it is necessary to wait until the concrete has set), the Bayt 980 housing cabinet may be installed and then tighten the four M14 hexagonal nuts securely with their relative washers (screwing them down tight on the anchor bolts extruding from the base of the cabinet) as illustrated in Fig.
  • Page 5 Important: THE ENTIRE SYSTEM MUST BE CONNECTED TO EARTH Important: before carrying out any procedure on the PCB, disconnect the electric power supply mains. It is furthermore recommended that the booklet "Safety Regulations" made available by Meccanica Fadini be examined thoroughly.
  • Page 6 Bayt 980 INSTALLATION OF THE BARRIER BEAM AND POSSIBLE COMBINATIONS INSTALLATION: Beam clamp with 8 attachment The R532 aluminium barrier beam is attached to the beam clamp located on the side of the screws housing cabinet, facing the entrance that is to be controlled with the barrier.
  • Page 7 (See table Fig. 34, page 20). In the Bayt 980 installation with barrier beams that are 6.40 metres in Important: the length of the counterweight attachment bolts varies with the length or longer with fencing, it is necessary to also attach number of counterweights needed.
  • Page 8 Ref. Drawing 5257 - Bayt 980 already prepared for the coupling. LEFT version - According to the demands of the installation it is possible to apply a hinge coupling to the Bayt 980 following the instructions found in Fig. 15. FIG. 15...
  • Page 9 (4) on the outside of the cover (Fig.18). - Replace the cover on the housing cabinet (Ref. 17) and attach it with the three M8 screws so as to cover the Bayt 980 cabinet, as shown in Fig. 18.
  • Page 10 OFF: Without pre-flashing switches and has a pre-set maximum work DIP-SWITCH 8: time limit of 25 sec. (BAYT 980 8 metre barrier beam with fencing: maximum 19 sec.) ON: Flasher deactivated during pause in automatic...
  • Page 11 Electrical connections: 1) Elpro 980-A: Perform all of the connections necessary for the operation of the Bayt 980-A. Any command accessories, radio PCB or whatnot, must be connected exclusively to the Elpro 980-A. 2) Elpro 980-B: Power the PCB, jumper the NC connections (Stop, photocell and safety switches) and finally connect the motor and the limit switches of the...
  • Page 12 M16 counter nut - Once the adjustment has been made, the M16 counter nut previously loosened must be tightened, so as to lock the Bayt 980 valve attachment yoke base. Release valve - Remember to tighten the M16 counter nut (9) of the piston rod yoke ferrule to the actuation 24mm spanner rod (8).
  • Page 13 Bayt 980 ADJUSTMENT OF THE BARRIER BEAM IN VERTICAL AND HORIZONTAL Barrier beam in intermediate position Vertical at 45° Horizontal Half Important stroke The first operation to be performed is to put the spring-rod at half stroke: (see "C1 - C2", fig.25).
  • Page 14 COUNTER NUTS Once the procedure on the stop points of the Bayt 980 barrier beam has been finished, it is possible to adjust the opening and closing limit switches with the “L.S.” adjustable ridged feelers, which contact the flexible limit switch Flexible limit switch lever lever.
  • Page 15 Bayt 980 barrier beam, with the possibility of the acting manual by acting on the regulator on the adjustment regulator for the maximum and the...
  • Page 16 IS COMPLIANT TO THE MACHINE DIRECTIVE..2006/42/CE FURTHERMORE: The Bayt 980 is marketed to be installed as an "automated system" with original accessories and components indicated by the Manufacturing Firm. The automated mechanism, according to the provisions of the law is a "machine" and therefore the installer must apply all safety regulations to it.
  • Page 17 FIG. 30 In the event of an installation of the Bayt 980 with LED lamps it is possible to connect the Al.Flex 34 command device the gate opener and to obtain the alternating flashing without pauses or else the alternating flashing of the "flash" type (Fig.30).
  • Page 18 - Weight 10 Kg each - "INOX" Bayt 980 complete cabinet weight....75 kg (without barrier beam) Bayt 980 complete cabinet weight ..75 kg (without barrier beam) Colour of painted pillar........RAL 2002 Red Version with cabinet, cover and door Colour of painted cover and door....
  • Page 19 Elettric motor " ..P20 ø 140 - 0.5 HP - 0.37 KW Condenser..20 μF ø 16 FIG. 33 TECHNICAL SPECIFICATIONS - BAYT 980 - TECHNICAL SPECIFICATIONS OIL-HYDRAULIC MOTOR-PUMP UNIT - COS 982 - ELECTRIC MOTORS Working pressure 20 atm Power output 0,37 kW (0,5 HP) Max.
  • Page 20 SPECIFIC SUGGESTIONS The development of the firm MECCANICA FADINI has always been based upon the guarantee of the quality of its products and on the existence of a TOTAL QUALITY CONTROL system, which has guaranteed the maintenance of quality levels over time and a constant updating of the European Regulations, in the framework of a continuous process of improvement.
