Care of the screen Do not touch the screen with anything hard as this may scratch, mar or damage the screen permanently. Do not rub with dust clothes with chemical treatment. Do not touch the surface with bare hands or greasy cloth (some cosmet ics are detrimental to the screen).
Switch the TV on : Press the power switch on the TV. An indicator on the front of the TV lights up and the screen comes on. If the TV is in standby mode (red indicator), press the - TV+ keys or the Accessing the Set-up Menu When the set is in the High Security Mode, the Setup menu can be accessed only with an Institutional Set-up Remote Control (RG4172BK or RC2573).
Page 4
Language: Select the language of the installation menu. Options are “ENGLISH”, “FRANCAIS”, and “ESPANOL”. Communication: The Communication menu is required to enable interactive applications. For more information consult the application notes. For stand-alone applications select “OFF”. Channel Install: This sub menu allows setting the number of television channels.
Page 5
In the Channel Install sub-menu, program settings can be set . When this menu is displayed, all the protections are inactive. Label: This menu item wi l l be used to add a label/name for each channel. By pressing the left/right buttons you may enter or exit the label field; by pressing the up/down cursor you may insert alphanumeric characters.
Page 6
In this sub menu the behavior of the TV after switching on and the behavior of the On Screen Display can be selected. Switch On Volume: This item sets the television’s volume at Power On. Use the Right/Left Cursor buttons or direct digit entry to adjust.
Page 7
In this sub menu, the Picture and Sound settings of the TV can be configured. In this sub menu, the Security settings of the TV can be configured. Brightness: This changes picture brilliance. Color: This changes the intensity of the color. Contrast: This changes the difference between the light and dark tones.
Page 8
In this sub menu, the Control settings of the TV can be configured. 3 Digit Entry: To allow for 3-digit entry of channel numbers via the Remote Control, select “YES”. Select “NO” to allow only 2 -digit entry of channel numbers via Remote Control. Source Menu Item: Toggle between “YES/NO”...
Page 9
The pictures you receive may be transmitted in 16:9 format (wide screen) or 4:3 format (conventional screen). 16:9 pictures sometimes have a black band at the top and bottom of the screen (letterbox format). This function allows you to optimize the picture display on screen. Using the different formats Select the preferred format from the Switch ON/OSD Menu in the setup screen, or (if applicable) use the Format button on the Remote Control to select the different modes: 4:3, Zoom 14:9, Zoom 16:9, Subtitle...
Page 10
Source Select To toggle between available video sources DVD PAUSE To Pause DVD playback (if applicable) Close Caption To activate Close Caption functionality DVD STOP To Stop DVD playback (if applicable) Menu To call up or exit the menus. + Vol - To adjust the volume.
Page 11
Press the key for approximately 5 seconds. The following text appears: If the word “LOW” appears instead of “OK”, the batteries are low and must be replaced. Should your remote be lost or broken you can still change some of the basic settings with the keys on top/side of your TV.
Page 12
This section provides information on the connectivity available for different LCD Television sets. Refer to the screen size that is relevant to your TV set. 26” LCD TVs Connectors on the 26” LCD TVs External Bathroom Speaker Connector (8 Ohm, 1 Watt) Audio-Video In Connector (Side AV) S-Video In Connector (Side S-Video) Data 2 (RJ45) jack –...
Page 13
This section provides information on mounting the television stand. Refer to the screen size that is relevant to your LCD television set. 26” LCD TVs - 13 -...
