Digital Multi Processor
WZ-DM35NH
GEQ
CH PEQ
•
2 inputs and 4 outputs.
•
6 functions: Graphic equalizer function, parametric
equalizer function, delay function, crossover network
function, compressor/limiter function, and noise gate
function.
•
6 Basic Modes: Three delay modes for sense-of-direction
control (DELAY1 to DELAY3) and three crossover
network modes (X-OVER1 to X-OVER3)
•
Built-in digital audio interface and conforms to the
AES/EBU format.
•
24-bit A/D and D/A converters are employed for analog
inputs and outputs to offer a dynamic range close to that
of an analog device.
•
All settings can be saved in up to 16 patterns in the
memory.
Dimensions
480
465
Rear Panel
X-OVER
LEVEL
SPECIFICATIONS
General Frequency Response
User Memory
External Type
Control Connector
5
275
Unit : mm
DELAY
Model No.
Input
No. of Channels
2 ch
Analog
Type
Electronic balance
Rated Input
+4 dB
Maximum Input
+24 dB or more
Connector
XLR-3-31 or equivalent, 2 connectors
Input Impedance
20 kΩ
In-Phase Reject Ratio
40 dB or more
24-bit ∆-∑ type
A/D Converter
Digital
Type
AES/EBU format, for professional use
Sampling Frequency
48 kHz±0.1%
Connector
XLR-3-31 or equivalent, 1 connector
Output No. of Channels
4 ch
Analog
Type
Electronic balance
Rated Output
+4 dB±1 dB
Maximum Output
+24 dB or more (at 10 kΩ load)
Output Impedance
150Ω
Connector
XLR-type connector or equivalent, x4
Applicable Load Impedance 600Ω or more
24-bit ∆-∑ type
D/A Converter
Digital
Type
AES/EBU format, for professional use
Sampling Frequency
48 kHz
Connector
XLR-3-31 or equivalent, 1 connector
(Recommended cable: Canare Electric DA206 or equivalent)
20 to 20,000 Hz, +0.5, –1.0 dB
Dynamic Range
Analog input/output (typ, IHF-A)
115 dB (noise gate ON)
109 dB (noise gate OFF)
THD
0.015% at +4 dB, 20 to 20,000 Hz, 30 kHz LPF (at 600Ω load)
Crosstalk
–70 dB or less (10 kHz)
No. of memories: 16
RS-485 RAMSA-NET (See Note.)
D-SUB 9-pin, IN/OUT 1 each, setscrew M2.6
Recommended connectors
Male: OMRON XM2A-0901 or equivalent
Female: OMRON XM2D-0901 or equivalent
Hood: OMRON XM2S-0911 or equivalent
Pattern Type
Make contact type, No. of control patterns: 12 + MUTE
Control
Anti-reverse diode provided
Connector
D-SUB 15-pin, setscrew M2.6
Recommended connectors
Male: OMRON XM2A-1509 or equivalent
Hood: OMRON XM2S-1511 or equivalent
Power Supply
AC220-240V 50/60Hz
Power Consumption
19 W (as defined in the Electrical Appliances Control Act)
Heat Flow
19 W (15 kcal)* The figure in parentheses is calorific value per hour.
Stacking Conditions
2 units high maximum
* If you are using 3 units or more, leave a space for a unit or more every 2 units.
Dimensions
480 (W) x 44 (H) x 280 (D) mm (without rubber feet)
Weight (approx.)
4.5 kg
Note: "RAMSA-NET" is a protocol exclusive to Matsushita Communication Industrial Co., Ltd.,
used to send and receive data between the host computer and two or more audio control units
connected to it with communication lines.
