Honda Pilot 2009 Service Bulletin

Pdi of the dvd navigation system
Hide thumbs Also See for Pilot 2009:
1
2
3
4
5

Advertisement

Quick Links

Download this manual See also: Navigation Manual, Owner's Manual
2009 Pilot – ALL
Applies To:
2009 Pilot: PDI of the DVD Navigation System
BACKGROUND
This bulletin provides information for the PDI
(pre-delivery inspection), including testing, of the
navigation system. These topics are covered:
• Navigation System Controls
• Voice Control System Operation
• Navigation System Setup at PDI
• Map Coverage Areas
• Hawaii System Setup
• Ordering a DVD
For more information about the navigation system and
its operation, refer to these resources:
- Quick Start Guide
- Online University - Use the keyword NAVI for more
information about the navigation system.
- Navigation System Manual - Besides the one that
comes with the vehicle, the navigation system
manual is also available online. Select SEARCH BY
PUBLICATION, select Consumer Information,
select Owner Manuals, select your applicable
vehicle, then select the Navigation Manual from the
list.
WARRANTY CLAIM INFORMATION
None. These procedures are considered part of the
normal PDI.
© 2008 American Honda Motor Co., Inc. – All Rights Reserved
CUSTOMER INFORMATION:
and training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not assume
this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an
authorized Honda automobile dealer.
Service Bulletin
The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment,
NAVIGATION SYSTEM CONTROLS
MAP/GUIDE
CANCEL
A
U
I D
O
AUDIO
BUTTON
DISPLAY
MODE
BUTTON
The buttons listed above are used in this bulletin. For
more information on the button functions, see Getting
Started in the navigation system manual.
ATB 39139 (0805)
08-027
May 15, 2008
SCREEN
MAP/GUIDE
BUTTON
MENU
MENU
BUTTON
INFO
ENTER
INFO
BUTTON
S
E
T
U
P
SETUP
BUTTON
CANCEL
INTERFACE DIAL/
BUTTON
ENTER BUTTON
LOWER
DISPLAY
1 of 5

Advertisement

loading

Related Manuals for Honda Pilot 2009

Summary of Contents for Honda Pilot 2009

  • Page 1 Getting Started in the navigation system manual. 1 of 5 © 2008 American Honda Motor Co., Inc. – All Rights Reserved ATB 39139 (0805) CUSTOMER INFORMATION: The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and training to correctly and safely maintain your vehicle.
  • Page 2 VOICE CONTROL SYSTEM OPERATION NAVIGATION SYSTEM SETUP AT PDI Voice recognition is controlled by the NAVI TALK and The navigation system is basically ready to use when NAVI BACK buttons on the steering wheel. This is the the vehicle is delivered to the dealership. Since the primary way to give commands to the system.
  • Page 3 NAVI TALK button. 10. When you hear the beep, say “find the nearest Honda dealer.” The system should display a list of Honda dealers. 11. Rotate the interface dial to highlight your dealership, then push in on the dial.
  • Page 4 13. The system then calculates a route and displays it 22. Return to the main menu; if needed, clean the as a blue line. If you are in a rural area with screen with a soft damp cloth. You may use a mild unverified roads, you may see a blue vector line or cleaner intended for eyeglasses or computer a blue/pink dotted line pointing in the direction of...

  • Page 5: Map Coverage Areas

    For a list of current detailed coverage areas by country www.hondanavi.com, then select ORDER and state/province, refer to the navigation system NAVIGATION DVD. You can also call the Honda manual or www.hondanavi.com. Select the View Navigation Disc Fulfillment Center at (888) 291-4675.
