Related Manuals for Smeg DSP1
Summary of Contents for Smeg DSP1
- Page 1 Instruction Manual Microwave Gebrauchsanweisung Mikrowelle Руководство по эксплуатации Микроволновой...
- Page 2 The user manual is also available for download at www.smeg.com Sehr geehrter Kunde, Danke dass Sie sich für dieses SMEG Gerät entschieden haben. Wir bitten Sie, die in diesem Heft enthaltenen Anweisungen aufmerksam durchzulesen,die helfen Ihnen, bei der Nutzung Ihres Gerätes die besten Ergebnisse zu erzielen.
-
Page 3: Table Of Contents
Contents 1. Instructions ............................. 4 1.1. Safety Information ........................4 1.2. Disposal ............................ 9 1.3. This user manual ........................9 1.4. How to read the user manual ....................9 2. Description ............................ 10 2.1. General Description....................... 10 2.2. Control Panel ......................... 11 2.3. -
Page 4: Instructions
Instructions 1.1. Safety Information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. CHILDREN AND VULNERABLE PEOPLE SAFETY Warning! Risk of suffocation, injury or permanent disability. - Page 5 Instructions Only use utensils that are suitable for use in microwave ovens. When heating food in plastic or paper containers, keep an eye on the appliance due to the possibility of ignition. The appliance is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
- Page 6 Instructions For toasting, use just the grilling function and watch the oven all the time. It you use a combined function to toast bread it will catch fire in a very short time. Make sure you never catch the power cables of other electrical appliances in the hot door or the oven.
- Page 7 Instructions Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass door since they can scratch the surface, which may result in shattering of the glass. The door contact surfaces (the front of the cavity and the inside part of the doors) must be kept very clean in order to ensure the oven functions correctly.
- Page 8 Instructions Do not cover or obstruct the ventilation openings. Use only dishes suitable for microwaves. Before using dishes and containers in the microwave, check that these are suitable (see the section on types of dishes). Never remove the mica cover on the ceiling of the oven interior! This cover stops fat and pieces of food damaging the microwave generator.
-
Page 9: Disposal
Instructions 1.2. Disposal 1.4. How to read the user manual This user manual uses the following reading Eliminating the packaging conventions: The packaging carries the Green Dot. Use the right bins when discarding all of the packaging Instructions materials, such as the cardboard, styrene and plastic films. -
Page 10: Description
Description 2.1. General Description 1. Catches 2. Door window glass 3. Drop-down grill 4. Ceramic base 5. Control panel 10 / EN... -
Page 11: Control Panel
Current time / Duration display (From now on, for convenience it will be referred to (From now on, for convenience it will be referred to as DSP1.) as PT2.) This display shows the current time or the cooking This knob allows: duration. -
Page 12: Acessories
Description 2.3. Acessories Rack Some models are not provided with all accessories. Useful for grilling thin foods useful for grilling foods or other general uses. 2.4. Description of functions The table below provides a short description of the functions available. Microwaves Defrost by time Microwaves + grill... -
Page 13: Use
3.1. Advantages of the microwave oven In a conventional cooker, the heat that is radiated The friction between the molecules generates through the resistances or gas burners slowly heat, which raises the temperature of the foods, penetrates the foods from outside defrosting or cooking them or keeping them hot. -
Page 14: Instructions
3.2. Instructions Grill function In the case of the grill function, the dish must be High temperature inside the resistant to temperatures of at least 250ºC. oven during use Plastic dishes are not suitable. Danger of fire or explosion Combined function ... - Page 15 The lid should have holes to avoid any type of Lids pressure from building up. Plastic bags should The use of glass or plastic lids or adherent film is also have openings. Baby bottles and baby food recommended, for the following reasons: jars and other similar containers must only be 1.
-
Page 16: First Use
It might become necessary to change the current Stand-by: activated as soon as the current time time, for example at the switch from summer to has been confirmed, with DSP1 on and showing winter time. To do this, start from the standby the current time setting (see “Operating modes”). -
Page 17: Cooking Functions
3.6. Cooking Functions Combination Microwave Combination cooking is a mix of traditional cooking and microwave Given that they penetrate directly into operation. the food, microwaves allow cooking to take place in a very short period of Microwave + Grill time and with a considerable saving of energy. -
Page 18: Special Functions And Automatic Programs
Traditional cooking functions 3.7. Special functions and automatic programs Grill Defrosting by time (manual) The heat coming from the grill element gives perfect grilling results above all for thin and medium thickness meat and allows you to give the food an even browning at the end of the cooking. - Page 19 1. After selecting this function, turn PT1 to the right or left to change the preset food type displayed 3. This pre-set time is indicated to cook handmade on DSP1. pizzas and frozen pizzas up to 26 cm diameter, with an approximate weight of 350g and whose 2.
-
Page 20: When The Oven Is Working
You can stop the cooking process at any time by DSP1 shows the current time and DSP 2 pressing the Start/Stop key once or by opening the shows “Auto”. oven door. In both cases: 2. -
Page 21: Secondary Menu
1. Activate or deactivate the Show Room function between 5-6 seconds, until the message OFF (which disables all the heating elements so that SHO appears on DSP1. This means that the only the control panel works); SHOW ROOM function (which disables all the 2. -
Page 22: Recommended Cooking Tables
situation is normal and may be more 3.10. Recommended cooking tables noticeable if the room temperature is low. The oven’s safe working is not affected by this. Cooking with Microwaves After you have finished cooking, clean up the water coming from the condensation ... - Page 23 Cooking vegetables Standing Quantity liquids Power Time Food Time Instructions (gr) Addition (min.) (min.) Cauliflower 100 ml 9-11 Cut into slices. Broccoli 50 ml Mushrooms 25 ml Keep covered. Peas, carrots 100 ml Cut into chunks or slices. Keep covered. Frozen 25 ml 8-10...
- Page 24 10. Turn the food whenever the oven lets out a the food is completely defrosted. beep and the DSP1 displays the word: The table below shows different defrosting and 11. Remove frozen food from its wrapping and do standing times (in order to ensure the food not forget to take off any metal twist-tags.
- Page 25 Cooking with the Grill Element For good results with the grill, use the rack 4. If the grill is used for extended period of time it supplied with the oven. is normal to find that the elements will switch themselves off temporarily due to the safety Fit the rack in such a way that it doesn’t come into thermostat.
- Page 26 Microwaves + Grill Element The microwave + grill function is ideal for cooking The microwave and the grill work simultaneously. quickly and, at the same time, browning foods. The microwave cooks and the grill toasts. Furthermore, you can also grill and cook cheese covered food.
-
Page 27: Cleaning And Maintenance
Cleaning and Maintenance Pour the product onto a damp cloth and wipe the 4.1. Instructions surface, rinse thoroughly and dry with a soft cloth High temperature inside the or a microfiber cloth. oven after use 4.4. Food stains and residues Danger of burns Do not use metallic sponges or sharp scrapers as ... -
Page 28: Extraordinary Maintenance
Cleaning and Maintenance Cleaning the cavity ceiling 4.6. Extraordinary maintenance If the oven ceiling is dirty, the grill can be lowered Occasionally, the oven will require minor servicing to make cleaning easier. procedures or the replacement of parts subject to wear and tear, such as gaskets, light bulbs, etc. -
Page 29: Installation
Installation When the oven is operating I can hear some 5.1. Electrical connection strange noises! Check if: The nameplate with the technical data, serial There is any electrical arcing inside the oven number and mark is in a visible position on the caused by foreign metallic objects (see oven door frame. -
Page 30: Installation Images
Installation Images/ Installations-Images / Установочные образы Push oven completely into the cabinet and centre it. Open microwave door and fasten the appliance to the cabinet using the four screws provided. Die Mikrowelle Nische einschieben entsprechend anpassen. Die Tür der Mikrowelle öffnen und das Gerät vier mitgelieferten... - Page 31 1730142-d...
