Page 5: Preface
This manual is intended for persons responsible for the configuration and operation of the IntuiKey keyboard when used with BVIP units (Bosch Video over IP) and the optional IP Matrix function. This manual describes the configuration of IP Matrix and the associated configuration and operation of the IntuiKey keyboard. - Page 6 | Preface IP Matrix F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 7: Product Description
IntuiKey keyboard fully installed and ready for operation – BVIP decoder fully installed and ready for operation, includes installed and configured IP Matrix function Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras... -
Page 8: Overview Of Functions
Up to 32 cameras, ten monitors and one IntuiKey keyboard – No computer required to operate system – Automatic camera tours – Automatic alarm processing via Alarm Task Scripting F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 9: Installation And Configuration
You use this number and the installation code on the Licenses page to generate the activation key on the Bosch Software License Manager Internet platform. Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12... - Page 10 | Installation and Configuration IP Matrix Open the following website: https://activation.boschsecurity.com/. The Bosch Security Systems Software License Manager user interface will appear. The page appears in English only. If you already have an account, log in. You can create a new account if you wish. The benefit of an account is that you can list all of your previous license activations.
-
Page 11: General
The audio signals are sent in a separate data stream parallel to the video data, and so increase the network load. The audio data are encoded according to G.711 and require an additional bandwidth of approx. 80 kbps for each connection. Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 12: Monitors
These correspond to quadrants 1 to 4. In this case, select the number of the quadrant you require from the list. F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 13: Cameras
Select the number of the data stream you require from the list. Preset For an AutoDome or a compatible unit that supports the AutoDome protocol, enter the required preset in the field. Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras... -
Page 14: Camera Tours
Cameras configuration page. You can also use the same camera more than once in each camera tour. F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 15: Softkeys
The softkeys are programmed using the Alarm Task Editor. For further information on this, please see the Alarm Task Editor section in the Installation and Operating Manual of the BVIP decoder and in the Alarm Task Script Language document. Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 16: Connecting And Starting The Intuikey
If access to IP Matrix is password protected, you must now enter the password that you defined on the IP Matrix > General configuration page for the connected BVIP decoder. F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 17: Operation Of Ip Matrix Using The Intuikey
NOTICE! Functions that concern a monitor or a camera always act on the active monitor and camera. Their numbers are displayed in the status display. Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras... -
Page 18: Switching Camera To Monitor
Press the Previous Camera softkey to select the previous camera in the system. The camera image is switched to the monitor that is currently active. F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 19: Controlling Cameras
Press the Aux On softkey and then press the number of the Aux command you require. Press Enter to confirm the selection. The command is executed. Press the Aux Off softkey to cancel an Aux command currently being executed. Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 20: Starting And Exiting A Camera Tour
When all alarms have been acknowledged, the key is no longer lit up. NOTICE! Depending on how IP Matrix is programmed, you can trigger further actions by pressing the alarm key. F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 21: Troubleshooting
In addition, an E is displayed in the status display. If you are unable to resolve the malfunction, please contact your supplier or systems integrator, or go directly to Bosch Security Systems Customer Service. The following table is intended to help you identify the causes of malfunctions and correct them where possible. - Page 22 | Operation of IP Matrix using the IntuiKey IP Matrix F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 23: Index
Overview of functions 8 Password 11 Preset 13 Quad view 18 Requirements 7 RS-232 16 Scenes 14 Screen resolution 7 Bosch Security Systems Installation and Operating Manual F.01U.082.117 | V4.0 | 2008.12 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 24: F.01U.082.117 | V4.0 | 2008.12
| Index IP Matrix F.01U.082.117 | V4.0 | 2008.12 Installation and Operating Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 25 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
