Specifications
1.
Project
Specification
Audioand
video
Hardware
2.
Welcome to use Lenovo Cloud Camera G2, No matter where you are, You can see Lenovo Cloud Camera G2 feel free
to browse the home of real‐time video and wonderful video by association, Capture things you care about, Get peace of
mind life.
Before using the product, Please read the installation guide carefully, In order to successfully install.
2.1.The product packing list
Lenovo Cloud Camera Instructions
Specifications
Subprojects
Size(W×D×H)
Weight
Color
Sensor
Lens
IR
LordResolution
Compression
Frame
Rate
Audio
Power
PowerConsumption
Temperature
Humidity
Appearance
Parameter
58*96*45.5mm
110g
White
HDCMOSSensor
f=3.6
Wide-anglelens
Infraredfilterautomaticallyswitch
1280*720
H.264/JPEG
30F/S
64kbps~8Mbps
Built-inmicrophoneandspeaker
DC5V/2A
<3.2W
-20℃~55℃，Indoor
10%~90%
Advertisement
Summary of Contents for Lenovo CLOUDCAMERA-G2
- Page 1 Lenovo Cloud Camera Instructions Appearance Specifications Specifications Project Subprojects Parameter Specification Size(W×D×H) 58*96*45.5mm Weight 110g Color White Image Sensor HDCMOSSensor Lens f=3.6 Wide-anglelens Infraredfilterautomaticallyswitch Audioand LordResolution 1280*720 video Compression H.264/JPEG Frame 30F/S Rate 64kbps~8Mbps Audio Built-inmicrophoneandspeaker...
- Page 2 Installation Guide 2.2.Confirm the use of the environment ＞ The camcorder uses the environment need to have a home wireless router, And real‐time access to the Internet ＞ Supports IE browser kernel, Chrome browser, etc. ＞ Intelligent Terminal: Android2.3 or above, iOS6/7 2.3.Camera Installation and Configuration 1).the camera is powered 2).Download and install Lenovo Cloud Camera G2 Client Download the following steps a).Download from lelink.lenovo.com b).Download from Android application market or APP Store c).Mobile Scan the following two‐dimensional code to download 2.4. Account Registration and Login You can use the phone numbers registered account 2.5. Add and configure a new camera After Login, Use the main interface "minimalist installation" feature, Follow the prompts to complete the ...
- Page 3 2.6. In the process of installing and using the camera in case of any problems,You can Call the service hotline: 400‐610‐6683,or Visit lelink.lenovo.com, Check the installation of video cameras and help support page 3. Account Management 3.1 Login Enter your registered mobile phone number and password, you can log in to the home page. 3.2 Forgot Password If you forget your account password, you can click on the "Forgot Password" prompt steps to recover the password according to the page. 3.3 Logout If you want to exit, click on "More" to quit account. 4. Quick Experience Even if not registered, you can also choose fast experience, access to public camera interface for video viewing. Public ...
- Page 4 4.1 Camera Management You can use the "minimalist install the" Add Camera,Click” ”,Add more Camers. 4.2 Settings Click the button “ ”,then can set the cameras. ...
- Page 5 4.3 Delete Click the button ,you can delete the cameras. 4.4 Real‐time video You can watch my video camera screen, click the screen ...
- Page 6 Screenshot: The picture is saved in the form of images, the image will be saved to your phone. You can view the local file. Mute: You can control the current is turned on the sound. 4.5 Playback You can select "Playback", according to video cameras and date to view The statements should be displayed in the user manual: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. ...
- Page 7 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 ...
