- Page 1 UHF-200 ® UHF-DUAL CHANNEL A-RF A-AF POWER B-RF B-AF WIRELESS MICROPHONE UHF-200 A-RF A-AF POWER B-RF B-AF UHF-200 WIRELESS USER GUIDE...
-
Page 2: Table Of Contents
INTRODUCTION UHF-200 Wireless Created for active musicisans and presenters who also manage their own sound, it improves your performance and simplifies your setup. Innovations such as automatic frequency selection and automatic transmitter setup make wireless quicker and completely worry free. -
Page 3: System Feature
SYSTEM FEATURE UHF-DUAL CHANNEL WIRELESS MICROPHONE UHF-200 A-RF A-AF POWER B-RF B-AF 1. Volume Control Adjust the volume level of each channel 2. AF LED Indicator Audio frequency indicator 3. RF LED Indicator Radio frequency indicator 4. Power LED Indicator 5. -
Page 4: Reciever Dc-Power Connection
RECIEVER DC-POWER CONNECTION Rear View 120AC DC14-18V 500mA Please make sure to use the correct power adapter, otherwise it will damage the reciever. Our warranty does not cover this. -
Page 5: Wirelesss Microphone Battery Installation
MICROPHONE BATTERY INSTALLATION Microphone Battery Compartment 1.Slide open the battery cover. UM 3 UM 3 2. Make sure to insert the battery with the right polarity, as shown in the picture. UM 3 UM 3 3. Slide the battery cover back. UM 3 UM 3... -
Page 6: System Specification
SYSTEM SPECIFICATION Specification Channel: 32 Group Frequency range: 500~900MHz Bandwidth: <200KHz Frequency response: 50Hz-16KHz+3dB Dynamic range: >110dB T.H.D.: <0.5% S/N ratio: >90dB Valid distance: >50m 1. Transmitter Transmitter: 10mW Oscillation mode: Adjustment mode: Image controlment: >50dB Adjust frequency deviation: <75KHz Channel switch mode: coding switch Power:... -
Page 7: Operation
OPERATION • The two microphone should be set to the same channel with the one reciever. • The green indicator is lite when the micro- Using the microphone correctly. phone is on. The microphone is in low on power when the LED indicator is flashing. •... -
Page 8: Service
TROUBLESHOOT Problems Indicator State Solution(s) Push the power switch to the “ON” position on the microphone. Reciever signal indicator is No Sound not lite up. Check if the battery is inserted properly, if inserted correctly replace with new battery. Check to see if the AC adapter is Reciever power indicator is No Sound properly plugged in into the wall outlet.
