- Page 1 SA7016 1.3GHz low voltage fractional-N synthesizer Product specification Supersedes data of 1999 Apr 20 INTEGRATED CIRCUITS 1999 Nov 04...
-
Page 2: General Description
Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer GENERAL DESCRIPTION The SA7016 BICMOS device integrates programmable dividers, charge pumps and a phase comparator to implement a phase-locked loop. The device is designed to operate from 3 NiCd cells, in pocket phones, with low current and nominal 3 V supplies. - Page 3 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer CLOCK 2–BIT SHIFT REGISTER DATA ADDRESS DECODER STROBE LOAD SIGNALS RFin+ RFin– in– TEST PINNING SYMBOL DESCRIPTION LOCK Lock detect output TEST Test (should be either grounded or connected to V Digital supply...
-
Page 4: Limiting Values
Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer LIMITING VALUES In accordance with the Absolute Maximum Rating System (IEC 134). SYMBOL Digital supply voltage Analog supply voltage DDCP –V Difference in voltage between V DDCP Voltage at pins 1, 2, 5, 6, 11 to 16... - Page 5 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer CHARACTERISTICS = +3.0V, T = +25 C; unless otherwise specified. DDCP SYMBOL PARAMETER Supply; pins 3, 9 Digital supply voltage Analog supply voltage DDCP Synthesizer operational total supply current DDTotal Total supply current in power-down mode Standby RFin main divider input;...
- Page 6 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer SYMBOL PARAMETER Phase noise (R = 7.5 k , CP=00) Synthesizer’s contribution to close-in phase noise of 900 MHz RF signal at 1 kHz offset. Synthesizer’s contribution to close-in phase noise of 800 MHz RF signal at 1 kHz offset.
-
Page 7: Functional Description
Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer FUNCTIONAL DESCRIPTION Main Fractional-N divider The RFin inputs drive a pre-amplifier to provide the clock to the first divider stage. For single ended operation, the signal should be fed to one of the inputs while the other one is AC grounded. The pre-amplifier has a high input impedance, dominated by pin and pad capacitance. - Page 8 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer REF DIVIDER AUX/MAIN DIVIDER 1999 Nov 04 “1” “1” Figure 5. Phase Detector Structure with Timing Product specification SA7016 P–TYPE CHARGE PUMP N–TYPE CHARGE PUMP SR02103...
- Page 9 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer Main Output Charge Pumps and Fractional Compensation Currents (see Figure 6) The main charge pumps on pins PHP and PHI are driven by the main phase detector and the charge pump current values are...
- Page 10 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer Charge pump currents NOTES: 1. I : bias current for charge pumps. 2. I is the total current at pin PHP during speed up condition. PHP–SU Lock Detect The output LOCK maintains a logic ‘1’ when the auxiliary phase detector ANDed with the main phase detector indicates a lock condition.
- Page 11 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer Serial programming bus The serial input is a 3-wire input (CLOCK, STROBE, DATA) to program all counter divide ratios, fractional compensation DAC, selection and enable bits. The programming data is structured into 24 bit words; each word includes 2 or 3 address bits. Figure 8 shows the timing diagram of the serial input.
- Page 12 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer Data format Table 1. Format of programmed data LAST IN Table 2. A word, length 24 bits LAST IN Address fmod Fractional-N Main Divider ratio Default: A word select Fixed to 00. Fractional Modulus select FM 0 = modulo 8, 1 = modulo 5.
- Page 13 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer –200 = 51.67 A = 103.33 A –400 = 165.33 A –600 = 206.67 A –800 0.25 0.5 0.75 1.25 1.5 1.75 COMPLIANCE VOLTAGE (V) Figure 9. Php Charge Pump Output vs. I (CP = 0, TEMP = 25 C) –50...
- Page 14 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer 1500 1000 = 51.67 A –500 = 103.33 A = 165.33 A –1000 = 206.67 A –1500 0.25 0.5 0.75 1.25 1.75 COMPLIANCE VOLTAGE (V) Figure 15. Php–su Charge Pump Output vs. I (CP = 1;...
- Page 15 Philips Semiconductors 1.3GHz low voltage fractional-N synthesizer TEMP = +85 C TEMP = +25 C TEMP = –40 C SUPPLY VOLTAGE (V) Figure 21. Current Supply Over V 1999 Nov 04 SR01931 Product specification SA7016...
- Page 16 Philips Semiconductors 1.3GHz low voltage fractional-N frequency synthesizer TSSOP16: plastic thin shrink small outline package; 16 leads; body width 4.4 mm 1999 Nov 04 Product specification SA7016 SOT403-1...
- Page 17 Philips Semiconductors 1.3GHz low voltage fractional-N frequency synthesizer 1999 Nov 04 NOTES Product specification SA7016...
- Page 18 Life support — These products are not designed for use in life support appliances, devices or systems where malfunction of these products can reasonably be expected to result in personal injury. Philips Semiconductors customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips Semiconductors for any damages resulting from such application.
