- Page 1 Netw ork Bullet Camera Quick Operation Guide ...
- Page 2 Network Bullet Camera·Quick Operation Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual applies to the following models. Model Model HNC301‐VB HNC303‐VB This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual. DISCLAIMER STATEMENT “Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950‐1. UL Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT. 0501001031101 ...
- Page 3 Network Bullet Camera·Quick Operation Guide Regulatory Information FCC Information FCC compliance: This eq uipment has been tested and found to comply with the limits for a digital device, purs uant to part 15 of the FCC Rules. The se limits ar e designed to provide reasonab le protection agains t harm ful interference when the equip ment is operated in a commercial environment. This equipment ge nerates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to rad communications. Operation of this equipment in a residential are is likely to cause harmful interf ence in which a case the user will be required to correct the interference at his own expense. FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference.
- Page 4 Network Bullet Camera·Quick Operation Guide municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. 2006/66/EC (battery directive): This produc t contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.r ecyclethis.info ...
- Page 5 Network Bullet Camera∙Quick Operation Guide Safety Instru ction These instruction s are intended to ensure that user can use the product correctl y to avoid danger or property loss. The precaution m easure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are negl ected. Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent potential injury or material serious injury or death. damage. Warnings In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950‐1 standard. Please refer to technical specifications for detailed information. ...
- Page 6 Network Bullet Camera∙Quick Operation Guide Do not connect seve ral devices to one power adapter as adapter overload may cause over‐heating or a fire hazard. Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. If smoke, o dor or noise rise from the device, turn off the power at once and unplug the power cable, and then please conta ct the service center. Cautions Make sure the p ower supply voltage is correct be re using the camera. Do not drop the camera or s ubject it to physical shoc k. Do not touch sensor mo dule s with fingers. If cleaning is necessary, use clean cloth w ith a bit of et hanol and wipe it gently. If the camera will not be used for an extended period, please replace the lens cap to protect the sensor from dirt. not aim the ca mera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time. ...
- Page 7 Network Bullet Camera∙Quick Operation Guide Do not place the camera in extremely hot, cold (the opera ting temperature shall be‐30 ~+60 ,or ‐40°C ~ 60°C if the cam era model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation. To avoid heat accumulation, good ventilation is required for operating environment. Keep the camera away from liquid while in use. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ar part re acement: a few parts (e.g. electrolytic capaci tor) of the equipment shall be replaced regularly according to their average enduring time. The average time varies because of differences between operating environment and using history, so regular checking is recommended for all the users. Please contact with your dealer for more deta ils. Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any respon sibility for problems caused by unauthorized repair or maintenance.) ...
- Page 8 Network Bullet Camera∙Quick Operation Guide Table of Contents 1 Appearance Description ............... 2 Installation ................. 10 3 Setting the Network Camera over the LAN ......... 15 4 Accessing via Web Browser ............ 20 ...
- Page 9 Network Bullet Camera∙Quick Operation Guide 1 Appearance Description Two types of camera interfaces are shown in Figure 1‐1 and Figure 1‐2. Choose the right figure according to your purchased product. Figure 1‐1 Overview Figure 1‐2 Overview Table 1‐1 Physical Description No. Description 1 10M/100M Self‐adaptive Ethernet Interface ...
- Page 10 Network Bullet Camera∙Quick Operation Guide No. Description 2 Power Supply Interface 3 IN, G: Alarm input interface 1A, 1B: Alarm output interface 4 D+, D‐: RS‐485 interface 5 AUDIO IN, G: Audio input interface AUDIO OUT, G: Audio output interface ...
- Page 11 Network Bullet Camera∙Quick Operation Guide 2 Installation Befor e you start: Make sure the device i n the package is in good conditio n and all the assembly parts are included. ke sure all the related equipment is power‐off du ring the talla tion. Check the specifica tion of the products for the installation environment. Make sure the power supply is matched with your required voltage to avoid damage. If the product does not function properly, please contact your dealer or the nearest service center. Do not disassemble the camera for repair or maintenance by yourself. Make sure that the wall is strong enough to withstand three times the weight of the camera. For the camera that supports IR, you are required to pay attention to the following precautions to prevent IR reflection: Dust or grease on the dome cover will cause IR reflection. Please do not remove the dome cover film until the installation is finished. If there is dust or grease on the dome cover, clean the dome cover with clean soft cloth and isopropyl alcohol. ...
- Page 12 Network Bullet Camera∙Quick Operation Guide Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera may reflect back into the lens causing reflection. The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS. Fasten the dome cover to came ra body so that the foam ring and the dome cover are attached seamlessly. Steps: 1. Fix the mounting base to the wall. Mounting base Figure 2‐1 Fix the Mounting Base 2. Fix the mounting bracket with the camera to the mounting base. The “bottom” mark on the mounting base should align with the “bottom” mark on the mounting bracket. ...
- Page 13 Network Bullet Camera a ∙Quick Operation Guide Figure 2‐2 Fix x the Camera 3. View the image of the camera o ver the network. 4. Loosen the screws on the bracke et slightly. Please loosen the screws slightly y until you can adjust the camera and do not remove the screws fr rom the bracket. 5. Adjust the camera to the desired d surveillance angle and then tighten the screws on bracket to o fix the camera. Panning screw Rotation screw Tilting screw Figure 2‐3 Adjust Monitoring Angle ...
- Page 14 Network Bullet Camera∙Quick Operation Guide 6. Loosen the lock screw on the sun shield and move the sun shield until you can re move it. Rem ove the sun shield. Figure 2‐4 Remove the Sun Shield 7. Rotate to remove the front cover from cam era and adjust the lens to get a clear image. Adjust the lens Front Cover Figure 2‐5 Adjust the Lens ...
- Page 15 Network Bullet Camera∙Quick Operation Guide 8. Fix the lens; reinstall the front cover and the sun shield to finish the installation. Reinstall the front cover until aligning the mark on the front cover with the mark on the camera. Figure 2‐6 Complete the Installation ...
- Page 16 Network Bullet Camera∙Quick Operation Guide 3 Set ing the Network Camera over the AN Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or PCNVR software to search and change the IP of network camera. The following figure shows the cable connection of network camera and PC: Figure 3‐1 Wiring over LAN Set the IP address of the camera for accessing via LAN. Steps: 1. To get the IP address, you can choose either of the following methods: Use SADP, a software tool which can automatically detect network camera in the LAN and list the device information like IP address, subnet mask, port number, device serial number, device version, etc., shown in 0. ...
- Page 17 Network Bullet Camera∙Quick Operation Guide Use PCNVR software and to list the online devices. Please refer to the user manual of PCNVR client software for detailed inform ation. 2. Change the IP address and subnet mask to the same subnet as of your PC. Refer to the following introductions to set IP address with SADP software: Search active devices online Search online device s automatically: After launch the SADP software, it automatically searches the online devices every 15 seconds from the subnet where your computer locates. It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device type, IP address, port number, gateway, etc. will be displayed. ...
- Page 18 Network Bullet Camera∙Quick Operation Guide Figure 3‐2 Search Online Devices Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device list manually. The newly searched devices will be added to the list. ...
- Page 19 Network Bullet Camera∙Quick Operation Guide You can click on each column heading to order the informat ion; can c lick to show the device table and hide the netwo k para ter panel on the right side, or click sho w the ne ork par ameter panel. Modify device information Steps: Select the device to be modified in the device list as shown in Figure 3‐3. The network parameters of the device will be displayed in the Modify Network Paramete rs panel on the right side as shown in Figure 3‐4. Edit the modifiable network parameters, e.g. IP address and port number. Enter the password of the admin account of the device in the assword field and click Save to save the changes. ...
- Page 20 Network Bullet Camera∙Quick Operation Guide Figure 3‐4 Modify Network Parameters 3. Enter the IP addr ess of network camera in the address field of the web browser to view the live video. The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”. For accessing the network camera from different subnets, please set the gateway for the network camera after you log in. ...
- Page 21 Network Bullet Camera∙Quick Operation Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version Steps: 1. Open the web browser. 2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3. Input the user name and password. Click Login. ...
- Page 22 Network Bullet Camera∙Quick Operation Guide Figure 4‐1 Login Interface 5. Inst all the plug‐in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug‐in. You may have to close the web browser to finish the installation of the plug‐in. ...
- Page 23 Network Bullet Camera∙Quick Operation Guide Figure 4‐2 Download Plug‐in Figure 4‐3 Install Plug‐in (1) ...
- Page 24 Network Bullet Camera∙Quick Operation Guide Figure 4‐4 Install Plug‐in (2) 6. Re open the web browser after the installation of the plug‐in and repeat steps 2‐4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera. ...
- Page 25 Network Bullet Camera a∙Quick Operation Guide ...
