  • Page 1 SERVICE MANUAL SERVICE MANUAL Magellan II Magellan II CHASSIS CHASSIS CHASSIS CHASSIS CHASSIS MODEL COMMANDER DEST VTX-D800U VTX-D800U VTX-D800U VTX-D800U VTX-D800U R M - X 8 0 0 VTX-D800N VTX-D800N VTX-D800N VTX-D800N VTX-D800N R M - X 8 0 0...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Warning..... Tools Required..... Dissassembly ....Cover Removal..... Front Panel Removal..... B Board Removal..... Chassis Removal..... Service Mode [TT Mode] ....Special Key Sequence ....Special Remote Commander Data Code ....Exiting TT Mode ....

  • Page 3: Safety Warning

    Safety Warning Dangerously high voltages exist on the Power Supply Unit (PSU) PWB (See Fig 1). FOR THIS REASON, THE RECEIVER MUST ALWAYS BE DISCONNECTED FROM THE MAINS SUPPLY BEFORE ANY WORK DETAILED IN THIS MANUAL IS CARRIED OUT. Caution High Voltage Fig.

  • Page 4: Dissassembly

    1 Dissassembly 1.1 Cover Removal Remove the foot by releasing the clips circled and easing the foot carefully away from the unit. Remove the 2 screws located at the rear of the unit (shown arrowed). Lift the front of the cover slightly and slide towards the rear of the unit until it is clear.

  • Page 5: B Board Removal

    [ 1.3 ] B Board Removal Remove the cover and front panel as indicated in [1-1] and [1-2]. Disconnect CN600 power cord and remove from unit. Remove the 1 Philips screw from the rear panel. Remove the 3 Philips screws from the circuit booard. The B board can then be lifted clear of the chassis.

  • Page 6: Service Mode [Tt Mode]

    2 Service Mode [TT mode] There are 2 possible mechanisms for starting TT mode on Sony cook STB’s… 2.1 Special key sequence The following key sequence entered via the standard remote commander for a particular STB can enable TT mode. This sequence must be entered…...

  • Page 7: Entering The Tt Command Number

    Entering a ‘0’ digit after any other digit entry (thus making the command a multiple of 10) will immediately reset the display and perform no action. 3.2 Example VTX-D800U requires 3 digits. Therefore the following sequences would be valid to issue a test command… Sequence Result 0 ⇒...

  • Page 8: List Of Tt Commands

    4 List of TT commands Depending on the STB model the number of digits which are capable of being entered will vary, therefore any leading zero have been omitted from the TT number defined in the list. Entries should be made according to the description in section 3.
  • Page 9 Slot 0 bypass Transport stream is set to bypass slot 0. This command is effective only when there is no CAM inserted into slot 0. Slot 0 pass thru Transport stream is set to pass out/in slot 0. This command is effective only when there is no DVB compliant CAM inserted into slot 0.
  • Page 10 LED ON 1 Sets all LED’s as Colour 1 (Red) If bicolour LED and Colour 2 ON, it will be Orange LED ON 2 Sets all LED’s as Colour 2 (Green) If bicolour LED and Colour 1 ON, it will be Orange Tuner Show tuner status Shows the tuner status display on the OSD...

  • Page 11: Power Supply

    5.0: Power supply The power supply in an integrated part of the Main PWB, and contains the following functional blocks: - The main components are:- Mains Plug, Lead and input filter Primary and PWM Controller Transformer and outputs Feedback Circuit Post Regulation Circuits.

  • Page 12: Power Supply Detailed Description

    5.1: Power Supply Detailed Description The most common failures will be fixed by replacing the following components. PRIMARY BLAST KIT:- F600, D600, D602 D601, IC600, PH600, IC602, D604. The components detailed below have the following functions: Fuse, F600. T1.25A 250V Always replace the fuse, with the same type and ratings as the one removed.
  • Page 13 D602 Catch Diode The catch diode is in place to help limit the excess voltage to the MOSFET to guarantee the parts ratings. If the STB is victim to high mains this part is the first to fail trying to protect IC600. If damaged primary replace the blast kit.
  • Page 14 Secondary Operation The secondary outputs from the transformer will all rise at the same time, 3.3V reach its regulation point first followed by 5.0V, +21V and 32V. If the LED is flashing about once every second then a transformer output is shorted to GND or overloaded. Remove FB610 (33V) Remove FB607 (+5V) Remove FB605 (+3V3)

  • Page 15: Technical Specifications

    6. Technical Specifications for the SONY Cook (FTA DTT) IRD • Receiver Type DVB Terrestrial Receiver Decoder • Inputs RF input 1 x RF input from customer antenna 75Ω termination Modulation DVB-T (OFDM) Input Frequency 470 MHz - 862MHz (CH 21 to 69)
  • Page 16 Audio Output (Digital) Optical output :- (Digital PCM output) (Complies with IEC958 Consumer Mode ) 1 x (3.5mm Jack type) – as part of 3.5mm Combination Connector. RF Outputs 1 x RF Male Connector, (looped through DTT Tuner ) Maximum RF loss = < 9dBm •...
  • Page 17 1 x Standby / On (Tactile µSwitch) 1 x Standby / On Indicator LED (Red / Green) Software :- Sony design GUI, based on Sony IDTV#2 DLI • Remote IR control Sony SIRCs system :- Commander CAT code = 0x1B7 •...
  • Page 18 Accessories 1 x User Manual – English 1 x SCART Lead 1 x RF loop through Cable 1 x Remote Control Unit (RM-X800) 2 x Batteries (AA) 4 x Unit rubber feet • Dimensions (Unit ) 215 x 48 x 240 mm •...

  • Page 19: Device Descriptions

    7. Device Descriptions TU1000 - BTD-DU606Z The Front End DTT (digital terrestrial) NIM module receives an off air UHF signal, and converts the digital content into a parallel transport stream, to be fed into the MPEG decoder IC. This device is I2C controlled. IC600 -TOP244Y The TOP244Y is the Main PSU, PWM control IC.
  • Page 20 IC601 - PQ025EZ01ZP This is a fixed 2.5V regulator, its main function is to supply the PWB with a 2.5V supply. IC701- LM317LMX This is a variable voltage regulator, its main function is to supply IC700 with a 5V supply. List of Specification Sheets included on Service Manual CD TU1000 - BTD-DU606Z IC600 -TOP244Y...

  • Page 21: Block Diagram

    8.1 BLOCK DIAGRAM MultiFunction TV SCART VCR SCART Connector CN801 CN800 J800 +3V3 +32V +12V +5V0 +3V3 +2V5 +1V5 +12V Audio AV Switch IC800 Audio DAC IC700 GPIO SPDIF DENC IR Receiver DDR SDRAM IR IN DDR SDRAM IC502 Interface +3V3 16 or 32 MBytes 16 bit...

  • Page 22: B Board Pwb Layout

    8.2 B Board PWB Layout - 22 -...

  • Page 23: Multimedia Processor & Clock Generator

    B..-VTX-D800 +3V3 C264 +3V3 C265 +3V3 Ground stiching for C270 3.3V Close to Power Plane STP0_CLK,STP0_DAT[0-7],STP0_EN C266 For Front and Side of PCB RSTSW RSTSW C267 C269 C268 RSTSWB R272 RSTSWB Q201 DTC114YUA-T106 IR_IN_0 C219 C222 C209 C207 C246 C206 IR_IN_0B IR_IN_0B 6.3V...

  • Page 24: Front Panel & Reset

    B..-VTX-D800 FULL HARDWARE RESET CIRCUIT (STANDBY BUTTON FOR AT LEAST 5s) RESET SIGNAL GENERATION +3V3 RESET PULSE STRETCHER R513 R531 R538 1/10W +3V3 1/10W 1/10W JL502 Q512 D506 R537 DAN202K-T-146 R532 2SA1037AK-T146-QR 100k 3.3k 1/10W 1/10W GEN_RSTB R533 R550 R554 220k R534 Q511...

  • Page 25: Power Supply

    B..-VTX-D800 +33V_CLEAN NOTE: THE TOPSWITCH DESCRIPTION IS WRONG FOR THIS SYMBOL !! C615 R618 100p CORRECT DESCRIPTION SHOULD BE TOP244Y (SYMBOL DUE TO BE UPDATED). 4.7k THE P/N AND MACRO ARE CORRECT THOUGH. R619 +33V_CLEAN D607 R646 FB610 RS1J VLINK VLINK 1/4W C645...

  • Page 26: Audio Dac & Smartlink Switch

    B..-VTX-D800 VIDEO NOTE THE USE OF 0.5% RESISTORS R721 1/10W CHIP R722 GREEN GREEN 1/10W CHIP R723 BLUE AUDIO DAC SUPPLY OPTION BLUE +12V 1/10W CHIP IC701 LM317LM R724 CVBS CVBS VACOMP 1/10W VOUT VOUT CHIP R756 VOUT VOUT 1/10W R725 LUMA LUMA...

  • Page 27: Av Switch & Scart

    B..-VTX-D800 +3V3 C837 R824 C839 C845 1/10W R825 C840 D800 1/10W BZA408B-115 R887 R888 +3V3 J800 C850 C852 C815 C849 C851 C816 L802 SPDIF 100uH R852 1/10W R800 C804 C817 R839 6.3V 1/10W R840 R801 C805 1/10W 6.3V SCL_0 SDA_0 R841 C806 1/10W...

  • Page 28: Tuner Nim

    B..VTX-D800 SIEL NIM BCN NIM THIS CIRCUIT IS TO BE PLACED CLOSE TO TU1000 NO FIT FOR SONY BARCELONA NIM IC1001 +3V3 FB1005 C1016 +2V5_TU R1019 C1034 C1035 C1037 +12V R1005 IC1000 FB1008 R1032 C1038 C1064 C1040 R1008 C1018 C1012...

  • Page 29: Exploded View

    UK MODEL ONLY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK £ 1-823-917-11 CORD, POWER SUPPLY (VTX-D800U) 4-099-730-11 SCREW +BVTP £ 1-827-469-11 CORD, POWER SUPPLY (VTX-D800N/ *A-1302-374-A COMPLETE PC BOARD, B VTX-D800E) X-4041-804-2 ASSY, PANEL FRONT 4-099-730-01 SCREW + BVTP 3X12 TYPE 2 TT(B)

  • Page 30: Electrical Parts List

    SECTION 10 ELECTRICAL PARTS LIST PARTS LISTING TABLE OF CONTENTS B BOARD COMPLETE Parts List : ....................31 MISCELLANEOUS : ....................37 ACCESSORIES AND PACKAGING MATERIALS : ..................37 REMOTE COMMANDER : ....................37 Note : Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.
  • Page 31 H6 B REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C260 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V *A-1302-374-A COMPLETE PC BOARD, B C261 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C262 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V 4-382-854-01 SCREW (M3X8), P, SW (+) C263 1-165-722-31 ELECT 100UF...
  • Page 32 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C607 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C807 1-125-837-91 CERAMIC CHIP 1UF 6.3V C608 1-126-967-11 ELECT 47UF 20.00% 50V C808 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C609 1-126-960-11 ELECT 20.00% 50V C809 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C610...
  • Page 33 B1 B REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C1015 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V < FUSE > C1016 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C1020 1-126-933-11 ELECT 100UF 20.00% 16V F600 £ 1-576-424-21 LINK, FUSE C1021 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C1022 1-126-966-11 ELECT...
  • Page 34 F4 D REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK L1000 1-412-537-31 INDUCTOR 100UH R257 1-216-833-11 METAL CHIP 1/10W R258 1-216-833-11 METAL CHIP 1/10W < PHOTOCOUPLER > R259 1-216-833-11 METAL CHIP 1/10W R264 1-216-805-11 METAL CHIP 1/10W PH600 £ 8-749-011-64 PHOTO COUPLER PC123ZY2 R265 1-216-805-11 METAL CHIP 1/10W...
  • Page 35 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R361 1-216-803-11 METAL CHIP 1/10W R536 1-216-845-11 METAL CHIP 100K 5% 1/10W R362 1-216-803-11 METAL CHIP 1/10W R537 1-216-845-11 METAL CHIP 100K 5% 1/10W R363 1-216-803-11 METAL CHIP 1/10W R538 1-216-837-11 METAL CHIP 1/10W R364 1-216-803-11 METAL CHIP...
  • Page 36 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R724 1-216-812-11 METAL CHIP 1/10W R855 1-216-864-11 SHORT CHIP R725 1-216-812-11 METAL CHIP 1/10W R859 1-216-817-11 METAL CHIP 1/10W R726 1-216-809-11 METAL CHIP 1/10W R862 1-216-864-11 SHORT CHIP R730 1-216-821-11 METAL CHIP 1/10W R865 1-216-833-11 METAL CHIP...
  • Page 37 PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK MISCELLANEOUS £ 1-823-917-11 CORD, POWER SUPPLY (VTX-D800U) £ 1-827-469-11 CORD, POWER SUPPLY (VTX-D800N/ VTX-D800E) 8-598-638-00 TUNER UNIT, DIGITAL BTD-DU606Z ACCESSORIES AND PACKAGING MATERIALS *3-704-284-01 BAG (STANDARD), PROTECTION *4-205-505-03 CUSHION (LOWER) (ASSY) *4-099-791-01 INDIVIDUAL CARTON...
  • Page 38 English Sony Corporation 03GP7100-1 Sony UK Printed in U.K. 9-927-462-01 Service Promotions Dept. © 2003.07...
