GE
Measurement & Control
Moisture
Optica™
Operator's Manual
A40238752 Rev. G
December 2015

Advertisement

Table of Contents
loading

Related Manuals for GE Optica

Summary of Contents for GE Optica

  • Page 1 Measurement & Control Moisture Optica™ Operator’s Manual A40238752 Rev. G December 2015...
  • Page 3 Optica™ General Eastern Dew Point Analyzer Operator’s Manual A40238752 Rev. G December 2015 www.gemeasurement.com ©2015 General Electric Company. All rights reserved. Technical content subject to change without notice.
  • Page 4 [no content intended for this page]...

  • Page 5: Table Of Contents

    2.3.1 Mounting the Wall-Mount Optica ........
  • Page 6 3.3 Operating the VGA Optica ........
  • Page 7 4.7 Saving Configuration Files ..............57 Chapter 5. Programming the 4x40 Optica 5.1 Introduction .
  • Page 8 C.1 Wiring to a Personal Computer ............. . .95 Optica™ Operator’s Manual...
  • Page 9 Programming Automatic Balance for a VGA Optica ........
  • Page 10 Contents [no content intended for this page] viii Optica™ Operator’s Manual...
  • Page 11 Make sure that operators and maintenance personnel have all safety equipment applicable to the auxiliary equipment. Examples include safety glasses, protective headgear, safety shoes, etc. Unauthorized Operation Make sure that unauthorized personnel cannot gain access to the operation of the equipment. Optica™ Operator’s Manual...
  • Page 12 Environmental Compliance Waste Electrical and Electronic Equipment (WEEE) Directive GE Measurement & Control Solutions is an active participant in Europe’s Waste Electrical and Electronic Equipment (WEEE) take-back initiative, directive 2012/19/EU. The equipment that you bought has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment.

  • Page 13: Chapter 1. Features And Capabilities

    Using the Optica, you can simultaneously measure and display dew point, temperature and pressure, with a wide variety of units of measure. The Optica is Ethernet-ready, so you can access the unit using the Internet for remote monitoring applications. You can use the data logging function to record and upload weeks of data.

  • Page 14: Front Panel

    Chapter 1. Features and Capabilities 1.2.1 Front Panel The Optica front panel is shown in Figure 1 below. The panel includes: a display, an alphanumeric keypad for data entry, ENTER and TAB keys, and four softkeys to the right of the display screen.

  • Page 15: The System

    The Optica can be configured with a chilled-mirror dew point sensor. The specific sensor is chosen according to the expected dew point range and the environment in which the dew point is to be determined. In addition, the Optica can be configured with a temperature and/or pressure sensor.

  • Page 16: Theory Of Operation

    1.5.1 Hygrometer Function Figure 2 below illustrates how GE Measurement & Control hygrometers detect and measure dew point. The condensate mirror is illuminated with a solid state, infrared emitter (IR). A photodetector monitors the IR light reflected from the mirror. The photodetector is fully illuminated when the mirror is clear of dew, and it receives less light as dew forms.

  • Page 17: Hygrometer Calibration

    The GE optical condensation sensors cover a wide range of applications limited only by the heat pumping capabilities of the thermoelectrically-cooled mirror.

  • Page 18: The Pacer Cycle

    (Programmable PACER Automatic Contaminant Error Reduction) that is very effective in reducing the Raoult Effect error associated with soluble contaminants, particularly for near-ambient dew points. The Optica is equipped with the cycle as well as PACER balance as found on earlier models. The user can choose which self-cleaning and balancing routine to run AUTO depending on the severity of the contamination.

  • Page 19: Chapter 2. Installation

    2.2 Benchtop Optica Installation 2.2.1 Mounting the Benchtop Optica The Optica benchtop dimensions are shown in Figure 5 below. Two feet on the bottom of the case can be unfolded to raise up the front for easier viewing, if desired.

  • Page 20: Using The Rack Mounting Option

    There is an optional kit for mounting the benchtop unit in a standard 19-inch rack (see Figure 6 below, Figure 7 on page 9, and Figure 8 on page 10). The two brackets are attached to the front panel using four #8 screws. The Optica is mounted to the brackets using the eight mounting holes located just in front of and behind the unit’s feet.
  • Page 21 Chapter 2. Installation 2.2.2 Using the Rack Mounting Option (cont.) Figure 7: Optica Rack-Mount Adapter - Front Panel Optica™ Operator’s Manual...
  • Page 22 Chapter 2. Installation 2.2.2 Using the Rack Mounting Option (cont.) Figure 8: Optica Rack-Mount Adapter - Bracket Optica™ Operator’s Manual...

  • Page 23: Wiring The Benchtop Optica

    Input Power The Optica operates with input power from 100 to 120 VAC at 4 amps, or from 200 to 240 VAC at 2.5 amps. It is designed for a nominal 100, 115 or 230 VAC source. A switch on the rear panel selects the appropriate voltage range (see Figure 9 below).

  • Page 24: Wall-Mount Optica Installation

    Chapter 2. Installation 2.3 Wall-Mount Optica Installation The Optica Wall-Mount unit is designed to mount on a flat, vertical surface, such as a wall or panel. To mount the wall-mount version, see Figure 10 and Figure 11 below. 2.3.1 Mounting the Wall-Mount Optica (165) 16.725...

  • Page 25: Wiring The Wall-Mount Optica

    Chapter 2. Installation 2.3.2 Wiring the Wall-Mount Optica All connections to the wall-mount unit are made through the panel at the bottom of the case as shown in Figure 12 and Figure 13below. Any I/O cabling is brought into the unit through a gland at the lower left of the case and connects to the terminal blocks on the left side of the case.

  • Page 26: Output Wiring

    Figure 14: Wall-Mount AC Power Wiring 2.4 Output Wiring The benchtop Optica outputs are connected to removable terminal blocks on the rear panel. Figure 9 on page 11 shows the location of the benchtop unit terminal blocks and Figure 15 below shows the connections.

  • Page 27: Analog Outputs

    Chapter 2. Installation 2.4.1 Analog Outputs Note: When the Optica is being programmed, the analog outputs provide 4–20 mA and 0–5 VDC signals representing the designated parameters. • For 4–20mA output, connect to terminals labelled 4–20 (+) and RTN (–).

  • Page 28: Alarm Outputs

    Both Upper and Lower threshold values are programmed for each parameter. These values designate an alarm band. How they are used depends on the programmed alarm type. Details are shown in “Inner Band Alarm” on page 17 and “Outer Band Alarm” on page 17. Optica™ Operator’s Manual...
  • Page 29 For the Outer Band alarm, the alarm relay activates whenever the parameter value is greater than the upper limit or less than the lower limit. Alarm Alarm Alarm Activated Deactivated Activated UPPER edge of band LOWER edge of band “NO” Contacts “NC” Contacts “NO” Contacts Closed Closed Closed Figure 18: Outer Band Alarm Optica™ Operator’s Manual...

  • Page 30: Serial Output

    The connector is a standard 9-pin D connector. For connection to another serial device, the cable is wired as shown in Table 1 below. For a basic interface without handshaking, only pins 2, 3 and 5 (RX, TX and GND) on the Optica connector are needed.

  • Page 31: Sensor Information

    Chapter 2. Installation 2.5 Sensor Information GE Measurement & Control produces a variety of sensors compatible with the Optica, ranging from one to five stages of thermoelectric cooling. A comparison chart listing specifications of each sensor is given in Appendix D. “Chilled Mirror Sensors“.

  • Page 32: Ensuring Heat Transfer

    At high temperatures, use stainless steel tubing with adequate insulation to avoid hot and cold sections in the line and to avoid water absorption/ desorption cycling as the heater is thermostatically controlled. Heated sampling lines (HSL) are available from GE. Optica™ Operator’s Manual...
  • Page 33 A flow rate of 2 to 2.5 ft /h (a little over 1 liter/min) is ideal for most applications. In many cases, flow rates between 0.2 and 5 ft /h (0.1 and 2.5 liter/min) may be used. Optica™ Operator’s Manual...

  • Page 34: Sensor Installation

    Chapter 2. Installation 2.6 Sensor Installation This section provides installation details for the GE Measurement & Control line of chilled-mirror humidity sensors. 2.6.1 Model 1111H Sensor The Model 1111H is an open-type sensor (see Figure 19 below). It can be threaded into standard pipe fittings or mounted in a type 0111D pressure boss, which encloses it and adapts it for ¼-inch compression fittings.

  • Page 35: Model 1211H Sensor

    300 watts at the coolant temperature. Switch the internal fan ON if air cooling is used; leave it OFF for liquid cooling. Install the gas sampling lines according to the instructions listed in “Sampling Lines” on page 19. Figure 21: Model 1311DR Sensor Optica™ Operator’s Manual...

  • Page 36: Model 1311Xr Sensor

    If a recirculating chiller is used, it should have a capacity of at least 600 watts at the coolant temperature. 2.6.5c Sample Gas Fittings The 1311XR sensor has 1/4” stainless steel compression fittings for sample gas inlet and outlet at the back of the sensor chassis. Optica™ Operator’s Manual...
  • Page 37 In AUTO mode, the controller senses the current supplied by the Optica to the top two stages of the thermoelectric coolers. The controller switches on the fourth stage power supply, as required to maintain the mirror temperature at the dew/frost point.

  • Page 38: Model Sim-12H Heated Sensor And Components

    2.6.7 Connecting the Sensors Dew point, temperature and pressure sensors provided by GE for the Optica monitor are pre-wired with connectors installed. Plug these connectors into their corresponding sockets as shown in Figure 9 on page 11 for the benchtop unit, or Figure 12 on page 13 for the wall-mount unit.

  • Page 39: Chapter 3. Operation

    3.2 Normal Operation Normal operation of the Optica is very simple. To turn the unit on, check that the main power switch on the rear of the benchtop unit is set to ON (—), then press the right-hand side of the power switch (located at the lower left corner on the front of the unit).

  • Page 40: Operating The Vga Optica

    The parameters chosen during programming are displayed numerically in the top half of the screen, and graphically at the bottom (see Figure 23 below). To program the unit, see Chapter 4. “Programming the VGA Optica“. A balance indicator is shown as a vertical bar on the right side of the screen. It shows the state of the feedback control loop controlling the mirror temperature.

  • Page 41: Network Operation

    Chapter 3. Operation 3.5 Network Operation The VGA Optica can be operated and programmed remotely over a network. Networked operation is very similar to operation using the front panel. For programming from a network, see Chapter 6. “Network-Based Programming“. A typical network screen is shown in Figure 25 below.

  • Page 42: Process Pressure

    500 psi. A sampling system can be arranged to allow the measurement to be made at atmospheric pressure. The Optica can then calculate and display the dew point at the process pressure (see “Scenario 2: Measurement Requiring the Process Pressure Feature” on page 32).

  • Page 43: Scenario 1: Measurement Without Enabling The Process Pressure Feature

    3.6.4 Scenario 1: Measurement Without Enabling the Process Pressure Feature Process pressure is 100 psi, within the range of a typical GE chilled mirror sensor. Since vapor pressure and dew point are pressure-dependent, a flow meter is installed downstream of the sensor to assure that the sensor cavity is at the process pressure (see Figure 26 below).

  • Page 44: Scenario 2: Measurement Requiring The Process Pressure Feature

    3.6.6 Scenario 2: Measurement Requiring the Process Pressure Feature Process pressure is 500 psi, above the measurement range of a typical GE chilled mirror sensor. A flowmeter is installed upstream of the sensor cavity to expand the gas to be within the measurable range of the dew point sensor.
  • Page 45 Per Dalton’s Law of Partial Pressure: e = (P ) × e = (500/14.7) × 0.1283 = 4.36 mbar • Using standard vapor pressure equations, the actual pressurized dew point is calculated by the Optica to be: Tdew = –4.022°C Optica™ Operator’s Manual...

  • Page 46: Status Line Indications

    The unit is actively controlling the mirror temperature at a stable dew point. Alarm 1 Alarm 1 has activated. Alarm 2 Alarm 2 has activated. Lockout Heat, Cool, and PACER front panel controls are disabled. Heat Sensor Heating is active. Cool Sensor Cooling is active. Optica™ Operator’s Manual...

  • Page 47: Factory Default Settings

    Chapter 3. Operation 3.7.1 Factory Default Settings As shipped from the factory, the Optica is normally programmed with the configuration listed in Table 4 below. Table 4: Factory Default Values Function Setting Analog Output A Humidity, Units: Tdew °C, Range: –40°C to +60°C Analog Output B Temperature, Units: Tmp °C, Range: 0 to 100°C...

  • Page 48: Sensor Balancing

    The interval and type of balance are configurable as described in the Optica programming chapters. If the Service indicator is displayed after a balance operation, the sensor may need to be adjusted (see “Minor Maintenance of Sensor Optics”...

  • Page 49: Supercooled Dew Points

    3. Balance the detector by initiating a cycle. PACER 4. Measure the dew point again. If the new reading is lower than the first reading, it is likely that soluble material was present in sufficient quantity to cause a measurement error. Optica™ Operator’s Manual...

  • Page 50: Mirror Flooding

    The sensor location and hookup arrangement can influence the pressure. When the pressure at the sensor is different from the process pressure, the Optica can perform a conversion from the measured pressure to the desired process pressure (see “Process Pressure” on page 30 for details).

  • Page 51: Chapter 4. Programming The Vga Optica

    Chapter 4. Programming the VGA Optica 4.1 Introduction The Optica is programmed at the factory to display and output the data required for many applications (see Table 4 on page 35). In these cases, no further programming is required. By programming the Optica, the following categories of data can be customized for your application: the front panel display (up to six parameters displayed numerically and, on the VGA screen, a graphical display) •...

  • Page 52: The Keys

    Chapter 4. Programming the VGA Optica 4.2.1 The Keys The following keys on the Optica’s front panel are used for programming: • performs the function shown on a selected control button. ENTER • moves cursor to the next field or control button to select it.
  • Page 53 Chapter 4. Programming the VGA Optica 4.2.2a Direct-Entry Fields (cont.) Note: It is necessary to press after setting each value in its field. ENTER Figure 28 below shows a typical direct-entry field, with the (Graph Minimum) field selected and ready for GrphMin numeric input from the keypad.

  • Page 54: Units Of Measure

    In some applications an output may be needed that is not a simple function of a single parameter, but a combination of two or three parameters. One or more user equations can be defined within the Optica to calculate new parameters that meet the application requirements.
  • Page 55 Chapter 4. Programming the VGA Optica User Equations (cont.) Table 6: User Equation Parameters Identifier Units Identifier Units Humidity Units: Temperature Units: Tdew °C Tmp °C Tdew °F Tmp °F Tmp °K Twet °C Tmp °R Twet °F Pressure Units:...

  • Page 56: Menu 1

    Chapter 4. Programming the VGA Optica 4.5 Menu 1 is shown in Figure 30 below. This menu is accessed by selecting the control button on the main screen Menu 1 Menu and pressing ENTER Figure 30: Menu 1 allows programming of the items in the following sub-sections.

  • Page 57: Pressure Input

    Chapter 4. Programming the VGA Optica 4.5.2 Pressure Input For more information on using these items, see “Process Pressure” on page 30. Table 8: Pressure Input Options Item Function Available Options Input Choose which pressure input channel is in use, or disable this V in (0-5), I in (4-20), or Use Default input.

  • Page 58: Alarms

    Inner Band: • alarm activates when parameter is outside upper and lower limits. Outer Band: • alarm activates when Optica is actively controlling mirror temperature. Control: • alarm activates when Service indicator is activated. Service: •...

  • Page 59: Automatic Cleaning And Balance Function

    Chapter 4. Programming the VGA Optica 4.5.4 Automatic Cleaning and Balance Function Note: For Optica Analyzers with earlier versions of software, see Appendix F. “Automatic Balance (for earlier software versions)“. Optica Analyzers with version 1.4.1a software have been upgraded to include the ability to program the PACER self-cleaning and rebalancing cycle to run once per day at a preset time.
  • Page 60 Chapter 4. Programming the VGA Optica 4.5.4 Automatic Cleaning and Balance Function (cont.) 3. Manually clean the mirror as required. Note: Manual cleaning provides the most thorough cleaning. 4. After manual cleaning, initiate the Automatic Cleaning & Balancing. 5. To program a specific time of day at which to initiate the Automatic Cleaning and Balancing: a.

  • Page 61: Data Fields

    Chapter 4. Programming the VGA Optica 4.5.5 Data Fields Table 11: Data Field Options Item Function Available Options Field Graph line number and numeric display number to be 1, 2, 3, 4, 5 or 6 programmed Parameter For the field selected above, choose which parameter will be Humidity, Temperature, Pressure output.

  • Page 62: Network Menu

    Table 13: Network Settings Options Item Function Available Options Host Name Enter the host name for the Optica unit of the LAN. Domain Enter the Domain name for the local network. IP Address Use the left and right arrow keys to select between...

  • Page 63: Datalog

    Chapter 4. Programming the VGA Optica 4.5.8 Datalog Enter parameters for automatically logging data within the Optica. This menu is accessed by selecting the Data Log control button on and pressing ENTER. Menu 1 Figure 32: Datalog Menu The large window below the center of the screen shows a list of parameters chosen for logging.
  • Page 64 To view or output the logged data, select the control button and Download press . The Optica will display the Download screen, described below. ENTER 4.5.8a Download Screen The Download Screen is accessed by pressing...

  • Page 65: Menu 2

    Chapter 4. Programming the VGA Optica 4.6 Menu 2 is shown in Figure 34 below. This menu is accessed by selecting , and pressing Menu 2 More Menu 1 ENTER Figure 34: Menu 2 4.6.1 General Table 15: General Options...

  • Page 66: Special

    Chapter 4. Programming the VGA Optica 4.6.2 Special Table 16: Special Option Item Function Available Options Mol. Wt. Gas: The molecular weight of the gas being analyzed Enter a number. (Default value is molecular weight of dry air: 28.9645) 4.6.3 User Equation...

  • Page 67: Serial Output Data

    Chapter 4. Programming the VGA Optica 4.6.4a Query Mode Format: Table 19: Query Mode Format Command: Returns . . . $HELP < > Help string $GETDATA 0 <item> <item> <item>... <item> Requested data items $GETSTATUS 0 < > Status string Query mode examples: $GETDATA 0 0 1 <...

  • Page 68: Set Time & Date

    Set Time and Date Menu 2 ENTER To set the Optica’s internal clock, press to select each field of the date and time, and press the up and down softkeys to set each field. When the settings are correct, tab to the...

  • Page 69: Saving Configuration Files

    Chapter 4. Programming the VGA Optica 4.7 Saving Configuration Files This option allows the user to save a configuration file and then load it onto the system for future use. Note: To activate the selected configuration, the system must be reset.
  • Page 70 Chapter 4. Programming the VGA Optica [no content intended for this page] Optica™ Operator’s Manual...

  • Page 71: Chapter 5. Programming The 4X40 Optica

    5.1 Introduction The 4x40 Optica can be easily programmed to choose the data to be displayed, the data to be output on the analog or serial outputs, and the alarm settings. A typical data display is shown in Figure 37 below: Tdew °...

  • Page 72: Programming Technique

    Chapter 5. Programming the 4x40 Optica 5.2 Programming Technique The functions of the four softkeys to the right of the display change according to the current state of the unit. These functions, if any, are displayed at the right edge of the screen. While programming, these keys are labelled...
  • Page 73 Chapter 5. Programming the 4x40 Optica Programming Technique (cont.) A typical programming screen (for setting the Analog Outputs) is shown in Figure 38 below. Analog Outputs DOWN Output A Parameter >> Temperature <<<< Figure 38: Typical Analog Outputs Programming Screen An example of programming the Serial Baud Rate is shown in Figure 39 below.

  • Page 74: Programmable Functions

    Chapter 5. Programming the 4x40 Optica 5.3 Programmable Functions 5.3.1 Analog Outputs Table 22: Analog Output Options Setting Description Available Options Output A Parameter Choose which parameter will be Humidity, Temperature, Pressure or output on analog channel A. User Equation...

  • Page 75: Serial Output Units

    Chapter 5. Programming the 4x40 Optica 5.3.3 Serial Output Units Table 24: Serial Output Unit Options Setting Description Available Options Humidity Units* Set the units for humidity. See Table 5 on page 42 for the parameter chosen. Temperature Units* Set the units for temperature.

  • Page 76: Alarms

    • Alarm activates when the parameter is outside the upper and lower limits. Outer Band: • Control: Alarm activates when the Optica is actively controlling the mirror temperature. • Alarm activates when the Service indicator is activated. Service: • Alarm activates when the balance is active.

  • Page 77: Data Fields

    Chapter 5. Programming the 4x40 Optica 5.3.6 Data Fields Table 27: Data Field Options Setting Description Available Options Line 1 Parameter Choose which parameter will be Humidity, Temperature, Pressure or output on Line 1. User Line 1 Units Set the units for the selected See Table 5 on page 42 for the parameter.

  • Page 78: Automatic Cleaning And Balance Function

    To program the Automatic Cleaning & Balance Function on the Optica 4X40 monitor: 1. Make sure the internal clock of the Optica has the correct time. From the main screen: a. Press the ENTER key.
  • Page 79 Chapter 5. Programming the 4x40 Optica 5.3.8 Automatic Cleaning and Balance Function (cont.) Table 29: Automatic Cleaning and Balance Functions Item Function Type AUTO Heats the mirror and balances the Elapsed Time Interval optics. PACER First cools the mirror to develop a...

  • Page 80: Buzzer And Sounds

    8. Power down and restart the Optica 4x40 display analyzer for the settings to take effect. For environments or a gas sample where the mirror accumulates contamination rapidly, the use of an IMPORTANT: inline filter is recommended.

  • Page 81: User Equations

    Chapter 5. Programming the 4x40 Optica 5.3.11 User Equations See “User Equations” on page 42 for programming information. Table 32: User Equation Options Setting Description Available Options Select Equation Choose an equation to enter or edit. 1, 2, or 3...

  • Page 82: User Default Settings

    Chapter 5. Programming the 4x40 Optica 5.3.14 User Default Settings Table 35: User Default Setting Options Setting Description Available Options Restore Defaults Restore settings to factory defaults NO, YES shown in Table 4 on page 35. 5.3.15 Factory Calibrations Table 36: Factory Calibration Options...

  • Page 83: Chapter 6. Network-Based Programming

    Chapter 6. Network-Based Programming Chapter 6. Network-Based Programming 6.1 Introduction The VGA Optica can also be programmed remotely from a computer over a network, using a browser program such as Internet Explorer. It may be necessary to download and install the...
  • Page 84 Click on to display the programming screen shown in Figure 41 below. Menu Data Figure 41: Data Programming Screen Press More... to display the screen shown in Figure 42 below. Other Options Figure 42: Typical Other Options Screen Optica™ Operator’s Manual...
  • Page 85 Chapter 6. Network-Based Programming Programming Screens (cont.) Press from the screen to configure the screen shown in Figure 43 below. Display Main Data Main Display Setup Figure 43: Main Display Setup Screen Optica™ Operator’s Manual...
  • Page 86 Chapter 6. Network-Based Programming [no content intended for this page] Optica™ Operator’s Manual...

  • Page 87: Chapter 7. Maintenance

    Under normal conditions, the system is self-checking and self-balancing. However, there are occasions when particulate matter and water-soluble contaminants reduce sensor mirror reflectance and system accuracy (see “Contamination” on page 37). Three features of the Optica system allow users to monitor and adjust the mirror: •...

  • Page 88: Procedure For Cleaning And Balancing The Sensor Mirror

    • Screwdriver or hex driver for some sensors • Cleaning solution 1. From the Optica analyzer, press the soft-key next to the button, or, from the Optica Java applet running HEAT on your PC, move your mouse pointer over the button and click.
  • Page 89 It might be useful to shade the sensor cavity with your hand or place a coin over the sensor cavity. 6. Once balanced, replace the sensor cap and make sure the balance indicator does not change. Optica™ Operator’s Manual...
  • Page 90 Chapter 7. Maintenance 7.1.2 Procedure for Cleaning and Balancing the Sensor Mirror (cont.) 7. From the Optica analyzer press the soft-key next to the button, or, from Optica Java applet running on PACER your PC, move your mouse pointer over the button and click.

  • Page 91: Field Replacement Of Sensor Mirrors

    The Optica is now reading Control the correct dew/frost point and a stable dew or frost layer has been established. When the Optica is exposed to typical room humidity, this process takes 5-6 minutes. For very dry conditions, the unit may not display...

  • Page 92: Replacing The Sensor Mirror

    TW-1 The kit supplied by GE contains the replacement mirror, a container of white thermal compound for proper heat transfer, and (in some models) a mylar washer that is to be placed under the mirror. To install the replacement mirror, complete the following steps: 1.

  • Page 93: Test And Calibration

    Chapter 7. Maintenance 7.3 Test and Calibration The procedures in this section effectively test and/or calibrate the following aspects of the Optica: • Startup and power supply voltage • Normal sensor operation • Front panel display • Digital and analog outputs.

  • Page 94: Incorrect Dew Point Display

    Din Type 100 Ohms at 0°C 0.385 Ohms/°C Resistance Display Reading Ohms °C (±0.1) °F (±0.2) 76.33 –60.0 –76.0 RX0.1 96.09 –10.0 14.0 100.00 32.0 103.90 10.0 50.0 RX0.01 123.24 60.0 140.0 Figure 49: Using a Resistance Decade Box Optica™ Operator’s Manual...

  • Page 95: Balance" Remains On The Status Line

    7.4.6 No Serial Output Check the serial port programming for proper settings. For the unit, see the instructions in “Serial Output Data” on page 55. For the unit, see the instructions in “Serial Output Setup” on page 63. 4x40 Optica™ Operator’s Manual...
  • Page 96 Chapter 7. Maintenance [no content intended for this page] Optica™ Operator’s Manual...

  • Page 97: Appendix A. Specifications

    Governed by accuracy of dew point and temperature sensors A.1.1f Other Humidity Parameters: (optional) Governed by accuracy of dew point, temperature and pressure sensors A.1.1g Sensitivity > 0.05°C (0.09°F) A.1.1h Repeatability ± 0.05°C (±0.09°F) A.1.1i Hysteresis Negligible Optica™ Operator’s Manual...

  • Page 98: Measurement Ranges

    A.1.3b Temperature Response: (optional) < 7 sec for step change within +25°C to +70°C (+77°F to +158°F) A.1.3c Pressure Response (optional): 1 sec to 90% of steady state (10% to 90% change) A.1.3d Update Time 1 sec Optica™ Operator’s Manual...

  • Page 99: Functionality

    Ambient Temperature: –15°C to +80°C (+5°F to + 176°F), depending on sensor Pressure: 0 to 300 psig (0 to 22 bar), depending on sensor) A.2.6b Electronics Ambient Temperature: 0°C to +50°C (+32°F to +122°F) Relative Humidity: 85% maximum Optica™ Operator’s Manual...

  • Page 100: Physical (Bench Mount)

    A.4 Physical (Wall Mount) A.4.1 Dimensions 13.70"W x 16.725"H x 6.5"D (348 x 425 x 165 mm) A.4.2 Weight 15.5 lb (7 kg) A.4.3 Shipping Weight 22.5 lb (10.2 kg) A.4.4 Environmental Surface-mount, industrial environment (Type 4) Optica™ Operator’s Manual...

  • Page 101: Optional Accessories

    Complies with EMC Directive 2004/108/EC and 2006/95/EC Low Voltage Directive (Installation Category II, Pollution Degree II) Note: Product has reduced limits for Radiated immunity between 88 and 108 MHz and conducted immunity between 11 and 32 MHz. [Specifications subject to change without notice] Optica™ Operator’s Manual...
  • Page 102 Appendix A. Specifications [no content intended for this page] Optica™ Operator’s Manual...

  • Page 103: Appendix B. Humidity Equations And Conversion Chart

    The total pressure of a gas mixture is equal to the sum of the partial pressure each gas would exert, were it to occupy the same total volume, according to Dalton’s law. Optica™ Operator’s Manual...

  • Page 104: Humidity

    Expressing water vapor content as parts per million by weight (or mixing ratio) requires multiplication of the above by the ratio of the molecular weight of water to that of air as given by the following: × 0.622 ---------- - – See Figure 50 on page 93 for a graphical humidity conversion chart. Optica™ Operator’s Manual...
  • Page 105 Appendix B. Humidity Equations and Conversion Chart Humidity (cont.) WATER VAPOR CONVERSIONS Figure 50: Graphical Humidity Conversion Chart Optica™ Operator’s Manual...
  • Page 106 Appendix B. Humidity Equations and Conversion Chart [no content intended for this page] Optica™ Operator’s Manual...

  • Page 107: Appendix C. Configuring The Serial Interface

    • Pin 3 - Received data ( • Pin 5 - Signal ground ( To send the output of the Optica to a personal computer, use the cable arrangement shown in Figure 51 below. Optica 9-Pin Male 9-Pin Figure 51: Wiring Diagram - Optica to Personal Computer...
  • Page 108 Appendix C. Configuring the Serial Interface [no content intended for this page] Optica™ Operator’s Manual...

  • Page 109: Appendix D. Chilled Mirror Sensors

    Many of these features were pioneered by GE Measurement & Control, and are available only on GE products. A chilled mirror sensor is generally selected so that its depression capability will allow it to measure the lowest dew/frost point anticipated for the application.

  • Page 110: Measurement Range

    2°C (4°F) of depression capability. Conversely, operating under vacuum may result in a small increase. Other factors influencing sensor selection include temperature and pressure ratings, and whether anticipated dew points will be higher than ambient temperature. Optica™ Operator’s Manual...

  • Page 111: Comparing Optica Sensor Models

    Appendix D. Chilled Mirror Sensors D.4 Comparing Optica Sensor Models See Table 37 below for a comparison of the various Optica chilled mirror sensors. Table 37: Chilled Mirror Sensor Comparison Chart Model Model Model Model Model Model Parameter 1111H 1211H...
  • Page 112 Appendix D. Chilled Mirror Sensors [no content intended for this page] Optica™ Operator’s Manual...

  • Page 113: Appendix E. Glossary

    The temperature difference by which the chilled mirror can be lowered from the ambient temperature. Network A Local Area computer Network (LAN) or Wide Area Network (WAN) such as the Internet. The Optica can be operated or programmed remotely over a network.
  • Page 114 Appendix E. Glossary [no content intended for this page] Optica™ Operator’s Manual...

  • Page 115: Appendix F. Automatic Balance (For Earlier Software Versions)

    Appendix F. Automatic Balance (for earlier software versions) Appendix F. Automatic Balance (for earlier software versions) Programming Automatic Balance for a VGA Optica Note: For Optica Analyzers with software version 1.4.1a or later, see “Automatic Cleaning and Balance Function” on page 47. Table 36: Automatic Balancing Options...
  • Page 116 Appendix F. Automatic Balance (for earlier software versions) [no content intended for this page] Optica™ Operator’s Manual...

  • Page 117: Appendix G. Communicating With The Optica Using Ethernet

    Appendix G. Communicating with the OPTICA Using Ethernet Appendix G. Communicating with the OPTICA Using Ethernet G.1 Direct Communication The networking configuration for an model can be done using the front panel. The networking OPTICA VGA configuration for a 4x40 Optica...

  • Page 118: Computer Communication

    Optica. Commands that are used to retrieve information from the Optica are preceded with the prefix Get, and those that are used to set parameters at the Optica are preceded with the prefix Set. Only the commands that enable the user to retrieve information from the Optica are detailed in this document.

  • Page 119: Retrieving The Alarm Settings

    Appendix G. Communicating with the OPTICA Using Ethernet G.2.1 Determining the Available Commands (cont.) <OpticaAPI>SetAutoBalanceTypes</OpticaAPI> <OpticaAPI>SetChannelInfo</OpticaAPI> <OpticaAPI>SetCoolState</OpticaAPI> <OpticaAPI>SetCurrentData</OpticaAPI> <OpticaAPI>SetDataFields</OpticaAPI> <OpticaAPI>SetDataLogSettings</OpticaAPI> <OpticaAPI>SetHeatState</OpticaAPI> <OpticaAPI>SetHTPLabels</OpticaAPI> <OpticaAPI>SetHTPParam</OpticaAPI> <OpticaAPI>SetPacerOn</OpticaAPI> <OpticaAPI>SetPressureData</OpticaAPI> <OpticaAPI>SetOpticaInfo</OpticaAPI> <OpticaAPI>SetSerialCommData</OpticaAPI> <OpticaAPI>SetSerialData</OpticaAPI> <OpticaAPI>SetSupportedBaudRate</OpticaAPI> <OpticaAPI>SetSupportedDataBits</OpticaAPI> <OpticaAPI>SetSupportedSerialDataFormat</OpticaAPI> <OpticaAPI>SetUserDefinedEquations</OpticaAPI> </OpticaAPIInfo> G.2.2 Retrieving the Alarm Settings Command: http://3.112.160.36:28005/OpticaAPI.xml?GetAlarmData+0...

  • Page 120: Retrieving The Alarm Types

    G.2.2 Retrieving the Alarm Settings (cont.) The Optica supports two alarm set points: The above response shows the settings for alarm 1 and alarm 2 in that order. (Note that the index is referenced from 0 , not 1). Alarm 1 parameters are described below.

  • Page 121: Retrieving Supported Units

    Appendix G. Communicating with the OPTICA Using Ethernet G.2.4 Retrieving Supported Units This command enables the user to retrieve different units that are supported by the Optica and the order in which they are referenced. Command: http://3.112.160.36:28005/OpticaAPI.xml?GetAllLabels Function Name: GetAlarmTypes...

  • Page 122: Retrieving Labels And Functions

    G.2.5 Retrieving Labels and Functions This command enables the user to retrieve different units that are supported by the Optica, and the order in which they are referenced. It also indicates which labels are humidity labels, temperature labels and pressure labels.
  • Page 123 Appendix G. Communicating with the OPTICA Using Ethernet G.2.5 Retrieving Labels and Functions (cont.) <sUserLabels>UserEquation2</sUserLabels> <sUserLabels>UserEquation3</sUserLabels> <iLabels>33</iLabels> <sLabels>Tdew °C</sLabels> <sLabels>Tdew °F</sLabels> <sLabels>%RH</sLabels> <sLabels>Twet °C</sLabels> <sLabels>Twet °F</sLabels> <sLabels>ppmv</sLabels> <sLabels>ppmw</sLabels> <sLabels>Grains/lb</sLabels> <sLabels>Grains/SCF</sLabels> <sLabels>g/kg</sLabels> <sLabels>g/m3</sLabels> <sLabels>lb/Mft3</sLabels> <sLabels>Kj/Kg (0)</sLabels> <sLabels>Kj/Kg (32)</sLabels> <sLabels>Btu/lb (0)</sLabels> <sLabels>Btu/lb (32)</sLabels>...

  • Page 124: Retrieving Analog Output Information

    Appendix G. Communicating with the OPTICA Using Ethernet G.2.6 Retrieving Analog Output Information This command enables the user to retrieve settings for the two analog outputs. Command: http://3.112.160.36:28005/OpticaAPI.xml?GetAnalogOutData+0 Function Name: GetAnalogOutData Channel: 0 Response: <?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <OpticaAPIReturn Function="GetAnalogOutData">...
  • Page 125 Appendix G. Communicating with the OPTICA Using Ethernet G.2.7 Retrieving the Measured and Calculated Values (cont.) <fAllData>48.800430</fAllData> <fAllData>4014.087158</fAllData> <fAllData>2496.681885</fAllData> <fAllData>17.476774</fAllData> <fAllData>6.832514</fAllData> <fAllData>2.496682</fAllData> <fAllData>2.985780</fAllData> <fAllData>186.449982</fAllData> <fAllData>43.695812</fAllData> <fAllData>26.523333</fAllData> <fAllData>19.541956</fAllData> <fAllData>11.861956</fAllData> <fAllData>4.055074</fAllData> <fAllData>21.146547</fAllData> <fAllData>70.100189</fAllData> <fAllData>294.306549</fAllData> <fAllData>529.753784</fAllData> <fAllData>14.710732</fAllData> <fAllData>1014.265686</fAllData> <fAllData>1.014266</fAllData> <fAllData>101426.570313</fAllData> <fAllData>101.426567</fAllData> <fAllData>760.761841</fAllData> <fAllData>29.239281</fAllData>...

  • Page 126: 4X40 Optica Configuration

    Appendix G. Communicating with the OPTICA Using Ethernet G.2.8 4X40 Optica Configuration Using an RS-232 communication link, the user can set the network settings. To see the set of supported commands, type "$Help<>" 1. $SetIPAddress <IP ADDRESS><> (i.e., $SetIPAddress 3 112 60 36) 2.
  • Page 127 ....103 4x40 Optica (earlier software) ......65 4x40 Optica .
  • Page 128 ....114 4x40 Optica Configuration ......17 Inner Band Alarm .
  • Page 129 ....99 Optica Models Comparison ....... . 27 Normal .
  • Page 130 ......91 Vapor Pressure ......31 Measuring Optica™ Operator’s Manual...
  • Page 131 ....37 Water-Soluble Contaminants ......xii WEEE Directive Optica™ Operator’s Manual...
  • Page 132 Index [no content intended for this page] Optica™ Operator’s Manual...
  • Page 133 RETURN AUTHORIZATION NUMBER (RAN), and shipping instructions for the return of the instrument to a service center will be provided. 2. If GE Sensing instructs you to send your instrument to a service center, it must be shipped prepaid to the authorized repair station indicated in the shipping instructions.
  • Page 134 Warranty [no content intended for this page] Optica™ Operator’s Manual...
  • Page 135 • EN 61326-1: 2013, Group 1, Class A, Table 1, Basic EM Environments (For EN 61000-4-3 and EN 610004-6, the Optica meets performance criteria A and, in a limited number of frequencies, performance criteria B per EN 61326) •...
  • Page 136 [no content intended for this page]...
  • Page 138 Customer Support Centers U.S.A. The Boston Center 1100 Technology Park Drive Billerica, MA 01821 U.S.A. Tel: 800 833 9438 (toll-free) 978 437 1000 E-mail: sensing@ge.com Ireland Sensing House Shannon Free Zone East Shannon, County Clare Ireland Tel: +353 (0)61 470200 E-mail: gesensingsnnservices@ge.com An ISO 9001:2008 Certified Company www.gemeasurement.com/quality-certifications...

Table of Contents
