Yamaha MCX-A10 Service Manual

Musiccast digital audio terminal/speaker system
Hide thumbs Also See for MCX-A10:

Advertisement

Quick Links

DIGITAL AUDIO TERMINAL/SPEAKER SYSTEM
MCX-A10/MCX-SP10
The MusicCAST system consists of th MCX-1000, the
MCX-A10 and the MCX-SP10.
This service manual is for the MCX-A10 and the MCX-SP10.
For the MCX-1000 service manual, please refer to the
following publication number:
MCX-1000
100851
When accepting a repair request from the user, be sure to
let him/her know that the stored HDD data cannot be guar-
anteed.
For the repair work, it is recommended to receive MCX-
1000 and MCX-A10 as a set.
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevita-
ble and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING:
IMPORTANT:
1 0 0 8 5 2
SERVICE MANUAL
SERVICE MANUAL
ミュージックキャストシステムはMCX-1000、 MCX-A10
及びMCX-SP10で構成されています。
このサービスマニュアルはMCX-A10及びMCX-SP10用です。
MCX-1000のサービスマニュアルは下記を参照してくだ
さい。
修理依頼を受ける際、 H D D のデータは保証できないこと
をお客様に伝えてください。
修理品はMCX-1000とMCX-A10をセットでお預かりする
ことを推奨します。
IMPORTANT NOTICE
Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these
reasons, we advise all YAMAHA product owners that any service required should be performed by an
authorized YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification
or recognition of any applicable technical capabilities, or establish a principle-agent relationship of any
form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this
buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the
unit.
MCX-1000
100851
