User Manual
UXDC16 Underwater Digital Camera
QUICK INSTALLATION GUIDE
Step 1 Remove tape and packing materials
Step 2 Install battery in Camera
Step 3 Open back of housing and gently install camera
(insert external memory card here if needed)
make sure the camera is firmly seated
Step 4 Gently close back of housing. DO NOT FORCE.
Step 5 Turn swivel locking knob clockwise until safety locking lever is seated
If housing does not close properly, check to ensure
( "Click " sound will be heard ).
that camera is seated correctly
Advertisement
Related Manuals for Ultramax UXDC16
Summary of Contents for Ultramax UXDC16
- Page 1 UXDC16 Underwater Digital Camera QUICK INSTALLATION GUIDE Step 1 Remove tape and packing materials Step 2 Install battery in Camera Step 3 Open back of housing and gently install camera (insert external memory card here if needed) make sure the camera is firmly seated Step 4 Gently close back of housing.
- Page 2 Step 6 Remove protective file from Caseback LCD Display Step 7 Remove protective films from Lensport before starting to take photos underwater HOUSING CARE AND MAINTENANCE 1. Rinse housing thoroughly with fresh, clean water after each use. Be sure to rinse buttons well as salt residue will cause buttons stick. 2.
- Page 3 INSTALLATION OF OPTIC CABLE CONNECTOR FOR EXTERNAL FLASHES Step 1 Peel-off backing film of the adhesive tape Step 2 Gently press and fit the Connector base onto the camera flash window Step 3 Plug the Optic Cable Jacks into the connector holes Step 4 Connect the other end of the Optic Cable Jacks to your external flash NOTICE:-...
- Page 4 To obtain warranty service, contact ULTRAMAX to obtain a Return Authorization number (RA No) AND Return Address details (FOR USA ONLY). Product and Proof of Purchase must be returned, freight prepaid, to ULTRAMAX with RA number clearly marked on the package. Product must be sent in original or comparable packaging that safely protects the contents.
