Upgrading the Dell PowerEdge R940
system from dual processor to quad
processor configuration

Advertisement

loading

Related Manuals for Dell PowerEdge R940

Summary of Contents for Dell PowerEdge R940

  • Page 1 Upgrading the Dell PowerEdge R940 system from dual processor to quad processor configuration...
  • Page 2 Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. 2017 - 10 P/N 7WCG8 Rev. A00...

  • Page 3: Notes, Cautions, And Warnings

    Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

  • Page 4: Processor Configuration

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that are shipped with your product.
  • Page 5 Figure 2. Removing system cover Hold the system cover on both sides, and lift the cover away from the system. Hold the air shroud at both ends and lift the air shroud out of the system. NOTE: The air shroud for the dual processor system can be discarded. NOTE: If you have a dual processor 3UPI system, remove the two 3UPI cables from the system board and discard.
  • Page 6 Figure 3. Installing PEM power boards Hold the PEM vertically by using the PEM handle. Align the slots on the sides of the PEM with the standoffs on the sides of the system and lower the PEM into the standoffs. Figure 4.
  • Page 7 Hold the PEM handle and lower the PEM until it firmly seats in place. Place the heat sinks, processors, and processor brackets for installation on a static-safe work table. NOTE: Heat sinks, processors, processor brackets, and DIMMs are not part of the kit. They have to be ordered separately.
  • Page 8 Figure 6. Installing heat sink onto processor Remove the processor socket dust covers on the PEM. Align the pins on the heat sink to the guides on the PEM and then place the processor and heat sink module (PHM) on the processor socket.
  • Page 9 If applicable, move the NVMe extender cards from the system board to the appropriate expansion card riser slot per the Installation and Service Manual or System Information Label (SIL), and connect the new NVMe cables per requirement. For more information on NVMe cabling, watch the video at www.Dell.com/QRL/ PER940/4S-NVMe-cabling. Figure 8. 4S NVMe cabling...
  • Page 10 Figure 9. Removing expansion card riser blank Remove the protective covers on the expansion card riser connectors on the PEM. To install the expansion card riser, lift the release lever to an upward position. Figure 10. Installing expansion card riser Align the guide rail on the side of the expansion card riser with the slot on the side of the system and lower the expansion card riser into the system.
  • Page 11 Repeat the steps 20 to 24 to install the other expansion card riser. Install the air shroud for the quad processor configuration provided in the kit. Figure 11. Installing quad processor air shroud Align the tabs on the system cover with the guide slots on the system and slide the system cover forward to close the system cover latch.
  • Page 12 Figure 12. Installing system cover...
