SPECIFICATIONS

AMPLIFIER SECTION
• Output Power
FRONT L/R, CENTER, SURROUND L/R
1 kHz, 10% THD, 8 Ω ............................................................................... 35 W
SUBWOOFER
100 Hz, 10% THD, 8 Ω ............................................................................. 40 W
[U.S.A. and Canada models]
FRONT L/R, CENTER, SURROUND L/R
1 kHz, 0.9% THD, 8 Ω ........................................................................... 30 W
SUBWOOFER
100 Hz, 0.9% THD, 8 Ω ......................................................................... 35 W
• Inputs
VIDEO 1 (RCA)
AUDIO ................................................................................................ Analog
VIDEO .......................................................................................... Composite
VIDEO 2 (RCA)
[U.S.A., Canada, Australia, China, Korean and General models]
AUDIO ................................................................................................ Analog
VIDEO .......................................................................................... Composite
VIDEO 2 (EURO AV)
[U.K. and Europe models]
AUDIO ................................................................................................ Analog
VIDEO .......................................................................................... Composite
• Outputs
VIDEO 1 (RCA)
AUDIO ................................................................................................ Analog
VIDEO .......................................................................................... Composite
MONITOR OUT
VIDEO (RCA) .................................................................................. Composite
S-VIDEO ........................................................................................... DVD only
COMPONENT
[U.S.A., Canada, Australia, China, Korean and General models] .. DVD only
EURO AV
[U.K. and Europe models]
AUDIO ................................................................................................ Analog
VIDEO ........................................................ RGB (DVD only) & Composite
SPEAKERS
FRONT L/R ................................................................................................. 8 Ω
CENTER ..................................................................................................... 8 Ω
REAR L/R ................................................................................................... 8 Ω
SUBWOOFER ............................................................................................ 8 Ω
DVD PLAYER SECTION
• Type ............................................................................................ DVD video player
• Playback standard
[U.S.A., Canada and Korean models] ........................................................ NTSC
[U.K., Europe, Australia, China and General models] .................................. PAL
• Laser .............................................. Semiconductor laser, wavelength: 650/790 nm
• Laser output (Continuous wave max.) ............................................... 1 mW (DVD)
• Signal to Noise Ratio (IHF-A Network, shorted) ....................... More than 105 dB
• Total Harmonic Distortion .......................................................................... 0.003 %
• Wow and flutter ................................................................. Below measurable level
TUNER SECTION
• FM Tuning Range
[U.S.A. and Canada models] .................................................. 87.9 to 107.9 MHz
[Other models] .................................................................... 87.50 to 108.00 MHz
• AM Tuning Range
[U.S.A. and Canada models] ...................................................... 520 to 1710 kHz
[U.K. and Europe models] .......................................................... 522 to 1611 kHz
[Australia, China and Korean models] ....................................... 522 to 1710 kHz
[General model] .................................................................. 522/520 to 1710 kHz
26
E-
SPEAKER SECTION
• Front and Surround Speakers
Model Name .......................................................................................... NX-S60S
Type ...................................................................................... Acoustic suspension
Speakers ........................................................... 5 cm (2 inch) full range cone x 2,
Impedance ...................................................................................................... 8 Ω
• Center Speaker
Model Name ......................................................................................... NX-S60C
Type ...................................................................................... Acoustic suspension
Speakers ........................................................... 5 cm (2 inch) full range cone x 2,
Impedance ...................................................................................................... 8 Ω
• Subwoofer
Model Name ............................................................................................ SW-S60
Speaker ................................................. Passive 16 cm (6-1/2 inch) cone woofer,
Impedance ...................................................................................................... 8 Ω
GENERAL
• Power Supply
[U.S.A. and Canada models] ...................................................... AC 120 V/60 Hz
[Australia model] ................................................................ AC 230-240 V/50 Hz
[U.K. and Europe models] .......................................................... AC 230 V/50 Hz
[China model] ............................................................................. AC 220 V/50 Hz
[Korean model] ........................................................................... AC 220 V/60 Hz
[General model] ............................................. AC 110-120/220-240 V, 50/60 Hz
• Power Consumption
[U.S.A., Canada and Korean models] ........................................................ 230 W
[U.K., Europe, Australia, China and General models] ............................... 170 W
• Standby Power Consumption
DVR-S60 ..................................................................................................... 1.8 W
• Dimensions (W x H x D)
DVR-S60 ............................................................................... 435 x 90 x 381 mm
SW-S60 ................................................................................ 200 x 351 x 206 mm
NX-S60C ............................................................................... 300 x 72 x 110 mm
NX-S60S ............................................................................... 72 x 164 x 111 mm
• Weight
DVR-S60 ..................................................................................................... 8.0kg
SW-S60 ........................................................................................................ 4.8kg
NX-S60C ..................................................................................................... 1.1kg
NX-S60S ..................................................................................................... 0.9kg
0.5 mW (CD)
magnetic shielding
magnetic shielding
magnetic shielding
(17-1/8" x 3-9/16" x 15")
(7-7/8" x 13-13/16" x 8-1/8")
(11-13/16" x 2-13/16" x 4-5/16")
(2-13/16" x 6-7/16" x 4-3/8")
(17 lbs 10 oz)
(10 lbs 9 oz)
(2 lbs 7 oz)
(2 lbs)
