Halogen lamps
16.6 max.
∅ 50 max.
5.33 ± 0.25
∅ 1.45 - 1.60
Dimensions in mm
Maximum permissible temperatures Packing data
Reflector
Reflector rim
Pinch
Contacts
Type
ANSI
Wattage
W
14595
ESX
20
14597
FRB
35
14599
EXT
50
14596
BAB
20
14598
FMW
35
14600
EXN
50
14632
-
50
250°C
Single box packaging
240°C
Packing configuration
350°C
300°C
50 x 1
Voltage
Half-intensity
Luminuous
Beam angle
V
degs
12
+/- 10
12
+/- 10
12
+/- 10
12
+/- 36
12
+/- 36
12
+/- 36
12
+/- 60
Definition
Halogen reflector lamps consisting
of an extra-low-voltage halogen
burner optically positioned in a
glass reflector, which has a special
heat-transmitting and light-
reflecting dichroic coating.
The dichroic reflector coating
transmits the infra-red radiation
(heat) backwards through the
glass and reflects the visible
radiation (light) forward, thus
resulting in a 'cool beam. '
The ELV burner, with axial
filament, operates at low pressure
(≤ 2.5 bar) and is UV Block.
According IEC 598, these lamps
can be used in luminaires without
front glass.
Features
The most important features of
this lamp are:
• "cool beam" dichroic coated
reflector
• with front glass
• average lamp life of 3000 hrs
• colour temperature 3000°K
• excellent colour rendering
(R a = 100)
• universal burning position
• dimmable.
Weight
Dimensions
Volume
kg
cm
m
3
1.85
30.3 x 24.7 x 10.6
0.008
Base
Average
intensity
cd
3400
GU 5.3
3000
6000
GU 5.3
3000
8800
GU 5.3
3000
550
GU 5.3
3000
1000
GU 5.3
3000
1600
GU 5.3
3000
750
GU 5.3
3000
Low-voltage dichroic reflector
Applications
Dichroic reflector lamps are
ideally suitable for accent -, task-
and decorative lighting in homes,
shops and hotels/restaurants.
Ilcos
life
code
h
HRGI-20-12-GU5.3-50/10
HRGI-35-12-GU5.3-50/10
HRGI-50-12-GU5.3-50/10
HRGI-20-12-GU5.3-50/36
HRGI-35-12-GU5.3-50/36
HRGI-50-12-GU5.3-50/36
HRGI-50-12-GU5.3-50/60
ACCENTline
Ordering
EOC
number
9240 475 17100
412089
9240 477 17100
412119
9240 479 17100
412140
9240 476 17100
412171
9240 478 17100
412201
9240 480 17100
412232
9240 518 17100
426086
