- Page 1 4-735-433-11(1) Camera Control Box Instruction Manual CCB-WD1...
-
Page 2: Important Safety Instructions
English CAUTION For safety, do not connect the connector for peripheral device WARNING wiring that might have excessive voltage to LAN terminal. Follow To reduce fire or shock hazard, the instructions for LAN terminal. do not expose the unit to rain or moisture. - Page 3 For Customers in the U.S.A. your product For question regarding your product or for the Sony Service Center nearest you, call 1-800-222- • Refer to the Sony website for the SONY (7669). compatible models. • Along with this manual, refer to Declaration of Conformity...
-
Page 4: Supplied Items
Checking the Notes to avoid access by unintended third parties product and the Depending on the environment of use, unintended third parties may supplied items access your network. Only connect this product to networked devices managed by you. Connection The number in parentheses to other networked devices is indicates the number of pieces. - Page 5 Identifying parts Tripod socket hole Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the product, and damage to the product may occur. Power lamp LAN terminal Use this terminal to connect the product to a computer or a switching hub.
- Page 6 Connecting to a camera and a computer Connect this product to a camera and a computer to operate the camera from the computer. You can operate multiple cameras at once from a single computer by connecting them as illustrated below. Set the MASTER/CLIENT switch on one of the products (camera control boxes) to “MASTER.”...
- Page 7 Cable protector Use the cable protector to prevent the cables from being disconnected. Run all the cables through the cable protector, and then connect the cables to the product. Attachment screws Attach the cable protector to the product so that it aligns with the shape of the connector compartment, and then secure the cable...
- Page 8 Connecting the product to a camera Connect the product to the camera using the multi terminal connecting cable (supplied). • On the camera, set MENU (Setup) [USB Connection] to [PC Remote] before you connect it. • On the camera, set MENU (Setup) ...
- Page 9 Setting the MASTER/CLIENT (Master/Client) switch Set the MASTER/CLIENT switch to “MASTER” if you will be using one MASTER/CLIENT switch camera. To use multiple cameras at once, set the switch on one of the camera control boxes to “MASTER.” Then, set the switches on the others to “CLIENT.”...
- Page 10 Connecting the product to a computer or switching hub Connect the product to a computer or switching hub using a commercially available LAN cable. Connect the LAN terminal on the product with the LAN port on the computer or switching hub using a LAN cable. •...
- Page 11 Turning the power on Connect the product to a power source using the AC Adaptor (supplied). Connect the micro USB connector on the product with the USB connector on the AC Adaptor (supplied) using the micro USB cable (supplied), and then connect the AC Adaptor to a wall outlet (wall socket).
- Page 12 • Make sure that the battery inside the camera is sufficiently charged. • You can also turn the camera on from the web browser. For details on how to operate the camera from the web browser, refer to the “Help Guide.” “Help Guide” (Web manual) http://rd1.sony.net/help/dsc/1760/h_zz/...
-
Page 13: Troubleshooting
(Setup) The power does not turn on. [Auto Pwr OFF Temp.] to [High]. • Make sure that the AC This may extend the recording Adaptor is a genuine Sony time. AC-UUD12/AC-UUE12. The power lamp blinks. The power turns off suddenly. - Page 14 Precautions For customers bringing the product abroad This product is compatible with Do not use/store the product in electric voltages in the range of the following places 100 V – 240 V, and can be used worldwide. • In an extremely hot, cold or humid Do not connect the product to place a voltage transformer (travel...
-
Page 15: Specifications
Source code is provided on the web. 2 3/8 × 1 5/8 × 1 3/16 in. Use the following URL to download it. Mass (Approx.): 90 g (3.2 oz) http://oss.sony.net/Products/Linux/ We would prefer you do not contact AC Adaptor AC-UUD12/UUE12 us about the contents of source code. - Page 16 ©2018 Sony Corporation Printed in China...
