Please.read.these.instructions.carefully.before.using.this.product.and.save.this.manual.for.future.use.

OPERATING INSTRUCTIONS

Contents
Getting Started
Introduction. . ................................................................
Read.Me.First..............................................................
Description.of.Parts...................................................
Appendix
Specifications............................................................
Personal Computer
CF-30
Model No.
series
2
3
10
13

Advertisement

loading

Related Manuals for Panasonic CF-30

Summary of Contents for Panasonic CF-30

  • Page 1: Operating Instructions

    OPERATING INSTRUCTIONS Personal Computer CF-30 series Model No. Contents Getting Started Introduction..............Read.Me.First.............. Description.of.Parts........... Appendix Specifications............Please.read.these.instructions.carefully.before.using.this.product.and.save.this.manual.for.future.use.

  • Page 2: Introduction

    Introduction Thank.you.for.purchasing.this.Panasonic.computer..For.optimum.performance.and.safety,.please.read.these.instruc- tions.carefully. n Terms and illustrations in these instructions Conditions.that.may.result.in.minor.or.moderate.injury. CAUTION Useful.and.helpful.information. NOTE Enter .:. Press.[Enter].key. Fn .+. F5 .:. Press.and.hold.[Fn].key,.and.then.press.[F5].key. .(Start).-.[All.Programs].:. Click. .(Start),.and.then.click.[All.Programs]. Page.in.these.Operating.Instructions.or.in.the.Reference.Manual. è.:. Reference.to.the.on-screen.manuals. l Some illustrations are simplified to help your understanding and may look different from the actual unit. l. If.you.do.not.log.on.as.an.administrator,.you.cannot.use.some.functions.or.cannot.display.some.screens. l. Refer.for.the.latest.information.about.optional.products.to.the.catalogs,.etc. l. In.these.instructions,.the.names.and.terms.are.referred.as.follows. ® Ÿ. “Windows.Vista .Business”.as.“Windows”.or.“Windows.Vista”...

  • Page 3: Read.me.first

    Federal Communications Commission Radio Fre- This.device.complies.with.Part.15.of.the.FCC.Rules..Op- quency Interference Statement eration.is.subject.to.the.following.two.conditions: (1).This.device.may.not.cause.harmful.interference,.and Note:.This.equipment.has.been.tested.and.found.to.comply. (2).This.device.must.accept.any.interference.received,. with.the.limits.for.a.Class.B.digital.device,.pursuant.to.Part.15. including.interference.that.may.cause.undesired.op- of.the.FCC.Rules..These.limits.are.designed.to.provide.rea- sonable.protection.against.harmful.interference.in.a.residential. eration. installation..This.equipment.generates,.uses.and.can.radiate. Responsible.Party:. Panasonic.Corporation.of.North.America radio.frequency.energy.and,.if.not.installed.and.used.in.accor- One.Panasonic.Way dance.with.the.instructions,.may.cause.harmful.interference. Secaucus,.NJ.07094 to.radio.communications..However,.there.is.no.guarantee.that. Tel.No:1-800-LAPTOP5.(1-800-527-8675) interference.will.not.occur.in.a.particular.installation..If.this. 6-M-1 equipment.does.cause.harmful.interference.to.radio.or.televi- sion.reception,.which.can.be.determined.by.turning.the.equip- FCC Regulation Notice for modem ment.off.and.on,.the.user.is.encouraged.to.try.to.correct.the. This equipment contains a FCC approved modem.
  • Page 4 Read Me First 9.. The.Telephone.Consumer.Protection.Act.of.1991.makes. NOTICE for the products using LCD it.unlawful.for.any.person.to.use.a.computer.or.other. This product has a fluorescent lamp that contains mercury. electronic.device.to.send.any.message.via.a.telephone. Disposal.may.be.regulated.in.your.community.due.to.envi- fax.machine.unless.such.message.clearly.contains.in.a. ronmental.considerations... margin.at.the.top.or.bottom.of.each.transmitted.page.or. For.disposal.or.recycling.information,.please.contact.your. on the first page of the transmission, the date and time local.authorities,.or.the.Electronic.Industries.Alliance:.. it is sent and an identification of the business or other <http://www.eiae.org/> entry,.or.other.individual.sending.the.message.and. 24-M-2 the.telephone.number.of.the.sending.machine.or.such. business,.other.entity,.or.individual..In.order.to.program. this.information.into.your.fax.software,.you.should.refer. to.the.manual.of.the.Fax.software.being.used. 10.. A ccording.to.the.FCC’s.electrical.safety.advisory,.we. recommend.that.you.may.install.an.AC.surge.arrestor. in.the.AC.outlet.to.which.this.equipment.is.connected.. Telephone.companies.report.that.electrical.surges,. typically.lightning.transients,.are.very.destructive.to. customer.terminal.equipment.connected.to.AC.power. sources.and.that.this.is.a.major.nationwide.problem. “Caution : To reduce the risk of fire, use only No.26 AWG or larger.telecommunication.line.cord.” “ATTENTION.:.Pour.réduire.le.risque.d’incendie,.utiliser.
  • Page 5 25-Ca-1-1 Models for Europe <Only for model with a “CE” mark on the bottom of the computer> Declaration of Conformity (DoC) “Hereby,.we.declare.that.this.Personal.Computer.is.in.compliance.with.the.essential.requirements. and.other.relevant.provisions.of.the.Directive.1999/5/EC.” Hint: If.you.want.to.get.a.copy.of.the.original.DoC.of.our.products.which.relates.to.the.R&TTE,.please.con- tact.our.web.address:.http://www.doc.panasonic.de Contact.and.Pursuant.to.at.the.directive.2004/108/EC,.article.9(2) Panasonic.Testing.Centre Panasonic.Service.Europe,.a.division.of Panasonic.Marketing.Europe.GmbH Winsbergring.15,.22525.Hamburg,.F.R..Germany Network.connection. The.terminal.equipment.is.intended.for.connection.to.the.following.public.network;. In.all.the.countries.of.European.Economical.Area; -.Public.Switched.Telephony.Networks Technical.Features. The.terminal.equipment.includes.the.following.features;...
  • Page 6 Read Me First Important Safety Instructions / Importantes Mesures De Sécurité When.using.your.telephone.equipment,.basic.safety. Certaines.mesures.de.sécurité.doivent.être.prises.pen- precautions.should.always.be.followed.to.reduce.the.risk. dant l’utilisation de matérial téléphonique afin de réduire of fire, electric shock and injury to persons, including the les.risques.d’incendie,.de.choc.électrique.et.de.blessures.. following:. En.voici.quelquesunes: 1.. Do.not.use.this.product.near.water,.for.example,.near. 1.. Ne.pas.utiliser.l’appareil.près.de.l’eau,.p.ex.,.près.. a.bath.tub,.wash.bowl,.kitchen.sink.or.laundry.tub,.in.a. d’une.baignoire,.d’un.lavabo,.d’un.évier.de.cuisine,.. wet.basement.or.near.a.swimming.pool. d’un.bac.à.laver,.dans.un.sous-sol.humide.ou.près.. 2.. Avoid.using.a.telephone.(other.than.a.cordless.type). d’une.piscine. during.an.electrical.storm..There.may.be.a.remote.risk. 2.. Éviter.d’utiliser.le.téléphone.(sauf.s’il.s’agit.d’un.ap- of.electric.shock.from.lightning. pareil sans fil) pendant un orage électrique. Ceci peut 3.. Do.not.use.the.telephone.to.report.a.gas.leak.in.the. présenter.un.risque.de.choc.électrique.causé.par.la. vicinity.of.the.leak. foudre. 4..
  • Page 7 For Used in Motor Vehicle /Pour L’utilisation Dans Un Véhicule Motorisé Warning:.Notebook.Computer.may.be.installed.in.a.mo- Avertissement.:.L’ordinateur.bloc-notes.peut.être.installé. tor.vehicle.and.visible.to.the.driver.only.if.used.to.support. dans.un.véhicule.motorisé.et.dans.le.champ.de.vision.du. vehicle.related.functions.such.as.vehicle.information,. conducteur.uniquement.en.tant.que.dispositif.d’aide.aux. system.control,.rear.or.side.observation.and.navigation.. fonctions.du.véhicule,.comme.par.exemple.pour.fournir. If.used.for.entertainment.purpose,.such.as.television. des.informations.sur.le.véhicule,.comme.dispositif.de. reception.or.video.play,.it.must.be.installed.to.the.rear. contrôle.de.système,.pour.l’observation.à.l’arrière.ou.sur. of.the.driver’s.seat.where.it.will.not.be.visible,.directly.or. les.côtés.du.véhicule,.ainsi.que.pour.fournir.de.l’informa- indirectly,.to.the.operator.of.the.motor.vehicle..Check.with. tion routière. Pour toute utilisation à fin de divertissement, individual.state/provincial.laws.to.determine.lawful.use.of. comme.par.exemple.pour.regarder.la.télévision.ou.jouer. this.product.while.operating.within.a.motor.vehicle. à.des.jeux.vidéo,.il.doit.être.installé.à.l’arrière.du.siège.du. conducteur,.en.un.emplacement.où.il.ne.sera.pas.visible,. ni.directement.ni.indirectement,.pour.le.conducteur.du. véhicule motorisé. Vérifiez les lois fédérales et nationales qui.régissent.l’utilisation.légale.de.cet.appareil.à.l’intérieur. d’un.véhicule.motorisé. 35-M-1 Information on Disposal in other Countries outside the European Union These.symbols.are.only.valid.in.the.European.Union.
  • Page 8 This.computer.is.not.intended.for.use.in.medical.equipment. the.battery.pack..Then.contact.your.technical.support.of- including life-support systems, air traffic control systems, or fice. other.equipment,.devices.or.systems.that.are.involved.with. ensuring.human.life.or.safety..Panasonic.cannot.be.held.re- Do Not Disassemble This Product sponsible.in.any.way.for.any.damages.or.loss.resulting.from. There.are.high-voltage.areas.inside.which.may.give.you.an. the.use.of.this.unit.in.these.types.of.equipment,.devices.or. electric.shock.if.you.should.touch.them...Do.not.touch.the. systems,.etc. pins.and.circuit.boards.inside,.and.do.not.allow.foreign.mat- The.CF-30.was.developed.based.on.thorough.research.into. ter.to.enter.inside. the.real-world.portable.computing.environments..Exhaustive. Also, remodeling or disassembly may cause a fire. pursuit.of.usability.and.reliability.under.harsh.conditions.led. Keep SD Memory Cards Away from Infants and Small to.innovations.such.has.the.magnesium.alloy.exterior,.vibra- Children tion damped hard disk drive and floppy disk drive, flexible Accidental.swallowing.will.result.in.bodily.injury. internal.connections..The.CF-30’s.outstanding.engineering. In.the.event.of.accidental.swallowing,.see.a.doctor.immedi- has.been.tested.using.the.strict.MIL-STD-.810F.(for.vibra- ately.
  • Page 9 The.battery.pack.is.a.consumable.item...If.the.amount. Do Not Use This Product with a Battery Pack Other Than the One Specified of.time.the.computer.can.be.run.by.using.a.particular. Use only the specified battery pack (CF-VZSU46U) with your battery.pack.becomes.dramatically.shorter.and.re- product..Use.of.battery.packs.other.than.those.manufactured. peated.recharging.does.not.restore.its.performance,. and.supplied.by.Panasonic.may.present.a.safety.hazard. the.battery.pack.should.be.replaced.with.a.new.one. (generation.of.heat,.ignition.or.rupture). l. When.transporting.a.spare.battery.inside.a.package,. l. Do.not.touch.the.terminals.on.the.battery.pack...The.bat- briefcase,.etc.,.it.is.recommended.that.it.be.placed.in. tery.pack.may.no.longer.function.properly.if.the.contacts. are.dirty.or.damaged. a.plastic.bag.so.that.its.contacts.are.protected. l. Do.not.expose.the.battery.pack.to.water,.or.allow.it.to. l. Always.power.off.the.computer.when.it.is.not.in.use.. become.wet.

  • Page 10: Description.of.parts

    Description of Parts A: Bluetooth Antenna .:. Hard.disk.drive.status <Only.for.model.with.Bluetooth> .:. Power.status.of.the.multimedia.pocket .Reference Manual.“Bluetooth” è. .:. Battery.status .Reference Manual.“Battery.Power” B: ExpressCard Slot è. .:. Power.status .Reference Manual.“PC.Card./.ExpressCard” è. (Off:.Power.off/Hibernation,.Green:.Power.on,. C: PC Card Slot Blinking.green:.Sleep) .Reference Manual.“PC.Card./.ExpressCard” è. .:. Wireless.ready D: Multimedia Pocket This.indicator.lights.when.Wireless.LAN,.Blue- .Reference Manual.“Multimedia.Pocket”...
  • Page 11 Right side 1394 Rear side Bottom A: Hard Disk Drive M: External Display Port .Reference Manual.“External.Display” .Reference Manual.“Hard.Disk.Drive” è. è. B: SD Memory Card Slot N: Headphone Jack You can connect headphones or amplified speakers. .Reference Manual.“SD.Memory.Card” è. When.they.are.connected,.audio.from.the.internal. C: SD Memory Card Indicator speakers.is.not.heard. (Blinking:.During.access) O: Microphone Jack .Reference Manual.“SD.Memory.Card”...
  • Page 12 Description of Parts To.ensure.waterproof.integrity,.close.the.connector.covers.completely..When. closing the covers, push the 4 corners and make sure that the cover fits in com- pletely..(The.illustration.is.an.example.) Attaching the stylus to the computer (only for model with touchscreen) Use.the.tether.to.attach.the.stylus.to.the.computer.so.you.will.not.lose.it.. There.are.holes.(A).to.attach.it.

  • Page 13: Specifications

    Specifications This page provides the specifications for the basic model. The model number is different according to the unit configuration. l. To.check.the.model.number:. Check.the.bottom.of.the.computer.or.the.box.the.computer.came.in.at.the.time.of.purchase. l. To.check.CPU.speed,.memory.size.and.the.hard.disk.drive.(HDD).size:. .Reference Manual.“Setup.Utility”).and.select.[Information].menu.. Run.the.Setup.Utility.(è. [CPU.Speed]:.CPU.speed,.[System.Memory]:.Memory.size,.[Hard.Disk]:.Hard.disk.drive.size n Main Specifications Model.No. CF-30KTMAXJM CF-30K3MAXJM Intel®.Core™.2.Duo.Processor.SL9300.(1.6.GHz,.6.MB .L2.cache,.1066.MHz.FSB) Chipset Mobile.Intel®.GS45.Express.Chipset *1*2 Memory 2.GB.(4.GB.Max.) Video.Memory *1*3 UMA.285.MB.Max..(When.Memory.is.1024.MB)/1423.MB.Max..(When.Memory.is.4048.MB) Hard.Disk.Drive 160.GB Approx..2.GB.is.used.as.a.partition.with.recovery.tools..(Users.cannot.use.this.partition.) Display.Method 13.3.XGA.type.(TFT).with.Touchscreen 13.3.XGA.type.(TFT) Internal.LCD 65,536/16,777,216.colors.(800.×.600.dots/1024.×.768.dots) External.Display 65,536/16,777,216.colors.(800.×.600.dots/1024.×.768.dots/1280.×.768.dots/1280.×.1024. dots/1440.×.900.dots) Wireless.LAN è.page.35 Bluetooth™...
  • Page 14 Main Specifications Storage.Environment Temperature:.-20.°C.to.60.°C.{-4.°F.to.140.°F} Humidity:.30%.to.90%.RH.(No.condensation) Operating.System Windows.Vista ® .Business Utility.Programs DMI.Viewer,.Adobe.Reader,.PC.Information.Viewer,.Loupe.Utility,.. ® Bluetooth™.Stack.for.Windows .by.TOSHIBA ,.Wireless.Switch.Utility,.Hotkey.Settings,.. Battery Recalibration Utility, Panasonic Hand Writing, Infineon TPM Professional Package V3.0 ,.Power.Saving.Utility,.Wireless.Connection.Disable.Utility Setup.Utility,.Hard.Disk.Data.Erase.Utility ,.PC-Diagnostic.Utility n Wireless LAN <Only for model with wireless LAN> Data.Transfer.Rates IEEE802.11a.:.54/48/36/24/18/12/9/6.Mbps.(automatically.switched) IEEE802.11b.:.11/5.5/2/1.Mbps.(automatically.switched) IEEE802.11g.:.54/48/36/24/18/12/9/6.Mbps.(automatically.switched) IEEE802.11n.:.(HT20).144.4/130/117/115.6/104/86.7/78/65/58.5/57.8/52/43.3/39/28.926/19.5/ 14.4/13/6.5.Mbps.(automatically.switched) (HT40).300/270/243/240/216/180/162/130/120/117/108/104/90/81/78/60/54/52/ 39/30/27/26/13.Mbps.(automatically.switched) Standards.Supported IEEE802.11a./.IEEE802.11b./.IEEE802.11g./.IEEE802.11n(Draft.2.0) Transmission.method...
  • Page 15 . The.Product.Recovery.DVD-ROM.is.required. These are speeds specified in IEEE802.11a+b+g+n standards. Actual.speeds.may.differ.
