SERVICE MANUAL
2007
3 S ERVICE MANUAL
MA308
KD-ADV5380J,KD-DV5300J,KD-DV5301E,KD-DV5301EU,
KD-DV5302E,KD-DV5302EU,KD-DV5304UI,KD-DV5305U,
KD-DV5305UN,KD-DV5305UT,KD-DV5305A,KD-DV5306U,
KD-DV5306UN,KD-DV5306UT,KD-DV5306A,KD-DV5307EE,
KD-DV5308EE,KD-DV5388UF,KD-DV4304UI,KD-DV4305U,
KD-DV4305UN,KD-DV4305UT,KD-DV4305A,KD-DV4306U,
KD-DV4306UN,KD-DV4306UT,KD-DV4306A,KD-DV4388UF,
KD-ADV5380/KD-DV5300/KD-DV5306
KD-DV5305/KD-DV5304/KD-DV5303
COPYRIGHT © 2007 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
2
Specific Service Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
3
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
4
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-34
5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-40
DVD/CD RECEIVER
KD-DVH426UN
KD-DV5308/KD-DV5307/KD-DV5302
KD-DV5301/KD-DV4306/KD-DV4305
KD-DV4304/KD-DV4303

TABLE OF CONTENTS

COPYRIGHT © 2007 Victor Company of Japan, Limited
except
KD-DVH426
only for
KD-ADV5380
KD-DV5300
KD-DVH426
only for
KD-DV5308
KD-DV5307
KD-DV5302
KD-DV5301
2007/3
