  • Page 1 PRIME X299-Deluxe Series...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... vi About this guide ......................vii PRIME X299-DELUXE specifications summary ............ix Package contents ...................... xv Installation tools and components ................. xvi Chapter 1: Product Introduction Motherboard overview ................1-1 1.1.1 Before you proceed ..............1-1 1.1.2 Motherboard layout ..............
  • Page 4 3.6.13 PCH-FW Configuration ............. 3-20 Monitor menu ................... 3-20 Boot menu ....................3-20 Tool menu ....................3-22 3.9.1 ASUS EZ Flash 3 Utility ............3-22 3.9.2 Secure Erase ................3-23 3.9.3 ASUS Overclocking Profile ............3-24 3.9.4 ASUS SPD Information ............. 3-24 3.9.5...
  • Page 5 Virtual Raid on CPU in UEFI BIOS ........4-6 ® 4.1.5 Intel Rapid Storage Technology Option ROM utility ....4-12 ® Creating a RAID driver disk ..............4-16 4.2.1 Creating a RAID driver disk in Windows ......... 4-16 ® Appendix Notices ........................A-1 ASUS contact information ..................A-8...

  • Page 6: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 7: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 8: Conventions Used In This Guide

    Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 9: Prime X299-Deluxe Specifications Summary

    Core™ X-Series Processors Family on LGA 2066 Socket* ® Supports 14nm CPU Supports Intel Turbo Boost Max Technology 3.0** ® * Refer to www.asus.com for Intel CPU support list. ® ** Support of these features depends on the CPU types. Intel X299 Chipset Chipset ®...
  • Page 10 PRIME X299-DELUXE specifications summary Intel X299 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage ® Technology 15 support - 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE 3.0 x4 mode) - 1 x M.2_2 Socket 3 with vertical M Key, type 2242/2260/2280/22110 (supports PCIe storage device only)* - 1 x U.2 connector (supports PCIe 3.0 x4 NVM Express storage)*...
  • Page 11 - File Transfer <EZ DIY> OLED with ASUS LiveDash Utility Q-Design - ASUS Q-Code - ASUS Q-Connector - ASUS Q-DIMM - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Shield - ASUS Q-Slot (continued on the next page)

  • Page 12: Special Features

    - Protect your graphics card Investment ASUS 5X Protection III - ASUS SafeSlot Core - Fortified PCIe with solid soldering - ASUS LANGuard - Protects against LAN surges, lightning strikes and static-electricity discharges! - ASUS Overvoltage Protection - World-class circuit-protecting power...
  • Page 13 1 x RGB header 1 x Addressable header 1 x Front panel audio connector (AAFP) 1 x VROC_HW_KEY 1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX 3 support 1 x System Panel connector (Q-Connector) 1 x 3-pin CPU_OV header 1 x Q_Code...
  • Page 14 8-channel Audio I/O ports 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ BIOS Features Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.

  • Page 15: Package Contents

    3 x Thermistor cables 1 x miniDP to DP cable Cables 1 x ThunderboltEX 3 GPIO cable 1 x ASUS 2T2R dual band Wi-Fi moving antenna (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x ASUS Wi-Fi 802.11ad(WiGig) moving antenna (available in certified countries)

  • Page 16: Installation Tools And Components

    Installation tools and components Intel ® LGA 2066 CPU Intel LGA 2066 compatible CPU Fan ® Phillips (cross) screwdriver SATA hard disk drive PC chassis DIMM 1 bag of screws Power supply unit SATA optical disc drive (optional) Graphics card M.2 SSD module (optional) The tools and components in the table above are not included in the motherboard package.

  • Page 17: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Product Introduction Motherboard overview 1.1.1 Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ASUS PRIME X299-DELUXE Series...

  • Page 18: Motherboard Layout

    1.1.2 Motherboard layout Refer to 1.1.9 Internal connectors and 2.3.1 Rear I/O connection for more information about rear panel connectors and internal connectors. Chapter 1: Product Introduction...

  • Page 19: Layout Contents

    14. Thermal sensor connector (2-pin T_SENSOR) 1-27 15. Thunderbolt header (5-pin TB_HEADER) 1-25 16. USB 2.0 connector (10-1 pin USB78) 1-21 17. VROC_HW_KEY connector (4-pin VROC_KEY) 1-30 18. Addressable RGB header (4-pin ADD_HEADER) 1-29 19. EZ XMP switch 1-11 20. MemOK! button 1-10 21. Clear CMOS button (CLR_CMOS) 1-11 22. Q-Code LEDs 1-14 23. Reset button 24. Power-on button 25. Front panel audio connector (10-1 pin AAFP) 1-19 26. LED connectors (13-pin LED_CON1; 8-pin LED_CON2) 1-27 ASUS PRIME X299-DELUXE Series...

  • Page 20: Central Processing Unit (Cpu)

    1.1.3 Central Processing Unit (CPU) The motherboard comes with a surface mount LGA2066 socket designed for the Intel ® Core™ X-series Processors. • Ensure that all power cables are unplugged before installing the CPU. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA2066 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. Chapter 1: Product Introduction...

  • Page 21: System Memory

    1.1.4 System memory The motherboard comes with eight DDR4 (Double Data Rate 4) Dual Inline Memory Modules (DIMM) slots. A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. Recommended memory configurations Intel Core™ X-series Processors (6-core or above) ® ASUS PRIME X299-DELUXE Series...

  • Page 22: Memory Configurations

    Core™ X-series Processors (4-core) ® Memory configurations You may install 2 GB, 4 GB, 8 GB and 16 GB unbuffered and non-ECC DDR4 DIMMs into the DIMM sockets. • For Inte Core™ X-Series Processors (4-core), you may install varying memory sizes l® in Channel C and Channel D. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation. • For Intel Core™ X-Series Processors (6-core or above), you may install varying ® memory sizes in Channel A, Channel B, Channel C, and Channel D. The system maps the total size of the lower-sized channel for the quad-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation. • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. • For system stability, use a more efficient memory cooling system to support a full memory load (8 DIMMs) or overclocking condition. • Always install the DIMMS with the same CAS Latency. For an optimum compatibility, we recommend that you install memory modules of the same version or data code (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • Visit the ASUS website for the latest QVL. Chapter 1: Product Introduction...

  • Page 23: Expansion Slots

    1.1.5 Expansion slots Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. Slot No. Slot Description PCIE 3.0/2.0 x16_1 slot PCIE 3.0/2.0 x1_1 slot PCIE 3.0/2.0 x16_2 slot PCIE 3.0/2.0 x16_3 slot PCIE 3.0/2.0 x1_2 slot PCIE 3.0/2.0 x16_4 slot ASUS PRIME X299-DELUXE Series...
  • Page 24 44-Lane CPUs PCI Express 3.0 operating mode VGA / PCIe Single VGA / Dual VGA / Triple VGA / configuration PCIe card PCIe cards PCIe cards x16 PCIe 3.0/2.0 x16_1 (single VGA recommended) PCIe 3.0/2.0 x16_2 PCIe 3.0/2.0 x16_3 PCIe 3.0/2.0 x16_4 28-Lane CPUs PCI Express 3.0 operating mode VGA / PCIe...

  • Page 25: Onboard Buttons And Switches

    1.1.6 Onboard buttons and switches Onboard buttons and switches allow you to fine-tune performance when working on a bare or open-case system. This is ideal for overclockers and gamers who continually change settings to enhance system performance. Power-on button The motherboard comes with a power-on button that allows you to power up or wake up the system. The button also lights up when the system is plugged to a power source indicating that you should shut down the system and unplug the power cable before removing or installing any motherboard component. Reset button Press the reset button to reboot the system. ASUS PRIME X299-DELUXE Series...
  • Page 26 MemOK! button lights continuously, press the MemOK! button until the DRAM_LED starts blinking. System will begin automatic memory compatibility tuning and reboot for successful boot. • Refer to section 1.1.8 Onboard LEDs for the exact location of the DRAM_LED. • The DRAM_LED also lights up when the DIMM is not properly installed. Turn off the system and reinstall the DIMM before using the MemOK! function. • The MemOK! button does not function under Windows OS environment. ® • During the tuning process, the system loads and tests failsafe memory settings. It takes about 30 seconds for the system to test one set of failsafe settings. If the test fails, the system reboots and tests the next set of failsafe settings. The blinking speed of the DRAM_LED increases, indicating different test processes. • Due to memory tuning requirement, the system automatically reboots when each timing set is tested. If the installed DIMMs still fail to boot after the whole tuning process, the DRAM_LED lights continuously. Replace the DIMMs with ones recommended in the Memory QVL (Qualified Vendors Lists) at www.asus.com. • If you turn off the computer and replace DIMMs during the tuning process, the system continues memory tuning after turning on the computer. To stop memory tuning, turn off the computer and unplug the power cord for about 5–10 seconds. • If your system fails to boot up due to BIOS overclocking, press the MemOK! button to boot and load the BIOS default settings. A message will appear during POST reminding you that the BIOS has been restored to its default settings. • We recommend that you download and update to the latest BIOS version from www.asus.com after using the MemOK! function. Chapter 1: Product Introduction 1-10...
  • Page 27 Clear CMOS button (CLR_CMOS) Press this button to clear the BIOS setup information only when the systems hangs due to overclocking. EZ XMP switch Enable this switch to overclock the installed DIMMs, allowing you to enhance the DIMM’s speed and performance. ASUS PRIME X299-DELUXE Series 1-11...

  • Page 28: Jumpers

    1.1.7 Jumpers CPU Over Voltage jumper (3-pin CPU_OV) The CPU Over Voltage jumper allows you to set a higher CPU voltage for a flexible overclocking system, depending on the type of the installed CPU. To gain more CPU voltage setting, insert the jumper to pins 2-3. To go back to its default CPU voltage setting, insert the jumper to pins 1-2. Chapter 1: Product Introduction 1-12...

  • Page 29: Onboard Leds

    1.1.8 Onboard LEDs POST State LEDs The POST State LEDs provide the status of these key components during POST (Power-On Self-Test): CPU, memory modules, VGA card, and hard disk drives. If an error is found, the critical component’s LED stays lit up until the problem is solved. EZ XMP LED (XLED1) This LED lights up when you enable the EZ XMP switch. ASUS PRIME X299-DELUXE Series 1-13...
  • Page 30 OLED panel This OLED panel provides you a quick overview of the system temperature, power status, and fan speeds when your system boots up. You can also upload a .gif file for a customized look. Use the ASUS LiveDash Utility to configure and customize the OLED panel. Q-Code LEDs The Q-Code LED design provides you with a 2-digit error code that displays the system status. Refer to the Q-Code table on the next page for details. Chapter 1: Product Introduction 1-14...
  • Page 31 CPU micro-code is not found or micro-code update is failed Internal CPU error Reset PPI is not available Reserved for future AMI error codes 5C – 5F S3 Resume is stared (S3 Resume PPI is called by the DXE IPL) S3 Boot Script execution Video repost OS S3 wake vector call Reserved for future AMI progress codes E4 – E7 S3 Resume Failed S3 Resume PPI not Found S3 Resume Boot Script Error S3 OS Wake Error Reserved for future AMI error codes EC – EF Recovery condition triggered by firmware (Auto recovery) Recovery condition triggered by user (Forced recovery) Recovery process started Recovery firmware image is found Recovery firmware image is loaded Reserved for future AMI progress codes F5 – F7 Recovery PPI is not available Recovery capsule is not found (continued on the next page) ASUS PRIME X299-DELUXE Series 1-15...
  • Page 32 Code Description Invalid recovery capsule Reserved for future AMI error codes FB – FF DXE Core is started NVRAM initialization Installation of the PCH Runtime Services CPU DXE initialization is started 63 – 67 PCI host bridge initialization System Agent DXE initialization is started System Agent DXE SMM initialization is started System Agent DXE initialization (System Agent module specific) 6B – 6F PCH DXE initialization is started PCH DXE SMM initialization is started PCH devices initialization PCH DXE Initialization (PCH module specific) 73 – 77 ACPI module initialization CSM initialization Reserved for future AMI DXE codes 7A – 7F Boot Device Selection (BDS) phase is started Driver connecting is started PCI Bus initialization is started PCI Bus Hot Plug Controller Initialization PCI Bus Enumeration PCI Bus Request Resources PCI Bus Assign Resources Console Output devices connect Console input devices connect...
  • Page 33 Legacy Option ROM Initialization System Reset USB hot plug PCI bus hot plug Clean-up of NVRAM Configuration Reset (reset of NVRAM settings) Reserved for future AMI codes B8– BF CPU initialization error System Agent initialization error PCH initialization error Some of the Architectural Protocols are not available PCI resource allocation error. Out of Resources No Space for Legacy Option ROM No Console Output Devices are found No Console Input Devices are found Invalid password Error loading Boot Option (LoadImage returned error) Boot Option is failed (StartImage returned error) Flash update is failed Reset protocol is not available ACPI/ASL Checkpoints (under OS) Code Description System is entering S3 sleep state System is entering S4 sleep state System is entering S5 sleep state System is waking up from the S3 sleep state System is waking up from the S4 sleep state System has transitioned into ACPI mode. Interrupt controller is in PIC mode. System has transitioned into ACPI mode. Interrupt controller is in APIC mode. ASUS PRIME X299-DELUXE Series 1-17...

  • Page 34: Internal Connectors

    1.1.9 Internal connectors Intel Serial ATA 6 Gb/s connectors (7-pin SATA6G_12; SATA 6G_34; ® SATA 6G_56; SATA 6G_7) These connectors connect to Serial ATA 6 Gb/s hard disk drives via Serial ATA 6 Gb/s signal cables. If you installed Serial ATA hard disk drives, you can create a RAID 0, 1, 5, and 10 configuration with the Intel Rapid Storage Technology through the onboard Intel ® ® X299 chipset. These connectors are set to [AHCI Mode] by default. If you intend to create a Serial ATA RAID set using these connectors, set the SATA Mode item in the BIOS to [Intel RST Premium With Intel Optane System Acceleration (RAID)]. Chapter 1: Product Introduction 1-18...
  • Page 35 Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports HD Audio. Connect one end of the front panel audio I/O module cable to this connector. We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. USB 3.1 Gen 2 front panel connector (U31G2_E5) This connector allows you to connect a USB 3.1 Gen 2 module for additional USB 3.1 Gen 2 ports. The latest USB 3.1 Gen 2 connectivity provides data transfer speeds of up to 10 Gbps. ASUS PRIME X299-DELUXE Series 1-19...
  • Page 36 USB 3.1 Gen 1 connectors (20-1 pin U31G1_12; U31G1_34) These connectors allow you to connect a USB 3.1 Gen 1 module for additional USB 3.1 Gen 1 front or rear panel ports. With an installed USB 3.1 Gen 1 module, you can enjoy all the benefits of USB 3.1 Gen 1 including faster data transfer speeds of up to 5 Gb/s, faster charging time for USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. The USB 3.1 Gen 1 module is purchased separately. • Ensure to install the related driver to fully use the USB 3.1 Gen 1 ports under Windows ® • The plugged USB 3.1 Gen 1 device may run on xHCI or EHCI mode depending on the operating system’s setting. Chapter 1: Product Introduction 1-20...
  • Page 37 USB 2.0 connector (10-1 pin USB78) This connector is for USB 2.0 ports. Connect the USB module cable to this connector, then install the module to a slot opening at the back of the system chassis. This USB connector complies with USB 2.0 specification that supports up to 480 Mb/s connection speed. ASUS PRIME X299-DELUXE Series 1-21...
  • Page 38 CPU, CPU optional, AIO pump, water pump+, extension, M.2, and chassis fan connectors (4-pin CPU_FAN; 4-pin CPU_OPT; 4-pin AIO_PUMP; 4-pin W_PUMP+; 4-pin M.2_FAN; 5-pin EXT_FAN; 4-pin CHA_FAN1-2) Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! • Ensure that the CPU fan cable is securely installed to the CPU fan connector. • The CPU_FAN connector supports the CPU fan of maximum 1A (12 W) fan power. • W_PUMP+ function support depends on water cooling device. • Connect the fan of your water cooling kit to the AIO_PUMP connector.
  • Page 39 ATX power connectors (24-pin EATXPWR; 8-pin EATX12V1; 4-pin EATX12V2) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • DO NOT connect the 4-pin power plug only, the motherboard may overheat under heavy usage. • Ensure to connect the 8-pin power plug, or connect both the 8-pin and 4-pin power plugs. • For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a minimum power of 350 W. • We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • If you want to use two or more high-end PCI Express x16 cards, use a PSU with 1000W power or above to ensure the system stability. ASUS PRIME X299-DELUXE Series 1-23...

  • Page 40: System Panel Connector

    System panel connector (20-3 pin PANEL) This connector supports several chassis-mounted functions. • System power LED (2-pin or 3-1 pin PLED) The 2-pin or 3-1 pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin HDD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The HDD LED lights up or flashes when data is read from or written to the HDD. • System warning speaker (4-pin SPEAKER) This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. • ATX power button/soft-off button (2-pin PWRSW) This connector is for the system power button. Pressing the power button turns the system on or puts the system in sleep or soft-off mode depending on the operating system settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF. • Reset button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. • Chassis intrusion connector (2-pin CHASSIS) This connector is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector. The chassis intrusion sensor or switch sends a high-level signal to this connector when a chassis component is removed or replaced. The signal is then generated as a chassis intrusion event. Chapter 1: Product Introduction 1-24...
  • Page 41 Thunderbolt header (5-pin TB_HEADER) This connector is for the add-on Thunderbolt I/O card that supports Intel’s Thunderbolt Technology, allowing you to connect up to six Thunderbolt-enabled devices and a DisplayPort-enabled display in a daisy-chain configuration. U.2 connector (U.2) This motherboard comes with a U.2 connector which supports PCIe 3.0 x4 NVM Express storage. The U.2 connector shares bandwidth with the M.2_2 socket . Adjust the BIOS settings to use U.2 devices. ASUS PRIME X299-DELUXE Series 1-25...
  • Page 42 M.2 sockets (M.2_1(Socket 3); M.2_2(Socket 3)) These sockets allow you to install M.2 SSD modules. • M.2_1 socket supports PCIe 3.0 x4 and SATA mode M Key design and type 2242 / 2260 / 2280 PCIe and SATA storage devices. • M.2_2 socket supports PCIe 3.0 x4 M Key design and type 2242 / 2260 / 2280 / 22110 PCIe storage devices. • These sockets support IRST (Intel Rapid Storage Technology). ® • The M.2_2 socket shares bandwidth with the U.2 connector. Adjust the BIOS settings to use U.2 devices. The M.2 SSD module is purchased separately. Chapter 1: Product Introduction 1-26...
  • Page 43 Thermal sensor connector (2-pin T_SENSOR1) This connector is for the thermistor cable that monitors the temperature of the devices and the critical components inside the motherboard. Connect the thermistor cable and place the sensor on the device or the motherboard’s component to detect its temperature. LED connectors (13-pin LED_CON1; 8-pin LED_CON2) These connectors connect are for connecting LED strips on your cover. ASUS PRIME X299-DELUXE Series 1-27...
  • Page 44 RGB header (4-pin RGB_HEADER) This connector is for RGB LED strips. The RGB header supports 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 2A (12V), and no longer than 2 m. Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. • Actual lighting and color will vary with LED strip. • If your LED strip does not light up, check if the RGB LED extension cable and the RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up under the operating system. • The LED strip is purchased separately. Chapter 1: Product Introduction 1-28...
  • Page 45 Addressable RGB header (4-pin ADD_HEADER) This connector is for individually addressable RGB WS2812B LED strips or WS2812B based LED strips. The addressable RGB header supports WS2812B addressable RGB LED strips (5V/Data/ Ground), with a maximum power rating of 3A (5V) and a maximum of 60 LEDs. Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. • Actual lighting and color will vary with LED strip. • If your LED strip does not light up, check if the addressable RGB LED strip is connected in the correct orientation, and the 5V connector is aligned with the 5V header on the motherboard. • The addressable RGB LED strip will only light up under the operating system. • The addressable RGB LED strip is purchased separately. ASUS PRIME X299-DELUXE Series 1-29...
  • Page 46 VROC_HW_KEY connector (4-pin VROC_KEY) This connector allows you to connect a KEY module to enable additional CPU RAID functions with Intel CPU RSTe. ® • The KEY module is purchased separately. • Due to CPU behavior, CPU RAID functions with Intel CPU RSTe only supports Intel ® ® Core™ X-series Processors (6-core or above) and Intel SSD modules. ® Chapter 1: Product Introduction 1-30...

  • Page 47: Chapter 2: Basic Installation

    2.1.1 Motherboard installation Install the ASUS Q-Shield to the chassis rear I/O panel. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’ rear I/O panel.
  • Page 48 Place nine screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT overtighten the screws! Doing so can damage the motherboard. Chapter 2: Basic Installation...

  • Page 49: Cpu Installation

    Please note the order in opening/ closing the double latch. Follow the instructions printed on the metal sealing hatch or the illustrations shown below in this manual. The plastic cap will pop up automatically once the CPU is in place and the hatch properly sealed down. ASUS PRIME X299-DELUXE Series...
  • Page 50 Triangle mark Triangle mark Chapter 2: Basic Installation...

  • Page 51: Cpu Heatsink And Fan Assembly Installation

    2.1.3 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan, if necessary. To install the CPU heatsink and fan assembly ASUS PRIME X299-DELUXE Series...

  • Page 52: Dimm Installation

    2.1.4 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 53: Atx Power Connection

    2.1.5 ATX power connection • DO NOT connect the 4-pin power plug only, the motherboard may overheat under heavy usage. • Ensure to connect the 8-pin power plug, or connect both the 8-pin and 4-pin power plugs. ASUS PRIME X299-DELUXE Series...

  • Page 54: Sata Device Connection

    2.1.6 SATA device connection Chapter 2: Basic Installation...

  • Page 55: Front I/O Connector

    USB 3.1 Gen 2 This connector will only fit in one orientation. Push the connector until it clicks into place. To install USB 3.1 Gen 1 connector To install USB 2.0 connector USB 3.1 Gen 1 USB 2.0 To install front panel audio connector AAFP ASUS PRIME X299-DELUXE Series...

  • Page 56: Expansion Card Installation

    2.1.8 Expansion card installation To install PCIe x16 cards To install PCIe x1 cards Chapter 2: Basic Installation 2-10...
  • Page 57 To install FAN EXTENSION CARD The illustrations in this section are for reference only. The motherboard layout may vary with models, but the installation steps are the same for all models. ASUS PRIME X299-DELUXE Series 2-11...
  • Page 58 To install ThunderboltEX 3 card The illustrations in this section are for reference only. The motherboard layout may vary with models, but the installation steps are the same for all models. Chapter 2: Basic Installation 2-12...

  • Page 59: M.2 Installation

    2.1.9 M.2 installation Supported M.2 type varies per motherboard. ASUS PRIME X299-DELUXE Series 2-13...

  • Page 60: Wi-Fi Antenna Installation

    2.1.10 Wi-Fi antenna installation Installing the ASUS 2T2R dual band W-Fi and ASUS Wi-Fi 802.11ad(WiGig) antenna Connect the bundled ASUS 2T2R dual band Wi-Fi antenna connector to the top two Wi-Fi ports at the back of the chassis, then connect the Wi-Fi 802.11ad(WiGig) antenna to the bottom Wi-Fi port. ASUS 2T2R dual band W-Fi antenna ASUS Wi-Fi 802.11ad(WiGig) antenna...

  • Page 61: Bios Update Utility

    BIOS Flashback is not operating properly. This may be caused by improper installation of the USB storage device and filename/file format error. If this scenario happens, please restart the system to turn off the light. • Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service Center. ASUS PRIME X299-DELUXE Series 2-15...

  • Page 62: Motherboard Rear And Audio Connections

    Motherboard rear and audio connections 2.3.1 Rear I/O connection Rear panel connectors USB BIOS Flashback button USB 3.1 Gen 2 Type-A port E2 Wi-Fi 802.11 a/b/g/n/ac/ad, USB 3.1 Gen 1 ports E34 Bluetooth V4.2 ports Intel LAN port (LAN2)* USB 3.1 Gen 1 ports E2_5 ® Intel LAN port (LAN1)* USB 3.1 Gen 2 Type-C™ port EC1 ® USB 2.0 ports 9-12 (bottom port Optical S/PDIF Out port supports USB BIOS Flashback) USB 3.1 Gen 2 Type-A ports E34 Audio I/O ports** * and ** : Refer to the tables on the next page for LAN port LEDs and audio port definitions. •...
  • Page 63 Front Speaker Out Front Speaker Out Front Speaker Out Pink Mic In Mic In Mic In Mic In Orange – – Center/Sub Center/Sub woofer woofer Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out ASUS PRIME X299-DELUXE Series 2-17...

  • Page 64: Audio I/O Connections

    2.3.2 Audio I/O connections Audio I/O ports Connect to Headphone and Mic Connect to Stereo Speakers Connect to 2 Speakers Chapter 2: Basic Installation 2-18...
  • Page 65 Connect to 4 Speakers Connect to 6 Speakers Connect to 8 Speakers ASUS PRIME X299-DELUXE Series 2-19...

  • Page 66: Starting Up For The First Time

    Starting up for the first time After making all the connections, replace the system case cover. Ensure that all switches are off. Connect the power cord to the power connector at the back of the system chassis. Connect the power cord to a power outlet that is equipped with a surge protector. Turn on the devices in the following order: Monitor External SCSI devices (starting with the last device on the chain)

  • Page 67: Chapter 3: Bios Setup

    BIOS Setup Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 68: Bios Setup Program

    RTC RAM via the Clear CMOS button. • The BIOS setup program does not support the Bluetooth devices. Please visit ASUS website for the detailed BIOS content manual. BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.

  • Page 69: Ez Mode

    Click to go to Advanced mode Loads optimized Search on the FAQ default settings Click to display boot devices Selects the boot device priority The boot device options vary depending on the devices you installed to the system. ASUS PRIME X299-DELUXE Series...

  • Page 70: Advanced Mode

    3.2.2 Advanced Mode The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To switch from EZ Mode to Advanced Mode, click Advanced Mode(F7) or press the <F7> hotkey.

  • Page 71: Menu Bar

    This button above the menu bar allows you to view and tweak the overclocking settings of your system. It also allows you to change the motherboard’s SATA mode from AHCI to RAID mode. Refer to section 3.2.4 EZ Tuning Wizard for more information. ASUS PRIME X299-DELUXE Series...

  • Page 72: Hot Keys

    Move your mouse over this button to show a QR code, scan this QR code on your mobile device to connect to the BIOS FAQ web page of the ASUS support website. You can also scan the following QR code: Hot keys This button above the menu bar contains the navigation keys for the BIOS setup program.

  • Page 73: Qfan Control

    Click to activate DC Mode configured PWM Mode Select a profile to apply to Click to apply the fan setting your fans Click to undo the Click to go back to main menu changes Select to manually configure your fans ASUS PRIME X299-DELUXE Series...
  • Page 74 Configuring fans manually Select Manual from the list of profiles to manually configure your fans’ operating speed. Speed points Select to manually configure your fans To configure your fans: Select the fan that you want to configure and to view its current status. Click and drag the speed points to adjust the fans’...

  • Page 75: Ez Tuning Wizard

    To start OC Tuning: Press <F11> on your keyboard or click from the BIOS screen to open EZ Tuning Wizard screen. Click OC then click Next. Select a PC scenario Daily Computing or Gaming/Media Editing, then click Next. ASUS PRIME X299-DELUXE Series...

  • Page 76: Creating Raid

    Select a Main Cooling System BOX cooler, Tower cooler, Water cooler, or I’m not sure, then click Next. After selecting the Main Cooling System, click Next then click Yes to start the OC Tuning. Creating RAID To create RAID: Press <F11> on your keyboard or click from the BIOS screen to open EZ Tuning Wizard screen.
  • Page 77 After selecting the type of RAID, click Next then click Yes to continue the RAID setup. After the RAID setup is done, click Yes to exit the setup then click OK to reset your system. ASUS PRIME X299-DELUXE Series 3-11...

  • Page 78: My Favorites

    My Favorites My Favorites is your personal space where you can easily save and access your favorite BIOS items. My Favorites comes with several performance, power saving, and fast boot related items by default. You can personalize this screen by adding or removing items. Chapter 3: BIOS Setup 3-12...
  • Page 79 Configuration items such as Memory SPD Information, system time and date. Click Exit (ESC) or press <Esc> key to close Setup Tree Map screen. Go to My Favorites menu to view the saved BIOS items. ASUS PRIME X299-DELUXE Series 3-13...

  • Page 80: Main Menu

    Main menu The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup program. The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. Security The Security menu items allow you to change the system security settings.
  • Page 81 ASUS MultiCore Enhancement [Auto] This item allows you to maximize the oveclocking performance optimized by ASUS core ratio settings. [Disabled] This item allows you to set to default core ratio settings. CPU Core Ratio This item allows you to set the CPU core ratios.

  • Page 82: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 3.6.1 CPU Configuration The items in this menu show the CPU-related information that the BIOS automatically detects.

  • Page 83: Pch Configuration

    This item allows you to enable or disable the selected SATA port. Configuration options: [Disabled] [Enabled] Hot Plug These items appears only when the SATA Mode Selection is set to [AHCI] and allows you to enable or disable SATA Hot Plug Support. Configuration options: [Disabled] [Enabled] ASUS PRIME X299-DELUXE Series 3-17...

  • Page 84: Cpu Storage Configuration

    3.6.6 CPU Storage Configuration The items in this menu allow you to configure CPU storage configurations. • This menu will appear only when an Intel Core™ X-series Processors (6-core or ® above) is installed. • Due to CPU behavior, CPU RAID functions with Intel ®...

  • Page 85: Apm Configuration

    The Mass Storage Devices item shows the auto-detected values. If no USB device is detected, the item shows None. USB Single Port Control This item allows you to enable or disable the individual USB ports. Refer to section 1.1.2 Motherboard layout for the location of the USB ports. ASUS PRIME X299-DELUXE Series 3-19...

  • Page 86: Thunderbolt(Tm) Configuration

    3.6.12 Thunderbolt(TM) Configuration The items in this menu allow you to configure Thunderbolt settings. TBT Root port Selector This item allows you to select the thunder root port. Configuration options: [Thunderbolt Disabled] [PCIE16_1] [PCIE16_2] [PCIE16_3] [PCIE16_4] 3.6.13 PCH-FW Configuration This item allows you to configure the firmware TPM. Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings.

  • Page 87: Boot Configuration

    Configuration options: [Legacy only] [UEFI driver first] Secure Boot This item allows you to configure the Windows Secure Boot settings and manage its keys to ® protect the system from unauthorized access and malwares during POST. ASUS PRIME X299-DELUXE Series 3-21...

  • Page 88: Boot Option Priorities

    3.9.1 ASUS EZ Flash 3 Utility This item allows you to run ASUS EZ Flash 3. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice.

  • Page 89: Secure Erase

    To launch Secure Erase, click Tool > Secure Erase on the Advanced mode menu. Check the ASUS support site for a full list of SSDs tested with Secure Erase. The drive may become unstable if you run Secure Erase on an incompatible SSD.

  • Page 90: Asus Overclocking Profile

    This item displays the information and recommended configuration for the PCIE slots that the graphics card is installed in your system. This feature is only supported on selected ASUS graphics cards. Bus Interface This item allows you to select the bus interface.

  • Page 91: Exit Menu

    <Esc>, a confirmation window appears. Select Yes to discard changes and exit. Launch EFI Shell from filesystem device This item allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available filesystem devices. ASUS PRIME X299-DELUXE Series 3-25...

  • Page 92: Updating Bios

    ® ASUS EZ Flash 3: Updates the BIOS using a USB flash drive. ASUS CrashFree BIOS 3: Restores the BIOS using the motherboard support DVD or a USB flash drive when the BIOS file fails or gets corrupted. 3.11.1...

  • Page 93: Asus Ez Flash 3

    3.11.2 ASUS EZ Flash 3 ASUS EZ Flash 3 allows you to download and update to the latest BIOS through the Internet without having to use a bootable floppy disk or an OS-based utility. Updating through the Internet varies per region and Internet conditions. Check your local Internet connection before updating through the Internet.
  • Page 94 To update the BIOS by Internet: Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select ASUS EZ Flash Utility and press <Enter>. Select by Internet. Press the Left/Right arrow keys to select an Internet connection method, and then press <Enter>.

  • Page 95: Asus Crashfree Bios 3

    The BIOS file in the motherboard support DVD may be older than the BIOS file published on the ASUS official website. If you want to use the newer BIOS file, download the file at https://www.asus.com/support/ and save it to a USB flash drive.
  • Page 96 Chapter 3: BIOS Setup 3-30...

  • Page 97: Raid Support

    With the RAID 10 configuration you get all the benefits of both RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive and three new drives for this setup. ASUS PRIME X299-DELUXE Series...

  • Page 98: Installing Storage Devices

    4.1.2 Installing storage devices The motherboard supports Serial ATA hard disk drives and PCIE SSD storage devices. For optimal performance, install identical drives of the same model and capacity when creating a disk array. Refer to Chapter 2 for details on installing storage devices to your motherboard. 4.1.3 Intel Rapid Storage Technology in UEFI BIOS...
  • Page 99 When the RAID Level item is selected, press <Enter> to select the RAID level to create, and then press <Enter>. Under Select Disks, press <Enter> and select X for the disks you want to include in the RAID set. ASUS PRIME X299-DELUXE Series...
  • Page 100 When the Strip Size item is selected, press <Enter> to select strip size for the RAID array (for RAID 0, 10 and 5 only), and then press <Enter>. The available strip size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128 KB RAID 10: 64 KB RAID 5: 64 KB...
  • Page 101 <Enter>. The following screen appears: When the Delete item is selected, press <Enter>, then select Yes to delete the RAID volume and return to the Intel Rapid Storage Technology menu, or select No to ® cancel. ASUS PRIME X299-DELUXE Series...

  • Page 102: Intel ® Virtual Raid On Cpu In Uefi Bios

    4.1.4 Intel Virtual Raid on CPU in UEFI BIOS ® The motherboard supports Intel Virtual Raid on CPU with RAID 0, RAID 1, RAID 5, and ® RAID 10 solution. RAID 0 can be created without a KEY module, while RAID 1, RAID 5, and RAID 10 requires a KEY module.
  • Page 103 When the Enable RAID spanned over VMD Controllers item is selected, press <Enter> and select X to enable this function. Under Select Disks, press <Enter> and select X for the disks you want to include in the RAID set. ASUS PRIME X299-DELUXE Series...
  • Page 104 When the Strip Size item is selected, press <Enter> to select strip size for the RAID array (for RAID 0, 10 and 5 only), and then press <Enter>. The available strip size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128 KB RAID 10: 64 KB RAID 5: 64 KB...
  • Page 105 <Enter>. The following screen appears: When the Delete item is selected, press <Enter>, then select Yes to delete the RAID volume and return to the Intel Virtual Raid on CPU menu, or select No to cancel. ® ASUS PRIME X299-DELUXE Series...
  • Page 106 Installing the RAID controller driver during Windows 10 OS installation ® After creating the RAID sets, you are now ready to install an operating system to the independent drives or bootable array. This part provides the instructions on how to install the RAID controller drivers during OS installation.
  • Page 107 When the system finishes loading the RAID driver, replace the motherboard Support DVD with the Windows Server installation disc. Select the drive to install Windows and click Next. Setup then proceeds with the OS installation. Follow screen instructions to continue. ASUS PRIME X299-DELUXE Series 4-11...

  • Page 108: Intel ® Rapid Storage Technology Option Rom Utility

    4.1.5 Intel Rapid Storage Technology Option ROM utility ® To enter the Intel Rapid Storage Technology Option ROM utility: ® Turn on the system. During POST, press <Ctrl> + <I> to display the utility main menu. RAID Volumes: None defined. Physical Devices: Port Device Model...
  • Page 109 Size Status ST3160812AS 9LS0HJA4 149.0GB Non-RAID Disk ST3160812AS 9LS0F4HL 149.0GB Non-RAID Disk ST3160812AS 3LS0JYL8 149.0GB Non-RAID Disk ST3160812AS 9LS0BJ5H 149.0GB Non-RAID Disk Select 2 to 6 to use in creating the volume. [↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done ASUS PRIME X299-DELUXE Series 4-13...
  • Page 110 Use the up/down arrow key to select a drive, and then press <Space> to select. A small triangle marks the selected drive. Press <Enter> after completing your selection. Use the up/down arrow key to select the strip size for the RAID array (for RAID 0, 10 and 5 only), and then press <Enter>.
  • Page 111 (This does not apply to Recovery volumes) Are you sure you want to delete “Volume0”? (Y/N): Press <Y> to delete the RAID set and return to the utility main menu, or press <N> to return to the DELETE VOLUME menu. ASUS PRIME X299-DELUXE Series 4-15...

  • Page 112: Creating A Raid Driver Disk

    Exiting the Intel Rapid Storage Technology Option ROM utility ® To exit the utility: From the utility main menu, select 6. Exit, then press <Enter>. The following warning message appears: [CONFIRM EXIT] Are you sure you want to exit? (Y/N): Press <Y>...

  • Page 113: Appendix

    Appendix Appendix Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation.
  • Page 114 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This Class B digital apparatus complies with Canadian ICES-003, RSS-210, and CAN ICES- 3(B)/NMB-3(B). This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 115 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
  • Page 116 FCC Bluetooth Wireless Compliance The antenna used with this transmitter must not be co-located or operated in conjunction with any other antenna or transmitter subject to the conditions of the FCC Grant. Bluetooth Industry Canada Statement This Class B device meets all requirements of the Canadian interference-causing equipment regulations.
  • Page 117 ASUSTek Computer Inc. hereby declares that this device is in compliance zahtjevima i ostalim odgovarajućim odredbama direktive 2014/53/EU. Cijeli with the essential requirements and other relevant provisions of Directive tekst EU izjave o sukladnosti dostupan je na https://www.asus.com/support/ 2014/53/EU. Full text of EU declaration of conformity is available at https://www.asus.com/support/ WiFi koji radi na opsegu frekvencija 5150-5350 MHz bit će ograničen na...
  • Page 118 Direktive 2014/53/EU. Polno https://www.asus.com/support/ besedilo izjave EU o skladnosti je na voljo na https://www.asus.com/support/ Wi-Fi darbība 5150–5350 MHz ir jāierobežo lietošanai telpās valstīs, kuras WiFi, ki deluje v pasovnem območju 5150–5350 MHz, mora biti v državah, norādītas tālāk.
  • Page 119 ASUSTek Computer Inc. заявляє, що цей пристрій відповідає основним вимогам та іншим відповідним вимогам Директиви 2014 / 53 / EU. Повний текст декларації відповідності нормам ЄС доступний на https://www.asus.com/support/ Робота Wi-Fi на частоті 5150-5350 МГц обмежується використанням у приміщенні для країн, поданих у таблиці нижче: Робота...

  • Page 120: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support http://qr.asus.com/techserv ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555 Support Fax...

  • Page 121: Declaration Of Conformity

    DECLARATION OF CONFORMITY Compliance Information Statement Per FCC Part 2 Section 2. 1077(a) Asus Computer International Responsible Party Name: , CA 94539. Address: 800 Corporate Way, Fremont Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : PRIME X299-DELUXE...
