1-3. SS-F6000P
101
Ref. No. Part No. Description
101 A-1226-249-A GRILLE FRAME ASSY
102 2-899-184-01 WOOFER RING
103 1-826-595-11 LOUDSPEAKER (16cm)
104 1-826-596-11 LOUDSPEAKER (16cm)
105 2-898-826-01 MIDRANGE RING
106 4-254-182-01 CATCHER
4
106
105
103
102
not supplied
102
not supplied
Remark
110
109
108
107
104
106
not supplied
Ref. No. Part No. Description
107 4-874-614-12 SCREW (1) (3.5X14), TAPPING
108 1-826-594-11 LOUDSPEAKER (8cm)
109 4-235-903-02 SCREW (3.5X20)
110 X-2176-239-1 TWEETER ASSY
111 A-1226-248-A SPEAKER CABINET ASSY (BLACK) (US, CND, E)
111 A-1226-317-A SPEAKER CABINET ASSY (WOOD) (AEP, E)
111
Remark
