  • Page 1 EUM3006 Integrated Outdoor Modem Installation Guide APCD-LM048-1.1...
  • Page 2 Copyright © 2004 by WaveRider Communications Inc. You may copy and/or print as many copies of this manual as you wish, as long as the software license agreement and this copyright statement are included. Release 1.1, Dec. 2004 The following are trademarks or registered trademarks of their respective companies or organi-...
  • Page 3 Software License Agreement This is a legal agreement between you (either an individual or an entity) and WaveRider Communica- tions Inc. for the use of WaveRider computer software, hereinafter the “LICENSED SOFTWARE”. By using the LICENSED SOFTWARE installed in this product, you acknowledge that you have read this license agreement, understand it, and agree to be bound by its terms.
  • Page 4 WaveRider has been advised of the possibility of such damages, or for any claim by any other party.
  • Page 5 APCD-LM048-1.1...

  • Page 6: Table Of Contents

    4.3.4 Provide Power to the EUM3006 ........
  • Page 7 Appendix A Factory Configuration ........37 Appendix B Ethernet Cables and Connectors .

  • Page 8: Figures

    Grounding EUM3006 ........
  • Page 9 APCD-LM048-1.1...

  • Page 10: Tables

    Tables Table 1 MDB1000 Signal Strength FOMs ....... . 12 Table 2 MDB1000 Signal Quality LEDs .
  • Page 11 APCD-LM048-1.1...

  • Page 12: Preface

    Ethernet CAT-5E cable. Federal Communications Commission The EUM3006 has been designed and manufactured to comply with FCC Part 15. Operators must be familiar with the requirements of the FCC Part 15 Regulations prior to operating any link using this equipment. For installations outside the United States, contact local authorities for applicable regulations.
  • Page 13 Interference Environment on page xiii. The EUM3006 with its integrated antenna complies with these requirements, since the maximum average transmitting power is 25.8 dBm measured at the internal antenna port which is not accessible to the user. This is 4.2 dB below the maximum allowed, so the integrated, high-gain, active diversity antenna is allowed to provide an additional 4.2 dB gain...
  • Page 14 PoE Injector near or over a radiator, stove, heat register or other source of heat. Do not place the EUM3006 and PoE Injector in a built-in installation such as a bookcase or rack unless proper ventilation is provided. The EUM3006 has an outdoor temperature rating, so it can handle a much larger range of temperatures than the APCD-LM048-1.1...
  • Page 15 14. Ensure the system is properly grounded to provide some protection against voltage surges and built-up static charges. 15. Do not locate the EUM3006 in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall onto such power lines or circuits. When installing outdoors, take extreme care to keep from touching such power lines or circuits, as contact with them might be fatal.
  • Page 16 In other countries, use International Electrotechnical Commission (IEC) 364, part 1 through 7. 25. Ensure that the EUM3006 is properly grounded by attaching a grounding cable to the bolt marked “GND” on the back of the EUM3006. Art. 820-40 of the NEC (US)

  • Page 17: Figure 1 Grounding Eum3006

    Figure 1 Grounding EUM3006 Customer Support Telephone: +1 416–502–3161 Fax: +1 416–502–2968 Email: Customer Services Group: techsupport@waverider.com Customer Documentation Feedback and Comments: customerdocs@waverider.com URL: www.waverider.com WaveRider offers a complete training program. Please contact your sales representative for training information. xvii APCD-LM048-1.1...

  • Page 18: Introduction

    Connection between the end-user’s computer and the subscriber station is through an Ethernet port. The EUM3006 Integrated Outdoor Modem is the latest modem for the LMS4000 system and offers significant improvements: outdoor unit with extended temperature range; integrated, high-gain, active diversity antenna;...

  • Page 19: Eum3006 Features

    These manuals, as well as manuals for hardware elements, including EUMs and CCUs, can be found on WaveRider’s Web site (http://www.waverider.com). Other documents on the WaveRider web site are useful to assist in installing and operating the EUM3006. For example, you can find information on which roof and wall mounting brackets are recommended.

  • Page 20: Figure 1 Eum3006 Integrated Outdoor Modem

    Easy Outdoor Installation - The EUM3006 is tested to meet ETSI 300-019 environmental standards for outdoor installations, with an extended temperature range of -40º C to 50º C plus solar loading. The EUM3006 can also work in uninhabited indoor locations, such as attics, if there is an adequate RF signal. The advantages of an integrated outdoor unit include: •...
  • Page 21 • 48 VDC PoE - Using 48 VDC power allows the EUM3006 to have up to 100 m of Ethernet cable to the end-user’s PC, which is the maximum by the Ethernet standard. The PoE injector can be located anywhere along this 100 m of cable. This provides great flexibility in placing the EUM3006 to get the best RF signal.

  • Page 22: Eum3006 - End-User Modem Or Customer Premises Equipment

    The EUM3006 antenna is a high gain, active diversity antenna that ensures that the EUM3006 output power is at the maximum allowed by the FCC. The active diversity feature selects the best signal from horizontal and vertical polarizations on a per packet received basis.

  • Page 23: Ethernet Port

    The integrated antenna has a front-to-back ratio of more than 15 dB, which helps to suppress interference. 1.3.3 Ethernet Port The EUM3006 has a 10BaseT Ethernet RJ-45 connector at the end of 25 feet of CAT-5e outdoor Ethernet cable. This makes installation much easy and robust, since this length is APCD-LM048-1.1...

  • Page 24: Power Over Ethernet (Poe) Injector

    Appendix B on page There is great latitude available in locating the EUM3006 and routing the Ethernet cable, since up to 330 feet (100 m) of Ethernet cable can be used between the EUM3006 and the end- user’s computer, router or Ethernet switch.

  • Page 25: Poe Lightning Arrestor

    B PoE power, in lieu of the supplied PoE Injector. 1.3.5 PoE Lightning Arrestor A PoE lightning arrestor (not supplied) is used with the EUM3006 if required by the local building code and/or the EUM3006 is being installed in an area subject to direct or indirect lightning induced surges.

  • Page 26: Mdb1000

    The MDB1000 comes with a belt clip and two velcro straps, a short one to attach the MDB1000 to your wrist or forearm and a longer one to attach to the EUM3006 itself or the pole mount. So long as the MDB1000 is within 4 inches of the EUM3006, it picks up the magnetic signal sent by the EUM3006.

  • Page 27: Turning The Mdb1000 On

    2: MDB1000 It is recommended that the batteries be tested before starting the installation. Keeping a spare set of batteries with the installation tools may save you a trip down ladders, etc. to get new batteries. The AA batteries fit into the MDB1000 by removing the battery cover at the back of MDB1000, removing the old batteries, and inserting the new ones.

  • Page 28: Turning The Mdb1000 Off

    Turning the MDB1000 Off The MDB1000 automatically shuts off if it is out of range of the EUM3006 for more than 60 seconds. You can tell if the MDB1000 is out of range, since the MODEM LED will go out as well as all of the signal performance indicator LEDs.

  • Page 29: Table 1 Mdb1000 Signal Strength Foms

    These 5 LEDs have two interpretations, depending on the state of the EUM3006 if the MODEM LED is on. 1. A rotating pattern of LEDs shows that the EUM3006 is in Auto CCU Discovery mode. 2. When a CCU has been found, the Signal Quality LEDs indicate the figure of merit for a blend of quality indicators, including the carrier phase error and the signal to noise ratios for each antenna pattern.

  • Page 30: Table 2 Mdb1000 Signal Quality Leds

    EUM3006. The goal should be a signal strength of 5 or higher and a signal quality of 4 or 5. Regardless of the levels, the EUM3006 should be aligned so that the indicators are the highest possible for the given site.
  • Page 31 2: MDB1000 APCD-LM048-1.1...

  • Page 32: Setup Menu

    Setup Menu The EUM3006 is equipped with a simple setup menu through which you can monitor the RF link quality and view the key parameters of the modem. Accessing the Setup Menu The setup menu is accessed by connecting a Telnet session to the ‘local link’ IP address of the EUM3006, 169.254.10.250, with password = ‘setup’.

  • Page 33: Setup Menu

    Setup Menu The Setup Menu structure consists of a menu with four selections. Setup Menu WaveRider Communications, Inc. EUM3005 Password: ***** WaveRider Communications Inc. Setup Menu Modem Serial Number : C00017 Station Identifier (EUM ID): 40:00:17 Software Version : 10.0...
  • Page 34 3: Setup Menu • searching for a CCU - A complete sweep of all frequencies takes about 30 seconds. The display shows which frequencies may be CCUs. A search is started when any of the following occurs: • the modem boots up, either due to a hard (power) reset or software reset, •...

  • Page 35: Troubleshooting Information Display

    The information provided below is a brief description of the statistics provided. A detailed understanding of this information is not required to install the EUM3006. If there are problems with the installation, then the installer may contact the network operator and report the information on this display so that the network operator can troubleshoot the installation.
  • Page 36 3: Setup Menu The MAC Summary shows the breakdown for transmitted and received packets and payloads. All values are expressed as a count and percentage of total packets or payloads. A payload is a packet with real data. • Transmitted Payloads: shows how many payloads were successfully transmitted the 1st time or needed to be sent a 2nd, 3rd or 4th time to get through, as well as how many packets failed to get through at all.
  • Page 37 3: Setup Menu APCD-LM048-1.1...

  • Page 38: Installation

    4.2.3, Verifying the EUM3006 Components The end-user’s PC requires an Ethernet Network section 4.2.4, End-Users PC Interface to accept the data from the EUM3006. When everything is ready for the installation stage, then the installer performs the following steps: APCD-LM048-1.1...

  • Page 39: Table 4 Installation Stage Checklist

    4: Installation Table 4 Installation Stage Checklist Step Discussion Find the best location for mounting the EUM3006, with a section 4.3.1, Locating the good RF signal and at least 1 foot away from where EUM3006 people will stand. The EUM3006 mounts to a vertical pole with a diameter between 1 and 3.0 inches.

  • Page 40: Pre-Installation Steps

    If for some reason this is not acceptable, then the EUM3006 must be configured with its radio frequency. The easiest installation uses the EUM3006 factory defaults, so that the modem will gets all its IP address information from DHCP and its RF Frequency from the Auto CCU Discovery feature.

  • Page 41: Verifying The Eum3006 Components

    4.2.3 Verifying the EUM3006 Components Verify that the EUM3006 kit is complete with: • EUM3006 modem with integrated antenna and 25 feet of CAT-5e Ethernet Cable. • Attaching plate with 4 bolts and lock washers •...

  • Page 42: Installation Steps

    • If the signal levels are weak, the EUM3006 may need to be located on the roof and eventually on a pole above the roof that has good line of sight to the CCU. If you have no idea what signal levels are expected at your site, it is suggested that you climb to a high point (e.g.

  • Page 43: Mounting The Eum3006

    Once a good location for the modem has been selected, you need to provide a pole or pipe to which the EUM3006 can be attached. This can be any pole from 1” to 3.0” diameter. If the pole is vertical, it is easy to rotate (pan) the modem for the final alignment. The longitudinal axis must be vertical or horizontal only.
  • Page 44 Ensure that the modem will not rotate around the pole when reasonable force is applied. Avoid pressing on the radome, push on the cast base instead. Provide a drip-loop for Ethernet cable and grounding conductor from EUM3006 to pole (see Figure 5 Figure 6).

  • Page 45: Figure 5 Eum3006 Mounting - Vertical Orientation

    4: Installation TOP Marking Ground Connection and GND Marking Gear Clamps Ethernet Port Drip Loops Figure 5 EUM3006 Mounting - Vertical Orientation APCD-LM048-1.1...

  • Page 46: Running Cables

    If a PoE lightning arrestor is used, it must also be grounded through the building’s Power Service Grounding Electrode System. The Ethernet cable from the EUM3006 is attached to the external port of the lightning arrestor and a straight-through Ethernet cable is attached to the other port.

  • Page 47: Provide Power To The Eum3006

    7, is provided with every EUM3006. Locate it in a convenient location that has access to an AC plug and the Ethernet cable that runs to the EUM3006. If a Lightning Arrestor is used, the PoE Injector must be located on the protected side of the lightning arrestor.

  • Page 48: Connecting The End-User's Pc

    4: Installation 4.3.5 Connecting the End-User’s PC There are many ways to connect the EUM3006 to the end-user’s PC, using Ethernet switches, IP routers, etc. The discussion below is for the simplest, most direct method of connection, using the provided PoE Injector.

  • Page 49: Testing The Data Link

    This test verifies that the end-user’s PC is communicating with the EUM3006 and provides insight into the state of the RF link. This test is recommended even if the modem was aligned using the MDB1000, since it provides more details on the state of the modem and what CCU(s) it has located.
  • Page 50 4: Installation Ping the EUM Note that the EUM3006 may be on a different sub-net than the end-user’s PC, so pinging the IP address assigned to the EUM3006 will go through the CCU. Therefore, we ping the EUM3006 using the local link IP address as the 1st test.
  • Page 51 4: Installation This is what an unsuccessful ping from the end-user’s PC to the EUM looks like: C:\>ping 169.254.10.250 Pinging 169.254.10.250 with 32 bytes of data: Request timed out. Request timed out. Request timed out. Request timed out. Ping statistics for 169.254.10.250: Packets: Sent = 4, Received = 0, Lost = 4 (100% loss), Approximate round trip times in milli-seconds: Minimum = 0ms, Maximum =...
  • Page 52 4: Installation NOTE: If this test fails with the long packets, but pinging the Gateway with the default packet size succeeds, then the connection is working but is not operating at maximum capacity, possibly due to poor antenna placement or orientation, poor signal levels, and/ or interference.

  • Page 53: Post-Installation

    Minimum = 68ms, Maximum = 76ms, Average = 71ms Post-Installation Once a good link between the CCU and the EUM3006 has been established, the configuration can be completed automatically using the Automatic Remote Configuration feature with a RADIUS Server and database in which the EUM3006 information has been entered. The network operator must update the RADIUS database for the new modem.

  • Page 54: Appendix A Factory Configuration

    Appendix A Factory Configuration This appendix identifies the factory configuration settings for the EUM3006 Integrated Outdoor Modem Parameter Default Configuration Modem IP Address From DHCP Modem IP Netmask From DHCP Gateway IP Address From DHCP Local Link IP Address 169.254.10.250...
  • Page 55 (NOTE: For configuring the modem, the power values entered are rounded to the nearest dB) SNMP Name* (= Console Prompt) EUMID SNMP Contact* WaveRider Communications Ltd. SNMP Location* www.waverider.com SNMP Read Communities* None entered SNMP Write Communities* None entered...

  • Page 56: Appendix B Ethernet Cables And Connectors

    Ethernet cable can be used to provide extended distances. • If the EUM3006 is to be connected to a router or Ethernet Switch that do not provide PoE, then a straight-through Ethernet cable is used to connect the router or switch to the PoE injector.

  • Page 57: Table 6 Ethernet Interface Specifications

    Appendix B: Ethernet Cables and Connectors Table 6 Ethernet Interface Specifications EUM Physical Interface 25 foot CAT-5e (Ethernet) cable with RJ45 connector Power over Ethernet 802.3af Compliant Mode B PoE at 48 VDC Wiring standard TIA - T568A - Pair/Wire - Color Pin 1 - 3/a - Green/White TX Data + (Output from EUM)

  • Page 58: Figure 8 T568A Wiring

    Appendix B: Ethernet Cables and Connectors Straight-through Ethernet cables have T568A wiring at both ends while Cross-over cables have T568A at one end and T568B at the other end. T 5 6 8 A W irin g S c h e m e P a ir 2 P a ir 3 P a ir 1...
  • Page 59 Appendix B: Ethernet Cables and Connectors APCD-LM048-1.1...

  • Page 60: Appendix C Acronyms And Abbreviations

    Appendix C Acronyms and Abbreviations Table 8 Acronyms and Abbreviations Acronym or Definition Abbreviation 1st packet sent okay 2nd packet sent okay (i.e. 1 retry) 3rd packet sent okay (i.e. 2 retries) 4th packet sent okay (i.e. 3 retries) Alternating Current ANSI American National Standards Institute American Wire Gauge/Gage...
  • Page 61 Appendix C: Acronyms and Abbreviations Acronym or Definition Abbreviation Ethernet End-user Modem Failed (as in packets that failed to be transmitted) Federal Communications Commission (U.S.A.) Frame Check Sequence Figure Of Merit HCRC Header Cyclical Redundancy Check Hardware Industry Canada Identifier, Identification Internet Protocol Light-Emitting Diode Last Mile Solution®...
  • Page 62 Appendix C: Acronyms and Abbreviations Acronym or Definition Abbreviation Signal Quality Transmission Control Protocol Telecommunications Industry Association Time To Live Transmit Underwriters Laboratory Volts Direct Current APCD-LM048-1.1...
  • Page 63 Appendix C: Acronyms and Abbreviations APCD-LM048-1.1...

  • Page 64: Index

    Index ........... abbreviations .
